GPLT-26CC
UK Subject to change
Petrol Grass Trimmer
USER'S MANUAL
WARNING • PLEASE READ
For your own safety please read this manual before
attempting to operate your new unit. Failure to follow
instructions can result in serious personal injury. Spend
a few moments to familiarize yourself with your trimmer
before each use.
Warning! The silencer or catalytic silencer
and surrounding cover may become
extremely hot. Always keep clear of
exhaust and silencer area, otherwise
serious personal injure may occur.
Warning! Avoid inhaling the engine
exhaust from this product as it contains
chemicals which can cause cancer, birth
defects or reproductive harm.
Art. no. LTM6002
www.servotool.nl
0601-18
Advertisement
Related Manuals for Gardenline GPLT-26CC
Summary of Contents for Gardenline GPLT-26CC
- Page 1 GPLT-26CC UK Subject to change Petrol Grass Trimmer USER’S MANUAL WARNING • PLEASE READ For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarize yourself with your trimmer before each use.
- Page 2 EXPLODED VIEW Fig.1 Fig.2 Gardenline Gardenline...
- Page 3 SPARE PARTS LIST GPLT-26cc GARDENLINE NR. DESCRIPTION POSITION 400540 Switch A. 16 400541 Wire spool A. 21 5” (13cm) 400542 Protective cover A. 23 400543 Starter cord B. 2 400544 Fuel cap B. 32-1 Fig.3 Fig.4a Fig.4b Fig.4c Fig.4d Fig.4e...
- Page 4 Fig.4f Fig.4g Fig.4h Fig.5 BUMP Fig.6a Fig.6b Gardenline Gardenline...
- Page 5 Fig.7a Fig.7b A. KNOB B. SPOOL C. SPRING D. SPINDLE E. HOUSING F. SLOTS G. EYELETS H. TRIMMING LINE Fig.8a Fig.8b Fig.8c Fig.8d Gardenline Gardenline...
- Page 6 Fig.8e Fig.8f Fig.8g Fig.9 Fig.10a Fig.10b Gardenline Gardenline...
- Page 7 W. Kamphof Quality department Fig.12 It is our policy to continuously improve our products and we therefore reserve the right to change the product specification without prior notice. Servotool BV • Lingenstraat 6 • 8028 PM • Zwolle NL Gardenline Gardenline...
- Page 8 Petrol grass trimmer GPLT-26cc Removing a unit from storage • Remove spark plug. • Pull starter rope briskly to clear excess oil from combustion chamber. THE NUMBERS IN THE FOLLOWING TEXT CORRESPOND WITH THE PICTURES AT • Clean and gap spark plug or install a new spark plug with proper gap.
-
Page 9: Safety Instructions
Pour 1 teaspoon of clean 2-cycle oil into the combustion chamber. Pull starter rope slowly Never use blades several times to coat internal components. Replace spark plug. • Store unit in a cool, dry place away from any source of ignition such as an oil burner, water heater, etc. Gardenline Gardenline... -
Page 10: Maintenance Instructions
DO NOT USE ANY OTHER FUEL than that recommended in your manual. Always follow • Wash filter in soap and water. DO NOT USE PETROL! instructions in the Fuel and Lubrication section of this manual. Never use unleaded petrol • Air dry filter. Gardenline Gardenline... - Page 11 Note: Even with care, trimming around foundations, brick or stone walls, curves, etc., will • DO NOT use blades on this model. result in above normal line wear. Trimming / mowing Gardenline Gardenline...
- Page 12 Mixing fuel • Move ignition switch to the “RUN (I)” position (Fig. 5). Mix fuel with Gardenline brand 2 cycle oil in an approved container. Use mixing table for • Grip handle firmly, squeeze throttle trigger to FULL position. correct ratio of fuel to oil. Shake container to ensure thorough mix.
