TRU Audio REV6-LCR.1 User Manual

Description
This model is a High Performance 6.," Home Theater
loudspeaker designed to exclusively for in-ceiling
installations, this series also uses the· last version of the
EZFrame. The EZFramc is a TruAudio exclusive design
that will make the installation of the grill go from minutes
to seconds. The Revolve LCRs can be used for the center
channel , right or left channels or for all front three
channels (LCR). They are acoustically matched with the
REV6- SUR. l models to act as the perfect in-ceiling
Home Theater speaker system. All the Revolve series
speakers are also matched with many of TruAudio
architectural and freestanding speakers so it's easy to
design a custom home theater to fit any room. Multiple
pairs of the SUR.1 models mar be needed for 7.1 and 9.1
systems.
The LCR models feature a full range design so it can also
be used for the from two channels for audio listening
When using these models for Horne Theater, we
recommend completing the system with any TruAudio
subwoofers.
Choosing the Speaker Location
The Revolve series do NOT fit in the typical 2x4 wall
depth of 3.5". Because they were designed exclusively for
ceiling use and most ceiling depth is usually 8", these
models require 5.5" mounting depth. Please keep this in
mind while deciding on the final installation location of the
speakers.
The biggest determination of any speaker's sound quality,
is the room and the location of the speaker in that room.
Since you have chosen these models, the installation
requires you to mount one or more of the REV speakers
in the ceiling. The unique baffle and tweeter bridge allows
the frequencies to radiate toward the listening area and
down, away from the ceiling. With the woofer mounted at
the designed angle, even the lower
frequencies will be more pronounce and less forgotten
User Manual - 6-inch Revolve Series & Ghost HT In-Cieling
REV6-LCR.1 REV6-LCR.2 REV6P-LCR.1 REV6P-LCR.2
like most in~ceiling home theater speakers. The movable
tweeter bridge makes it easy to adjust the high
frequencies to the perfect degree once the speaker and
furniture are in their final location.
Today's home theater systems require 6 or more
speakers for true, life like home cinema listening. These
speakers are front right and left, the center channel. right
and left surround , and a subwoofer.
Some systems also require additional surround speakers
or rear centers to enhance the theater sound. The
placement for these speakers is critical to having your
home theater experience the best it can be.
LCR Location:
installed directly above the video picture or screen. The
front right and left speakers should be mounted to both
sides of the center channel. Try to keep these all aligned
if possible. At least make sure the front left and right
speakers arc aligned the same. While installing these
speakers. note the angle of the woofer. T he woofer
should be facing the listening area. If necessary, turn the
entire speaker frame to face the woofer angle properly.
Adjust the tweeter bridge so that high frequencies are
also directed toward the listening area. On
Model LCR.1, the tweeter adjusts separately from the
midrange to give added flexibility.
Surround location:
which means the tweeters are aimed and fire away from
the listener. This causes a more "surround" effect. This
actual model is deigned to be mounted into the ceiling.
The typical installation would put these speakers directly
above the listeners about 6-8 feet apart.
installations could put these speakers in from or in back of
the listener. In any of these cases, the tweeters should be
facing away from the listener meaning one tweeter facing
the front wall and the other face the rear of the room. The
woofer can be directed toward the listener or toward the
wall. This would depend on the installation and the
REV6P-SUR.1 REV6-SUR.1
The front center speaker should be
The SUR.1 is a bi-pole speaker
GHT-CSUR
Other
