- Page 1 Portable Petrol Generators DG 950P DG 3500PX DG 5000P DG 11000PS Installation & Operating Manual...
-
Page 3: Table Of Contents
INDEX GENERATOR SPECIFICATIONS 2. CONTROLS ELECTRICAL CONNECTIONS GENERATOR OPERATION ROUTINE MAINTENANCE SAFETY WARNINGS TROUBLE SHOOTING WARRANTY © Davis & Shirtliff Ltd 2015 Contents herein are not warranted... -
Page 4: Generator Specifications
Thank you for choosing Dayliff DG generator. It has been manufactured to the highest standards and if operated correctly should give many years of efficient and trouble free service. Careful reading of this instruction manual is therefore extremely important and if you have any queries please refer them to your retailer. -
Page 5: Specifications
Model Starter Rated Capacity capacity Period Model (kVA) (kVA) (cc) Power (HP) (litres) (Hrs) LT1E45, 2T DG 950P 0.65 0.72 Recoil Honda GX160, 4T DG 2500H Recoil LT200, 4T DG 3000P Recoil LT210, 4T DG 3500PX Recoil LT390, 4T DG 5000P... -
Page 6: Controls
2. CONTROLS All generators are fitted with the following:- 2 no 3 pin AC outlets, +ve and -ve DC connections. DG950 with one outlet Engine on/off switch. Magnetic circuit breaker electric cutout. Voltmeter (Not DG950) 3. ELECTRICAL CONECTIONS If the generator is to be connected for standby power use ensure a qualified electrician is employed. -
Page 7: Routine Maintenance
Close fuel valve whenever generator is not operating. DG 950 generators use two-stroke engines and oil must be pre-mixed with · petrol at the ratio of 50:1. Use fuel tank cap as an oil measure adding one inverted capfull for each litre of fuel. Engine damage will occur without pre-mixed oil. -
Page 8: Safety Warnings
6. SAFETY WARNINGS Read and carefully understand the Instruction Instruction Manual before before use. Manual Avoid proximity to fire when refueling. Highly inflammable! Ensure good ventilation around the generator and do not operate indoors. Exhaust gases are very poisonous. Do not use generator on a slope. Fuel spillage may occur and cause a fire. -
Page 9: Trouble Shooting
7. TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Carburettor is blocked Clean carburettor Spark plug is wet / dirty Clean and adjust plug Air cleaner dirty Clean air cleaner Reduce oil to suitable level Too much engine oil Engine does Oil sensor is activated. Add oil not start (Oil sensor prevents engine Insufficient engine oil... -
Page 10: Warranty
8. TERMS OF WARRANTY i) General Liability In lieu of any warranty, condition or liability implied by law, the liability of Davis & Shirtliff (hereafter called the Company) in respect of any defect or failure of equipment supplied is limited to making good by replacement or repair (at the Company's discretion) defects which under proper use appear therein and arise solely from faulty design, materials or workmanship within a specified period. - Page 12 INS302F-06/15...
