INSTALLATION AND OWNER’S MANUAL GATE STAR 6000 GATE STAR 6000 Model GS6000 - Heavy Duty Commercial Model GS6000 - Heavy Duty Commercial Vehicular Swing Gate Operator Vehicular Swing Gate Operator 112538 EXPLODED VIEW / PARTS LIST TECHNICAL SPECIFICATIONS... - Page 2 OPERATOR EXPLODED VIEW Figure 24: GS6000 Exploded View...
- Page 3 PARTS LIST - EXPLODED VIEW PART # DESCRIPTION PART # DESCRIPTION 005068 CON, 3/8 FLEX Conduit, Straight, AMP 207370-1 101490 Terminal Block, Barrier Type, 11 POS 005244 Transformer, 120V-24V, 50/60 Hz, Class 2, 40VA 103399 Screw, 10-32 x 3/8, HX SL WA, T/F, Green 006030 Screw, 5/16-18 x 1, ZI 104058...
- Page 4 Action D - Pull the release pin completely out of the arm assembly. The gate can now be moved manually. 112088-03 112088-02 Reverse above to put the operator back into automatic service. c.p. Allstar Corporation P/N 113025 Rev. A January 2006 Downingtown, PA 19335...
