Summary of Contents for Globalmediapro HBT-332H100

  • Page 1 ALL to HDMI with HDBaset 100m Cat6 Extender Operation Manual...
  • Page 2 1.Introduction This machine is a high−performance presentation scaler and switcher. It accepts one of eight inputs: one DVI, two VGA, one composite video and four HDMI signals. The HDMI1, HDMI2 to bypass the input function, supports input resolutions up to 4Kx2K@30Hz, and HDMI3, HDMI4, DVI, VGA1, VGA2, CV scales the video, supports output resolutions up to 1920x1080P@60Hz.
  • Page 3: Package Contents

     Supports POE function  VGA video supports YPbPr and RGBHV  Picture Adjustment Settings  Supports embeds the audio  Supports S/PDIF and stereo audio outputs  Supports HDBaseT LAN Serving function  The USB and RS-232 for the firmware update ...
  • Page 4: Panel Functions

    BYPASS) Up to 1920x1080P@60Hz(SCALES) Control IR , RS-232 , TCP/TP , Buttons ESD Protection Human-body Model: ± 8kV (Air-gap discharge) ± 4kV (Contact discharge) Power Supply 12 V/2.5 A DC (US/EU standards, CE/FCC/UL certified) Dimensions 440 mm (W)×200 mm (D)×45 mm (H) Weight 2300g Chassis Material...
  • Page 5: Rear Panel

    on/off. Press this button more than 2 seconds, the device has reached the standby mode. The LED will illuminate green when the power is on, red when it is in 'Standby' mode. LOCK: Press this button to lock all the buttons on the panel, press again to unlock.
  • Page 6 Part1: OUTPUT The HDMI OUTPUT connect to HDMI equipped TVs or monitors and the HDBT OUTPUT connect to the HDBT Receiver. The coaxial and output is connected an audio stereo amplifier. The LAN is connected to PC or Router. Part2: INPUT 1) HDMI 1/ 2/ 3/ 4: Connect to HDMI sources such as DVD player /Blu-ray player for both video and audio signal conversion.
  • Page 7: Remote Control

    2) RS232(DB9): Connect to a PC or control system with D- Sub 9-pin cable for the transmission of RS-232 commands. Note: The RS-232 interface can control the machine. 3) IR IN: Connect with the supplied wideband IR RX 4) RS232(3.81mm 3P captive screw connector):Connect to a PC or control system with a D-Sub 9pin to 3P cable.
  • Page 8: Serial Control

    VGA input source. b. Scaler adjust the step: six steps. 5. Resolution select: Press these buttons to select different resolution output. 6. These buttons for function extension keys. 7. Serial Control The RS-232 port lets you send and receive simple RS-232 signals between a controller and a serial device via the switcher which is connected to the RS-232 port (3.81mm 3P captive screw connector) and outputs via CAT5e/6/7 cable.
  • Page 9 8. IR Control Operations The IR control can realize two-way control function, and the 8 IR OUT ports are corresponding to the 8video inputs one to one, and switch following the corresponding video source. The example, illustrated in Figure 3 and Figure 4 : 1) To control far-end display: The IR Receiver (Rx1) is connected to the switcher IR IN port.
  • Page 10 IR remote can be used to control this machine (switcher) or local source device from remote. Figure 4 IR Cable Pin Assignment, illustrated in Figure 5: Ver1.1 Page 10 of 21...
  • Page 11: Hdbt Receiver

    Figure 5 9. HDBT Receiver Ver1.1 Page 11 of 21...
  • Page 12 1. RS232: Phoenix jack provide Serial port control signal from transmitter or to transmitter. 2. IR IN: Chanel 2 IR Receiver. Connect with Wideband IR Rx. 3. IR OUT: Chanel 1 IR Transmitter. Connect with Wideband IR Tx. 4. HDBaseT IN: Standard HDBaseT signal input port. Connect HDBaseT transmitter with a UTP cable follows the standard of IEEE-568B.
  • Page 13: Installation

    8. HDMI OUT: HDMI output port. This slot is where you connect the HDTV or monitor with HDMI cable 9. OUTPUT LED: The output status indicating lamp. This red LED illuminate when the TV plug in with HDMI cable. 10. ETHERNET: This slot provide Internet signal from transmitter or to transmitter.
  • Page 14 1. Select RS232 COM or TCP mode 2. Select RS232 COM port 3. Click to connect or disconnect PC and Switcher 4. Select Switcher IP 5. Connect to Switcher IP 6. Search Switcher IP 7. Configure Switcher IP and MAC 8.
  • Page 15 After action of 7, edit form will pop-up as below: 1. Select auto or static IP 2. Rewrite the Switcher IP 3. Rewrite the Switcher MAC  “EDID control” page Ver1.1 Page 15 of 21...
  • Page 16 1. Select the needed EDID to input port and click set button the EDID will write to the selected HDMI input ports. 2. Copy the selected HDMI output or HDBT output EDID and click set button to write to the selected HDMI input ports. Note: 1.The HDMI1/HDMI2 support EDID management mode: The EDID mode table:...
  • Page 17: "Switch" Page

    DVI 1920X1080 EDID. What is it and what is it used for? Under normal circumstances, a source device (digital and analog) will require information about a connected device/display to assess what resolutions and features are available. The source can then cater its output to send only resolutions and features that are compatible with the attached device/display.
  • Page 18 1. Input Selection: Click these buttons to switch to the required source. 2. Resolution select: Click these buttons to select different resolution output. 3. Audio select: Click these buttons to select audio from digital (INT) or analog (EXT), when the signal is switched to the HDMI or DVI signal source.
  • Page 19 1. Click to open FW file(file extension is “.fw”) 2. Display the FW file path 3. Displaying the progress of the software upgrade 4. Click to upgrade the Switcher software 5. Display the message of the software upgrade 6. Click to upgrade the Switcher scaler software 7.
  • Page 20 1. Connect HDMI source (for example, Blu-ray player or DVD player) to the HDMI1/2/3/4 video input connector. Alternatively, you can connect the DVI connector on the DVD player to the HDMI connector on this machine (switcher) via a DVI-HDMI adapter. You can connect the audio signal via the AUDIO IN HDMI 1/2/3/4 3.81mm 3P captive screw connector, or use the embedded audio.
  • Page 21 Connect with Component Video (YPbPr) Source: Operation Examples: Via PC control software Click the VGA1 or VGA2 button switch to YPbPr or RGBHV source, and chick the YPbPr button set to YPbPr source. 5. Connect a composite video source (for example, a composite video player) to the CV IN RCA connector.
