AlcoSense ELITE Instruction Manual

Hide thumbs

Advertisement

Table of Contents

Cover
WARNING: AlcoSense Elite is a sensitive measurement device. Performing a
breath test less than 10 minutes after drinking risks blowing high levels of
alcohol directly from your mouth into the system which could permanently
damage the sensor and cause the system to read inaccurately. For best results
wait at least 30 minutes after drinking or smoking before performing a breath
test. Do not blow directly into the blow hole without a blow tube – this can
damage the sensor and significantly reduce the lifetime of your unit.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELITE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AlcoSense ELITE

Summary of Contents for AlcoSense ELITE

  • Page 1 Cover WARNING: AlcoSense Elite is a sensitive measurement device. Performing a breath test less than 10 minutes after drinking risks blowing high levels of alcohol directly from your mouth into the system which could permanently damage the sensor and cause the system to read inaccurately. For best results wait at least 30 minutes after drinking or smoking before performing a breath test.
  • Page 2 It is safest to drive when you have no alcohol left in your blood stream. As a result we only recommend driving when the AlcoSense breathalyser reads ‘LO’. Before using the AlcoSense breathalyser you agree you have read the operating instructions & are aware of the legal alcohol limit in your jurisdiction.

  • Page 3: Table Of Contents

    Introduction Quick Sensor Clean Getting Started Performing a blow test Turning On/Off Understanding the results Setting Time Maintaining your Alcosense Changing Units of Measurement Accessories Activating the Sensor Servicing Automatic Sensor Clean (ASC) Legal How to Establish if an ASC is needed 10...
  • Page 4 There are some factors that that can affect the reading of breathalysers whether it be the AlcoSense breathalyser or a police system. As long as you are aware of these factors you will be able to use your AlcoSense to give high precision readings.

  • Page 5: Getting Started

    5. How to perform a breath test and understanding the results. 6. Things that can affect the readings. Unpacking the Box In the box you will have the following components: 1) 1 x AlcoSense Breathalyser 2) This instruction manual 3) 3 x AAA Batteries 4) 5 x Blow Straws...

  • Page 6: Turning On/Off

    Turning the AlcoSense On and Off Turning On The AlcoSense can be turned on one of two ways; slide the unit open, or press and hold the + key until the screen lights up. Turning Off The unit will automatically turn itself off after a while to conserve batteries.

  • Page 7: Setting Time

    Celsius and degrees Fahrenheit in temperature. You can change the unit of measurement as follows: 1) With the AlcoSense breathalyser in the closed position hold down the MODE key until you hear a beep. Then press the mode key repeatedly until the indicator reaches the UNIT option.

  • Page 8: Activating The Sensor

    (do not press the cap in more than ½ way otherwise it may be difficult to remove it). 4) urn the AlcoSense over so that it is facing you and slide the unit open as if you were to perform a breath test. The AlcoSense will count down from PH19 to PH0 and then display “BLOW”...
  • Page 9 5) Remove the cap from the ventilation hole and replace it in the bottom right hand corner where it originally came from. 6) If the result you got was “LO” please perform an ASC (see page 10) then perform steps 1-6 again. If the result is anything other than “LO”...

  • Page 10: Automatic Sensor Clean (Asc)

    Please note: When performing an ASC you will need to do so in an environment with clean fresh air. a) Keep the AlcoSense in the closed position and press and hold down the “MODE” button until the menu selector stops rotating and you hear a beep.

  • Page 11: Quick Sensor Clean

    8 to 0 and you will hear a buzzing sound. When complete, the screen will display ‘OFF’ and the buzzing will stop. 4. To exit from this mode press the SET key once and the AlcoSense will return to the standby mode.

  • Page 12: Performing A Blow Test

    1. Slide the AlcoSense into the open position and put blow straw on the system as shown in the image below. 2. The AlcoSense will beep and PH will flash on the screen for around 3 seconds, it will then display PH19 and count down all the way to PH00.

  • Page 13: Understanding The Results

    First, check the drink drive limit in the table below and with your local road authority. The AlcoSense will display the result of your breath test on screen in either mg/l or ‰BAC depending which option you have chosen. Common...
  • Page 14 On top of the unit there is a small sticker showing the alert level. Check this then refer to the screen shots and columns below for your device. PLEASE NOTE: The below example table is in ‰BAC, not mg/l. 0.5‰BAC Alert Level Model 0.8‰BAC Alert Level Description Example of Screen...
  • Page 15 DO NOT DRIVE. There has been an error while performing the breath test. This is normally caused by either blowing too hard or too softly into the AlcoSense. See page 10, bullet point 3 or call us.

  • Page 16: Maintaining Your Alcosense

    Keep it Clean To keep your AlcoSense in tip top condition we recommend cleaning it regularly using a soft damp cloth or the AlcoSense Cleaning Kit which is available separately. We also recommend that you regularly perform an ASC (Auto Sensor Clean as explained on page 10).

  • Page 17: Accessories

    Accessories The following accessories are available for your AlcoSense unit, which are available either from your local dealer or directly from www.AlcoSense.com Accessory Description Price* Protective Carry Keep your AlcoSense £9.99 Case breathalyser safe and sound in this beautiful carry case...

  • Page 18: Servicing

    12 months. 2) Alert Level Change Should the law change we can adjust your AlcoSense unit to alert at the new drink drive limit of either 0.2, 0.5 or 0.80‰BAC and re-calibrate the unit at the same time. This service typically takes 3-5 working days to complete and is priced at £19.99 including return postage back to you.

  • Page 19: Legal

    Defect, to the address or anything else), the entire liability of Now Group UK Ltd and provided to you by AlcoSense. If a defect arises and a valid any of its suppliers shall be limited to the amount actually paid claim under this Limited Warranty is received by AlcoSense by you for the Hardware.
  • Page 20 Now Group UK Limited AlcoSense™ is a trademark of Now Group UK Ltd UK calls: 0800 195 0088 International calls: +44 1628 778885 info@alcosense.com www.alcosense.com...
