Summary of Contents for MK Sound Tripole CS-22
-
Page 1: Operation Manual
CS-150 Tripole CS-35 Tripole ® CS-29 Tripole ® CS-22 Tripole ® ®... -
Page 2: Table Of Contents
COLUMN SURROUND SPEAKER INTRODUCTION...3 THE COLUMN SURROUND SPEAKER...3 THE TRIPOLE ® SURROUND CONCEPT...3 SPEAKER HOOK-UP...4 SPEAKER PLACEMENT...5 COLUMN SURROUND MOUNTING OPTIONS...7 CUSTOM MODES AND REMOTE OPERATION (CS-150 ONLY)...9 SPEAKER POLARITY TEST...10 SPEAKER DAMAGE & HOW TO AVOID IT...11 IF YOU NEED SERVICE...11 M&K TEN YEAR WARRANTY...11 CABINET MAINTENANCE...12 SPECIFICATIONS...12... -
Page 3: Introduction
If you have any questions about your speaker system, please contact your M&K dealer or call the M&K factory directly at (818) 701-7010, from 8:30 AM to 5:00 PM Pacific Time, Monday through Friday. We will be happy to help you with any question. -
Page 4: Speaker Hook-Up
RED ( + ) "INPUT" terminal labeled "1", and the Negative ( — ) lead from your amplifier or receiver should be connected to the BLACK ( — ) "INPUT" terminal labeled "2". See Figure 2. FIGURE 1 BASIC WIRING FOR CS-35, CS-29, CS-22 COLUMN TRIPOLE ®... -
Page 5: Speaker Placement
COLUMN SURROUND SPEAKER TRIPOLE ® OR DIPOLE OPERATION (CS-150 ONLY) To operate in the Tripole ® mode, the jumper between the terminals labeled "3" and "4" must be in place. To operate the speaker in the Dipole mode, the jumper between the terminals labeled "3" and "4" must be removed. Do not throw away or lose this jumper. - Page 6 In the CS-150, these drivers radiate forward, and in the CS-35, CS-29, and CS-22, these drivers radiate upward. The CS-35, CS-29, and CS-22 also have an additional 6.5" woofer to provide greater output at low frequencies.
-
Page 7: Column Surround Mounting Options
Here are the parts you need: 2 each: Column Surround Speakers 2 each: Bases CS-35, CS-29, CS-22: 10" x 11" CS-150: 8" x 9 3/8" 4 each: 1/4 -20 x 1" Phillips Pan Head machine screw (PN 20590) TOOLS REQUIRED: Phillips screwdriver... - Page 8 Column Surround. For the CS-35, CS-29, and CS-22, this is direct- ly behind the 6.5" woofer. You will first need to remove the round head screws that are installed at the factory before shipment.
-
Page 9: Custom Modes And Remote Operation (Cs-150 Only)
COLUMN SURROUND SPEAKER You have two sets of mounting locations (4 holes per set). You can use either set of mounting holes on the mounting plate to adjust the location of the speaker depending on the floor covering and the moulding at the base of the wall. -
Page 10: Speaker Polarity Test
COLUMN SURROUND SPEAKER e. Tripole ® With Adjustable Attenuated Dipole To adjust the attenuation of the Dipole element, connect the positive (+) lead to Terminal 3 and insert a 5 watt resistor between terminals 3 and 4. The resistor can be any value between 2 and 11 ohms. -
Page 11: Speaker Damage & How To Avoid It
9. SPEAKER DAMAGE & HOW TO AVOID IT An important factor to consider with any speaker system is the potential for speaker damage. Even though your speakers have high power handling ability, they still can be damaged by relatively low powered amplifiers. -
Page 12: Cabinet Maintenance
BASE DIMENSIONS: WEIGHT: CS-29 IMPEDANCE: MINIMUM POWER: RECOMMENDED POWER: MAXIMUM POWER: FREQUENCY RESPONSE: CABINET DIMENSIONS: BASE DIMENSIONS: WEIGHT: CS-22 IMPEDANCE: MINIMUM POWER: RECOMMENDED POWER: MAXIMUM POWER: FREQUENCY RESPONSE: CABINET DIMENSIONS: BASE DIMENSIONS: WEIGHT: 4 ohms 10 watts RMS 25 watts RMS to 200 watts RMS 200 watts RMS unclipped peaks 80 - 20 kHz ±...
