Page 1: Operation Manual
S-125 S-125C Miller & Kreisel Sound Corporation 10391 Jefferson Boulevard Culver Cit y, CA 90232 USA (310) 204-2854 FAX (310) 202-8782 © 1996 MILLER & KREISEL SOUND CORP. S-85 S-85C... -
Page 2: Table Of Contents
S-125/S-125C/S-85/S-85C 1. INTRODUCTION...3 2. BASIC PLACEMENT OF YOUR SATELLITE SPEAKERS...3 3. SPEAKER HOOK-UP & USAGE...3 ...4 HOOK-UP VARIATIONS OF SOUND 4. S-125C & S-85C CENTER CHANNEL USAGE...6 5. OPTIMIZING SPEAKER PLACEMENT...6 6. HOME THEATRE USAGE...7 CENTER CHANNEL USAGE 7. SATELLITE/SUBWOOFER PHASING TEST...10 8. -
Page 3: Introduction
If you have any questions about your speaker system, please contact your M&K dealer or call the M&K factory directly at (310) 204-2854, from 8:30 AM to 5:00 PM Pacific Time, Monday through Friday. We will be happy to help you with any question, no matter how simple or complex it may be. -
Page 4: Hook-Up
S-125/S-125C/S-85/S-85C Your M&K Satellites are not designed for bi-wiring. Do not use the four input terminals to bi-wire your Satellites, as this may damage your amplifier and speakers. If you wish to bi-amplify your Satellites in combination with an M&K Powered Subwoofer, see Section 9 (page 11) for more details. -
Page 5: Figure 1 Speaker Wiring
S-125/S-125C/S-85/S-85C The four diagrams below show all possible wiring configurations for the S-125, S-125C, S-85 and S-85C. See page 4 for a detailed discussion of the effect these configurations have on the sound of the speakers. MAXIMUM OUTPUT / WIDE RANGE MILLER &... -
Page 6: S-125C & S-85C Center Channel Usage
S-125/S-125C/S-85/S-85C If you have a separate electronic high-pass filter (such as the M&K VF-80 or HP-80), always use the WIDE RANGE terminals, as you do not want to have this combination of dual filters operating. This also applies if your amplifier or controller has built-in high-pass filters (such as THX-approved components and AC-3 units). -
Page 7: Home Theatre Usage
S-125/S-125C/S-85/S-85C SEPARATION BETWEEN LEFT & RIGHT SPEAKERS LEFT SPEAKER If the speakers are on a television set or shelves, locate them on the front edge, so there is no flat surface directly in front of them. If the speakers will sit close to walls or other large objects, leave as much space as possible between the speaker and the object. -
Page 8: Center Channel Usage
S-125/S-125C/S-85/S-85C If the other speakers are not M&Ks, don't worry; M&K's unique tonal balance controls allow the M&K speakers to be adjusted to emulate the sound of the other speakers. Here's how: Set up a listening comparison between your the M&K speaker and the other speaker. Connect one speaker to the front right channel and the other to the front left channel. -
Page 9: Surround Channels
S-125/S-125C/S-85/S-85C When using a Center channel speaker, you have extra flexibility in placing the left and right speakers, as the Center channel speaker will tie most dialog and effects directly to the screen. The Surround channel speakers can be placed in a wide variety of locations in the room to give good performance. -
Page 10: Satellite/Subwoofer Phasing Test
S-125/S-125C/S-85/S-85C 7. SATELLITE/SUBWOOFER PHASING TEST In any system using a subwoofer separate from Satellite speakers, a phasing test must be performed to insure good bass blending. This test insures optimum sound in the critical bass frequencies where your Subwoofer and Satellite speakers overlap. -
Page 11: Bi - Amplifying Your Satellites With M&K High-Pass Filters
The S-125 and S-125C Satellites contain both the threaded (3/8") insert and 1/4" inserts (1/4-20) located on the speaker's back baffle (the S-125 has two and the S-125C has four). This gives you two options to mount the speaker to either the M&K ST-1 or ST-2 stands or to an OmniMount bracket. -
Page 12: Use With Omnimount Bracket
USE WITH AN OMNIMOUNT The drawings below are from the OmniMount catalog and are not intended to show the actual dimensions and specific mounting locations on the S-125 and S-85. Please see the back baffles of your speaker cabinets. S-125 and S-125C...
