- Page 1 Induction Hob Instruction Manual / Installation Manual MODEL: VGIT70B...
-
Page 2: Product Overview
Congratulatio ns on the purchase of your new “VOGUE" induction Hob. We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install correctly and operate it. For installation, please read the installation section. -
Page 3: A Word On Induction Cooking
A Word on Induction Cooking Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it up. iron pot magnetic circuit ceramic glass plate... -
Page 4: Choosing The Right Cookware
Choosing the right Cookware • Only use cookware with a base suitable for induction cooking. Look for the induction symbol on the packaging or on the bottom of the pan. • You can check whether your cookware is suitable by carrying out a magnet test. -
Page 5: Using Your Induction Hob
Using your Induction Hob To start cooking 1. Touch the ON/OFF control. After power on, the buzzer beeps once, all displays show “ – “ or “ – – “, indicating that the induction hob has entered the state of standby mode. 2. -
Page 6: If The Display Flashes
If the display flashes alternately with the heat setting This means that: • you have not placed a pan on the correct cooking zone or, • the pan you’re using is not suitable for induction cooking or, • the pan is too small or not properly centred on the cooking zone. No heating takes place unless there is a suitable pan on the cooking zone. -
Page 7: Locking The Controls
4. Beware of hot surfaces H will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. It can also be used as an energy saving function if you want to heat further pans, use the hotplate that is still hot. -
Page 8: Auto Shutdown Protection
Auto Shutdown Protection Auto shut down is a safety protection function for your induction hob. It shut down automatically if ever you forget to turn off your cooking. The default working times for various power levels are shown in the below table: . Power level Default working timer (hour) When the pot is removed, the induction hob can stop heating immediately and the... -
Page 9: Setting The Timer To Turn One Cooking Zone Off
3. Set the time by touching the control of the timer Hint: Touch the control of the timer once to decrease or increase by 1 minute. Hold the control of the timer to decrease or increase by 10 minutes. If the setting time exceeds 99 minutes, the timer will automatically return to 00 minute. - Page 10 1. Touching the heating zone selection control that you want to set the timer for. (e.g. zone 3#) 2. Touch timer control , The minder indicator will start flashing and “10” will show in the timer display. 3. Set the time by touching the or control of the timer Hint: Touch the control of the timer...
-
Page 11: Cooking Guidelines
5. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator flash for 5 seconds. NOTE: The red dot next to power level indicator will illuminate indicating that zone is selected. 6. -
Page 12: Heat Settings
setting higher than the lowest setting to ensure the food is cooked properly in the time recommended. Searing steak To cook juicy flavoursome steaks: 1. Stand the meat at room temperature for about 20 minutes before cooking. 2. Heat up a heavy-based frying pan. 3. -
Page 13: Care And Cleaning
• reheating 3 - 4 • rapid simmering • cooking rice • pancakes 5 - 6 • sautéing 7 - 8 • cooking pasta • stir-frying • searing • bringing soup to the boil • boiling water Care and Cleaning What? How? Important! -
Page 14: Hints And Tips
Boilovers, melts, Remove these immediately • Remove stains left by melts and with a fish slice, palette knife or sugary food or spillovers as soon hot sugary spills on razor blade scraper suitable for as possible. If left to cool on the the glass Induction glass cooktops, but glass, they may be difficult to... - Page 15 The touch controls are There may be a slight film of Make sure the touch control area is difficult to operate. water over the controls or you dry and use the ball of your finger may be using the tip of your when touching the controls.
-
Page 16: Failure Display And Inspection
The above are the judgment and inspection of common failures. Please do not disassemble the unit by yourself to avoid any dangers and damages to the induction hob. Technical Specification Cooking Hob VGIT70B Cooking Zones 4 Zones Supply Voltage 220-240V~... -
Page 17: Selection Of Installation Equipment
Installation Selection of installation equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant work surface material to avoid larger deformation caused by the heat radiation from the hotplate. -
Page 18: Before Locating The Fixing Brackets
A(mm) B(mm) C(mm) 50 mini 20 mini Air intake Air exit 5mm Before you install the hob, make sure that • the work surface is square and level, and no structural members interfere with space requirements • the work surface is made of a heat-resistant material •... -
Page 19: Connecting The Hob To The Mains Power Supply
Adjust the bracket position to suit for different table top thickness. Cautions 1. The induction hotplate must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. The hob will not be installed directly above a dishwasher, fridge, freezer, washing machine or clothes dryer, as the humidity may damage the hob electronics 3. -
Page 20: Safety Warnings
• If the cable is damaged or to be replaced, the operation must be carried out the by after-sale agent with dedicated tools to avoid any accidents. • If the appliance is being connected directly to the mains an omnipolar circuit-breaker must be installed with a minimum opening of 3mm between contacts. -
Page 21: Operation And Maintenance
as it • could reduce your installation costs. • In order to avoid a hazard, this appliance must be installed according to these instructions for installation. • This appliance is to be properly installed and earthed only by a suitably qualified person. •... - Page 22 • Do not place or leave any magnetisable objects (e.g. credit cards, memory cards) or electronic devices (e.g. computers, MP3 players) near the appliance, as they may be affected by its electromagnetic field. • Never use your appliance for warming or heating the room. •...
- Page 23 This appliance is labeled in compliance with European directive 2002/96/EC for Waste Electrical and Electronic Equipment (WEEE). By ensuring that this appliance is disposed of correctly, you will help prevent any possible damage to the environment and to human health, which might otherwise be caused if it were disposed of in the wrong way.
