Volt Ac Circuit Breakers; Power Distribution Panel - Leisure Unity Owner's Manual

Electrical System Operation
ower istribution anel
The power distribution panel (1), located in
a lower ca inet ascia, contains the 120 volt
reakers or the C inco ing power and 12 volt
uses 2 or the coach C attery power
The le t side o the reaker panel
120 volt C reakers Re er to the circuit
breaker panel decal to identify the function of
each reaker The right side 3 houses 12 volt
DC fuses. Refer to the circuit fuse panel decal
to identify the function of each fuse.

120 Volt AC Circuit Breakers

The circuit reaker panel protects all 120 volt C
equipment and components in the motorhome
from overload, a short in the wiring, or a short
in the component itself. In the event of an
overload, the circuit reaker cuts o the ow
of electricity in the system and helps prevent
da age or fire
a circuit reaker trips, allow a rie cool
down period o 30 90 seconds, then reset the
reaker y turning it
a circuit reaker trips repeatedly, the circuit
is overloaded or there may be a short in the
wiring or in the equipment, and both should
e checked and serviced y ualified service
personnel. Refer to the converter and control
panel manuals in the Motorhome Information
Kit for further details.
O here is a single 3 amp main brea er
which protects the entire AC electrical
s stem. Chec the main brea er if the entire
electrical system will not function on shore
power or generator (if equipped).
