Summary of Contents for Ovation excel
- Page 1 Excel...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Package Contents Getting Started Battery Information Wearing your Ovation Excel Ear Tube and Tip QuickFit Program Selection Volume Adjustment Troubleshooting Caring for your Ovation hearing aid Warranty and Returns Technical Specifications FDA Information... - Page 4 Ovation and begin hearing sounds that you previously had been missing. We recommend that you start by only wearing your Excel unit for an hour or two a day and grad- ually extend the period of time as you get more comfortable.
- Page 5 Your Ovation Excel comes equipped with an easy to use volume control and is pre-programmed with 4 different hearing set- tings. We recommend that you start your adjustment period in relatively quiet environments, but as you get more comfortable, we encourage you to also experiment with the different hearing settings to find the best option for you in different listening environments.
-
Page 6: Package Contents
PACKAGE CONTENTS In addition to your Ovation Excel hearing device, we have included the following accessories to help you maximize your hearing experience. Ovation Excel Tubes and Tips • 1 Set Open-Fit Ear Tips • 1 Set Closed Zip Tips •... - Page 7 (after removing from device body). Protective Storage Case Your Ovation storage case is heavily padded and designed to be portable. We recommend keeping your device in the storage case or in a dry box when not in use.
-
Page 8: Getting Started
GETTING STARTED Rocker switch – the rocker switch is used to change between program settings using our exclusive QuickFit technology and is used to control the volume. Battery door – this also serves as the On/Off switch. Close the door to turn on your device. Open the door to turn off the device. - Page 9 Rocker Ear Tube Switch & Tip Battery Door Retention Loop...
-
Page 10: Battery Information
BATTERY Your Ovation Excel uses a size 10 battery. Please use high-quality batteries because they are more con- sistent in size. Lesser-quality batteries can vary in size – even by only 1 or 2 millimeters – making them unusable in your Ovation Excel. -
Page 11: Installing The Battery
INSTALLING THE BATTERY Step 1 Using your fingernail, gently pull up on the battery door tab until the door swings open. Note: Do not push against the volume button and do not open the battery door too far or damage may occur. Step 2 With the “+”... - Page 12 Step 3 With the battery installed, close the battery door to turn the device on. To turn off the device and to prevent battery use when not using the device, gently pull the battery door open. Match flat (+) side of the battery with the “+”...
-
Page 13: Wearing Your Ovation Excel
WEARING YOUR OVATION EXCEL On/Off Switch The battery door on your Ovation Excel not only allows access to the battery, but also serves as the On/Off switch. ON: Simply close the battery door. OFF: Open the battery door when you are not wearing your Ovation Excel to turn the unit off and conserve battery life. - Page 14 Next, place your Ovation Excel over the top of your ear until it rests securely behind your ear.
-
Page 15: Ear Tube And Tip
EAR TUBE & TIP Replacing ear tube & tip Your ear tube & tip will come connected. For optimal performance, replace ear tube & tip at least once every two months. Removing an ear tip Use your index finger and thumb to grip the ear tube near the tip. - Page 16 Removing the ear tube Grasp the “device end” of the ear tube; gently turn ~90 degrees and pull to remove the ear tube from the unit. Attaching the ear tube Gently push the “device end” of the ear tube onto the unit until it snaps into position.
- Page 17 Cleaning ear tube & tip Between replacements, you’ll need to clean the ear tube & tip with a cleaning wire, typically once a week. Remove the ear tube & tip from unit. Thread the cleaning wire through the ear tube, starting at the “device end,” until it comes out at the “ear tip end,”...
-
Page 18: Quickfit Program Selection
3 seconds to change the program setting. Continue pressing and releasing the rocker switch for 3 seconds each time to sample the available hearing programs. The Ovation Excel unit will beep to let you know which setting has been selected. -
Page 19: Volume Adjustment
VOLUME ADJUSTMENT The rocker switch is also used to adjust the volume within each of the QuickFit programs, enabling you to control the loudness of sounds you are hearing and giving you additional control over your listening experience. To increase volume: tap and release the upper portion of the rocker switch To decrease volume: tap and release the lower portion of the rocker switch. -
Page 20: Troubleshooting
TROUBLESHOOTING If you are having mechanical problems with your Ovation Excel, first check the following: • Battery is inserted correctly and the battery door is closed tightly. • Ear tip is clean and clear of wax and ear tube is attached proper •... -
Page 22: Caring For Your Ovation Hearing Aid
Wipe daily with a dry cloth or using the cleaning brush that was includ- ed with your Ovation to carefully remove any traces of wax and debris. Do not rinse or submerge your Ovation in water. In fact do not not use water, alcohol or any other liquid agent to clean your unit as they may damage it. - Page 23 Do not drop your Ovation Excel or bang it against hard surfaces. Always be careful when opening and closing the battery door. Do not carry the unit by the battery door, do not remove the unit by pulling on the battery door, and never pull the door back father than what is necessary to insert or remove a battery.
-
Page 24: Warranty And Returns
WARRANTY & RETURNS Warranty The Ovation Excel is covered against defects in materials and workmanship for 1 year from the time you receive your order. If after our examination it is determined that the unit failed to work due to parts, materials or workmanship we will repair or replace it for free. - Page 25 Each Ovation unit comes with a risk-free 60 day free trial. If for any reason you are not completely satisfied with your Ovation, simply return it and we will issue a full refund – no questions asked. To initiate a return, call us within 60 days of receiving your order to obtain a Return Merchandise Authorization (RMA).
-
Page 26: Technical Specifications
TECHNICAL SPECIFICATIONS Average Saturation Output: 100.4 dB HF Avg full-on gain: 50.3 dB Peak gain: 55 dB Reference test gain: 30 dB Frequency range: 200 –5500 Hz Total harmonic distortion: < 3% Equivalent input noise: < 32 dB SPL Battery current drain: .9 mA Induction coil sensitivity: n/a Attack: 6 mS Release: 30 mS... -
Page 28: Fda Information
FDA STATEMENTS Warning to hearing aid dispensers A hearing aid dispenser should advise a prospective hear- ing aid user to consult promptly with a licensed physician (preferably an ear specialist) before dispensing a hearing aid if the hearing aid dispenser determines through inquiry, actual observation, or review of any other available information concerning the prospective user, that the prospective user has any of the following conditions:... - Page 29 Special care should be exercised in selecting and fitting a hearing aid whose maximum sound pressure level exceeds 132 decibels because there may be risk of impairing the remaining hearing of the hearing aid user. (Ovation hearing aids as manufactured do not have this level of output)
- Page 30 Important Notice for Prospective Hearing Aid Users Good health practice requires that a person with a hearing loss have a medical evalu- ation by a licensed physician (preferably a physician who specializes in diseases of the ear) before purchasing a hearing aid. Licensed physicians who specialize in diseases of the ear are often referred to as otolaryngologists, otologists or otorhinolaryngologists.
- Page 31 Children with hearing loss In addition to seeing a physician for a medical evaluation, a child with a hearing loss should be directed to an audiologist for evaluation and rehabilitation since hearing loss may cause problems in language development and the educational and social growth of a child.
