- Page 1 LUPUS GEODOME – LE 337HD / 338HD User's Manual Version 1.0.0...
-
Page 2: Table Of Contents
Table of Contents Introduction ......................... 3 Disclaimer ........................3 Important safety advice....................3 Notes for usage and installation ................. 4 In case you encounter an error ................... 5 Designated use ......................5 1.1. Features......................5 GEODOME – LE 337HD / 338HD ..............6 2.1. -
Page 3: Introduction
Introduction Thank you for purchasing a LUPUS GEODOME® camera. Before you begin to use your camera, please carefully read the following security and installation instructions. Keep the manual in order to be able to refer to it in case of any open questions in the future. -
Page 4: Notes For Usage And Installation
Notes for usage and installation This camera is a high quality surveillance device. Please keep the following security information in mind: Do never angle the camera directly into the sun. Do never angle the camera directly into a spotlight. ... -
Page 5: In Case You Encounter An Error
1. General Introduction 1.1. Overview The LUPUS GEODOME LE 337HD and 338HD conform to the HD-CVI standard. They support long distance, high speed video signal transmission without any delay. They can be controlled by DVRs conforming to the HD-CVI standard. -
Page 6: Geodome - Le 337Hd / 338Hd
Supports high performance noise reduction. Performs excellently in low illumination. Supports ICR switch to allow surveillance by day and by night. Intelligent IR function: GEODOME – LE 337HD max. range of 20m / 22 yards GEODOME – LE 338HD max. range of 30m / 33 yards ... - Page 7 Figure 2-2 GEODOME – LE 338HD Figure 2-3 GEODOME – LE 338HD Figure 2-4 GEODOME – LE 337HD Figure 2-5 GEODOME – LE 337HD...
-
Page 8: Installation
The cameras will transmit a high definition video signal. If you bypass the standard definition/high definition switch control cable, the camera will transmit a standard definition video signal. 2.2. Installation IMPORTANT: Before you install the camera, please make sure that the surface on which you install the camera can at least support 3x the weight of the camera. - Page 9 Step 1: Take the installation position map enclosed in the accessories bag and place it on the ceiling or wall where you want to install the camera. Mind the camera’s cable exit. Drill three holes according to the positions marked in the installation map and then push the three expansion bolts from the accessories bag into these holes.
-
Page 10: Geodome - Le 337Hd
2.4. GEODOME – LE 337HD Figure 3-3 GEODOME – LE 337HD Step 1: Use the wrench to loosen the three screws from the side of the camera (Fig. 3-4). Then unscrew the pan base from the pedestal (B2 and B1 in Fig. 3-3) of the camera. Figure 3-4 GEODOME –... - Page 11 Screw the camera back onto the pedestal. Rotate the camera (B4), as well as the base (B3), to achieve the desired angle. 3. DVR settings for the LUPUS GEODOME – LE 337HD / 338HD Note: The following interface is only used as a rudimentary example. Please refer to your HD-CVI DVR manual for more detailed information.
- Page 12 Please visit our website or contact your local service engineer for more information. ® LUPUS-Electronics GmbH Otto-Hahn-Str. 12, D-76829 Landau Tel. +49 (0) 6341 93 55 3 0 Fax. +49 (0) 6341 93 55 3 20 E-Mail: info@Lupus-Electronics.de www.Lupus-Electronics.de...
