- Page 1 OPERATIONS MANUAL 5 LITER LPG GAS TANKLESS WATER HEATER C AMPER SERIES MODEL # AGL-5 DRAKKEN INDUSTRIES LLC 790 W. 20 St. Suite-103, Hialeah, FL. 33010 Toll:1-888-818-4328...
-
Page 2: Table Of Contents
Table of Contents Use and Care Introduction________________________ 1 The Purpose and Benefits of the L5_________________2 Getting Started_________________________________ 3 Installation/Use_________________________________ 4 Adjustment____________________________________ 5 Troubleshooting________________________________ 6... -
Page 3: Use And Care Introduction
1.Use & Care Manual-L5 The purpose of this manual is; to provide the installer with the basic directions and recommendations for the proper installation and adjustment of the water heater, and two, to the owner operator, to explain the features, operation, safety precautions, maintenance and troubleshooting of the water heater. -
Page 4: The Purpose And Benefits Of The L5
The unit has standard 1/2”NPT pipe fittings and an adapter for using a standard garden hose for inlet water supply. The AGL-5 is a small work horse. People around the world use similar units to heat the water in their homes, safely, and reliably. -
Page 5: Getting Started
3. Getting Started 1. Check box for damage. Damages caused in shipment must be reported immediately 2. Make sure you have all the parts: a. Heater Body b. Gas Regulator and Shower Nozzle/Hose Set... -
Page 6: Installation/Use
3. Install vent shield as shown with two Phillips screws found in the hardware package for a more permanent fixture. Or, you can simply slide it into its slots for a more temporary placement. 4. Attach a garden hose adapter to the fitting marked”Water Input”(far right1/2”connection). -
Page 7: Adjustment
Failure to properly drain your unit will cause water damage which may or may not be reparable. Please check the warranty information by contacting IHeat at 1-888-818-4328 for more information on freezing issues. -
Page 8: Troubleshooting
DO NOT RETURN TO STORE: Call IHeat directly toll free at 888-818-4328 or via email at info@drakkenusa.com you encounter a problem! 6. TROUBLE SHOOTING Unit will not start-there are no audible clicks at startup: a. The first thing to check is to ensure that the incoming water on the “right” side of the unit. - Page 9 d. One of the ignition sensors is bent and/or too close to the burner. Look to ensure that the ignition pins and the heat sensor are completely vertical and they do a 90 degree to the back of the box. If they are not straight (i.e. a 45 degree angle) then you can straighten them with pliers.
