FM/MW/LW
Compact Disc Player
Operating Instructions
For installation and connections, see the supplied installation/connections manual.
CDX-M630
© 2002 Sony Corporation
3-242-546-31 (1)
GB
CT

Advertisement

Table of Contents
loading

Related Manuals for Sony CDX-M630

Summary of Contents for Sony CDX-M630

  • Page 1 3-242-546-31 (1) FM/MW/LW Compact Disc Player Operating Instructions For installation and connections, see the supplied installation/connections manual. CDX-M630 © 2002 Sony Corporation...

  • Page 2: Card Remote Commander Rm-X117

    Card remote commander RM-X117 • Optional controller accessory Wired rotary commander RM-X4S *1 This unit works with Sony products only. *2 A CD TEXT disc is an audio CD that includes information such as the disc name, artist name, and track names. This information is recorded on...

  • Page 3: Table Of Contents

    Table of Contents Location of controls....4 Precautions ......6 Overview of RDS .

  • Page 4: Location Of Controls

    To select the source. f SEEK (</,) buttons *1 When an optional MD unit is connected. *2 Available only when an optional Sony portable To skip tracks/fast-forward, reverse a track/ device is connected to BUS AUDIO IN of the unit.

  • Page 5: Programme Type) Button

    Main display side Operation side CDX-M630 l LIST button The buttons on the unit share the same n TA button 17 functions as those on the card remote commander. o CLOSE (front panel close) button p SOURCE button a OPEN button 8, 26...

  • Page 6: Precautions

    If you have any questions or problems concerning your unit that are not covered in this manual, please consult your nearest Sony dealer. Moisture condensation On a rainy day or in a very damp area, moisture condensation may occur inside the lenses and display of the unit.

  • Page 7: Notes On Discs

    • Before playing, clean the discs with a Notes on discs commercially available cleaning cloth. Wipe each disc from the centre out. Do not use solvents such as benzine, thinner, commercially • To keep the disc clean, do not touch the surface. available cleaners, or antistatic spray intended Handle the disc by its edge.

  • Page 8: Getting Started

    Setting the clock Getting Started The clock uses a 24-hour digital indication. Example: To set the clock to 10:08 Resetting the unit Press (MENU), then press M or m repeatedly until “Clock” appears. Before operating the unit for the first time, or after replacing the car battery or changing the connections, you must reset the unit.

  • Page 9: Cd Player Cd/Md Unit (Optional)

    • With an optional unit connected, playback of the same source will continue on to the optional CD/MD CD Player unit. CD/MD Unit (optional) (With optional unit) Press (SOURCE) repeatedly to select In addition to playing a CD with this unit, you “CD”...

  • Page 10: Display Items

    Display items When A.Scrl (Auto Scroll) is set to off, and the disc/ track/album is changed, the disc/track/album name or ID3 tag does not scroll. When the disc/album/track changes, any prerecorded title* of the new disc/album/track is automatically displayed (if the Auto Scroll function is set to “on,”...

  • Page 11: Playing Tracks Repeatedly

    Playing tracks repeatedly Playing tracks in random order — Repeat Play The disc in the main unit will repeat a track, the — Shuffle Play entire album, or the entire disc when it reaches You can select: the end. For repeat play, you can select: •...

  • Page 12: Labelling A Cd

    Tips Labelling a CD • Simply overwrite or enter “ ” to correct or erase a name. • There is another way to start labelling a CD: Press — Disc Memo (For a CD unit with the (LIST) for 2 seconds instead of performing steps 2 CUSTOM FILE function) and 3.

  • Page 13: Locating A Disc By Name

    Locating a disc by name Radio — List-up (For a CD unit with the CD TEXT/ CUSTOM FILE function, or an MD unit) The unit can store up to 6 stations per band (FM1, FM2, FM3, MW, and LW). You can use this function for discs that have been assigned custom names* or for CD TEXT Caution...

  • Page 14: Receiving The Stored Stations

    Receiving the stored stations Storing only the desired stations Press (SOURCE) repeatedly to select “TUNER.” You can manually preset the desired stations on Press (MODE) repeatedly to select the any chosen number button. band. Press (SOURCE) repeatedly to select Press the number button ((1) to (6)) “TUNER.”...

  • Page 15: Tuning In A Station Through A List

    Tuning in a station through a list — List-up Overview of RDS During radio reception, press (LIST) momentarily. FM stations with Radio Data System (RDS) The frequency or the name assigned to the service send inaudible digital information along current station appears in the display. with the regular radio programme signal.

  • Page 16: Automatic Retuning For Best Reception Results

    For stations without alternative Automatic retuning for best frequencies reception results Press (SEEK) (<) or (SEEK) (,) while the station name is flashing — AF function (within 8 seconds). The unit starts searching for another The alternative frequencies (AF) function allows frequency with the same PI (Programme the radio to always tune into the area’s strongest Identification) data (“PI Seek”...

  • Page 17: Receiving Traffic Announcements

    Receiving traffic Presetting RDS stations with announcements AF and TA setting — TA/TP When you preset RDS stations, the unit stores each station’s AF/TA setting (on/off) as well as By activating the Traffic Announcement (TA) its frequency. You can select a different setting and Traffic Programme (TP), you can (for AF, TA, or both) for individual preset automatically tune in an FM station broadcasting...

  • Page 18: Tuning In Stations By Programme Type

    Press (DSPL) during FM reception Tuning in stations by until “PTY” appears. programme type — PTY You can tune in a station by selecting the type of The current programme type name appears if programme you would like to listen to. the station is transmitting the PTY data.

  • Page 19: Setting The Clock Automatically

    Setting the clock Other Functions automatically You can also control the unit (and optional CD/ — CT MD units) with a rotary commander (optional). The CT (Clock Time) data from the RDS transmission sets the clock automatically. Using the rotary commander During radio reception, press (MENU), then press M or m repeatedly until “CT off”...
  • Page 20 – Change albums. *1 Only if the corresponding optional equipment is connected. *2 Available only when an optional Sony portable device is connected to BUS AUDIO IN of the unit. You cannot connect any optional CD/MD units at the same time.

  • Page 21: Adjusting The Sound Characteristics

    Adjusting the sound Quickly attenuating the characteristics sound (With the rotary commander or the card You can adjust the bass, treble, balance, fader, remote commander) and subwoofer volume. Press (ATT). Press (SOUND) repeatedly to select “ATT on” appears in the display momentarily. the desired item.

  • Page 22: Changing The Sound And Display Settings

    Sound Changing the sound and • HPF (High pass filter) – to select the cut-off frequency to “78 Hz,” display settings “125 Hz,” or “off.” • LPF (Low pass filter) — Menu – to select the cut-off frequency to “78 Hz,” “125 Hz,”...

  • Page 23: Setting The Equalizer (Eq7)

    Adjusting the equalizer curve Setting the equalizer (EQ7) Press (MENU). You can select an equalizer curve for 7 music Press M or m repeatedly until “EQ7 types (Xplod, Vocal, Club, Jazz, New Age, Rock, Tune” appears, then press (ENTER). Custom), and off (equalizer off). Press <...

  • Page 24: Setting The Dynamic Soundstage Organizer

    Setting the Dynamic Selecting the spectrum Soundstage Organizer (DSO) analyzer (SA) If your speakers are installed into the lower part The sound signal level is displayed on a spectrum of the doors, the sound will come from below analyzer. You can select a display for 9 patterns and may not be clear.

  • Page 25: Connecting Auxiliary Audio Equipment

    Note original fuse. If the fuse blows, check the power If you connect an optional Sony CD/MD unit, you connection and replace the fuse. If the fuse blows cannot connect any portable devices and “AUX” will again after replacement, there may be an internal not appear in the display as a source.

  • Page 26: Removing The Unit

    Replacing the lithium battery Removing the unit Under normal conditions, batteries will last approximately 1 year. (The service life may be shorter, depending on the conditions of use.) With the front panel open When the battery becomes weak, the range of the card remote commander becomes shorter.
  • Page 27 If the front panel does not open because of a blown fuse Remove the front cover 1 Press the clip inside the front cover with a release key (supplied), and pry the front cover free. Release key (supplied) Note To protect the surface of the unit, put thin cloth between release key and the unit by inserting the release key.

  • Page 28: Specifications

    Specifications General CD Player section Outputs Audio outputs (front/rear) Signal-to-noise ratio 90 dB Subwoofer output (mono) Frequency response 10 – 20,000 Hz Power aerial relay control Wow and flutter Below measurable limit terminal Power amplifier control Tuner section terminal Inputs Telephone ATT control terminal Tuning range...

  • Page 29: Troubleshooting

    Playback does not begin. Troubleshooting • Defective MD or dirty CD. • CD-R/CD-RW that is not finalized. • You tried to playback a CD-R/CD-RW not The following checklist will help you remedy designed for audio use. problems you may encounter with your unit. •...

  • Page 30: Error Displays/Messages

    A programme broadcast in stereo is heard Error displays/Messages in monaural. • The unit is in monaural reception mode. t Cancel monaural reception mode (page Error displays 22). (For this unit and optional CD/MD changers) The following indications will flash for about 5 seconds, and an alarm sound will be heard.
  • Page 31 If these solutions do not help improve the situation, consult your nearest Sony dealer. Messages LCL Seek +/– The Local Seek mode is on during automatic tuning (page 14). NO AF There is no alternative frequency for the current station.
  • Page 32 • • • •...
  • Page 33 CD n CD/MD  ’ “...
  • Page 34 (DISC) OPEN/CLOSE DSPL SHUF DISC (SEEK) (SEEK) (,“ <“ SOURCE – SEEK SEEK MODE – DISC (DISC) ’m): DISC SOURCE – SEEK SEEK – DISC ¡ (OFF) (SOURCE) " < ,...
  • Page 35 CDX-M630 c qa d qd .m M>...
  • Page 36 7 X|  (OFF) X S   • •...
  • Page 37 • • • • • • • • • •...
  • Page 38 (MENU) RESET X (ENTER) (ENTER) RESET X • • ¡ • (OPEN) •...
  • Page 39 CD n (SOURCE) CD/MD  ’ “ (MODE) (DISC) M m ¡ (DISC) MGS-X1 @ MD  ¡ (SOURCE) • (OPEN/CLOSE) (OPEN) (MODE) • (SOURCE) (MODE) n MP3  ¡ (OPEN/CLOSE) (CLOSE) (SOURCE) (OFF) (OPEN/CLOSE) (OPEN) (SEEK) < , (SEEK) <...
  • Page 40 • • • " • • • • • •  n • • (DSPL) (SCRL) (DSPL) ( DSPL) ¡ • • •...
  • Page 41 • • • • (MENU) (ENTER) ¡ C ... 2 ... < (ENTER)
  • Page 42 • • (LIST) (LIST) • ¡ (LIST) (DSPL) (ENTER) ¡ (SOURCE) (MODE) (MENU) (ENTER) (ENTER) (MENU) ¡ • • •...
  • Page 43 (SOURCE) (MODE) (1) (6) (SEEK) (SEEK) < • (SOURCE) (MODE) • < (MENU) < (ENTER) ¡ • •...
  • Page 44 (LIST) (SOURCE) (MODE) (SEEK) < (SEEK) , ¡ (ENTER)
  • Page 45 î n  96.0 MHz 98.5 MHz • • 102.5 MHz (MENU) • • (ENTER) (DSPL) ¡ • • • • ¡ • •...
  • Page 46 (SEEK) (TA) ¡ (TA) (SOURCE) (MODE) (1) (6) (VOL) (VOL) (TA)
  • Page 47 (TA) (MENU) (ENTER) (TA) ¡...
  • Page 48 (DSPL) (MENU) -------- -------- (ENTER) (ENTER) ¡ • •...
  • Page 49 SEEK/AMS ¾ ž e ¾ ž D S P L S O U N D M O D E M O D E S O U N D D S P L PRESET/DISC (ATT) (SOUND) ž (MODE) ‚ " ž (SOURCE) ž...
  • Page 50 (SOUND) (SOUND) BAS ’ “ t TRE ’ “ t BAL ’ “ t < (SOUND) ¡ (SOUND)
  • Page 51 (ATT) • (ATT) • • • • • • • • • • •...
  • Page 52 • • • • (SOURCE) (EQ7) • • (EQ7) • • (MENU) (OFF) (MENU) (ENTER) ¡...
  • Page 53 (MENU) (ENTER) < (ENTER) < < (SOURCE) < (DSO) 62 Hz y 157 Hz y 396 Hz y 1.0 kHz y 2.5 kHz y 6.3 kHz y 16 kHz ¡ • • (ENTER) (ENTER)
  • Page 54 (SOURCE) ¡ (MENU) (SOURCE) < (ENTER) (MENU) (ENTER) (ENTER) (OFF) (MENU)         (MENU)
  • Page 55 • &  (10 A) • • • •...
  • Page 56 (OPEN/CLOSE) (OPEN)  9 ’ “ ¡...
  • Page 57 ¡...
  • Page 58 • ° • (VOL) • -------- • • (LIST) • • • • • • (OFF) • (OFF) • • • • • • • • • (SOURCE) • • • • • • • •...
  • Page 59 • (TA) • • • • -------- • • •...
  • Page 60 Sony Corporation Printed in Korea...
