SunEyes V Series User Manual

Hide thumbs Also See for V Series:
Table of Contents

Advertisement

Quick Links

S
u
n
E
y
e
s
V
S
e
r
i
e
s
I
P
C
a
m
e
r
a
U
s
e
r
M
a
n
u
a
l
S
u
n
E
y
e
s
V
S
e
r
i
e
s
I
P
C
a
m
e
r
a
U
s
e
r
M
a
n
u
a
l
Version：V4.4
Applicable equipment version：V6.9.8.1.1-20141113 and later
This documents can be used for 1080P IR PTZ IP Camera.
Page
on Page 41
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SunEyes V Series

Summary of Contents for SunEyes V Series

  • Page 1 Version：V4.4 Applicable equipment version：V6.9.8.1.1-20141113 and later This documents can be used for 1080P IR PTZ IP Camera. Page on Page 41...
  • Page 2 SunEyes V Series IP Camera Quick Installation User Manual This manual may exist in some technical details description inaccurate or printing errors, if you cannot solve the problem as this manual when using,pls contact our technical department to inquire relevant operation method. The contents of this manual will update at any time, without prior notice.

  • Page 3: Table Of Contents

    SunEyes V Series IP Camera Quick Installation User Manual Content Product introduction ........................ 5 Equipment installation......................6 Operating environment ................... 6 Equipment installation ..................... 6 Network setting ........................6 Use installation guide to configurate IP Camera ............. 6 access to ip camera ....................8 Configurating manufacturer’s DDNS to access the camera .........
  • Page 4 SunEyes V Series IP Camera Quick Installation User Manual Advance setting ...................... 33 4.5.1 User management ..................33 4.5.2 Timing capture ....................33 4.5.3 Timing record....................34 4.5.4 Email ....................... 34 4.5.5 FTP setting ...................... 35 4.5.6 PTZ setting ...................... 35 System setting ......................

  • Page 5: Product Introduction

    SunEyes V Series IP Camera Quick Installation User Manual 1 Product introduction IP Camera is a product based on embedded web server. It has multi-function image effect. It is an indepent installation monotoring system, built-in CPU and web serrver, transmit high quality image through internet.

  • Page 6: Equipment Installation

    SunEyes V Series IP Camera Quick Installation User Manual 2 Equipment installation 2.1 Operating environment Operating system: Windows 2000/2003/XP/vista/7 Network protocal: TCP/IP PC Client: P4/128M RAM/40GHD/ video card support convergent divergent, Dirict X8.0 or above Equipment installation 1. Connect the IP Camera into your network or use crossed net cable connected to PC directly 2.
  • Page 7 SunEyes V Series IP Camera Quick Installation User Manual PC that can access to the Camera. Upon IP Camera started, find “search tool”from CD and install, after finished, click shortcut “search tool”on destop, as shown in below: Click “Next”, popup below image: select the device, then click “Next”, see below interface:...

  • Page 8: Access To Ip Camera

    SunEyes V Series IP Camera Quick Installation User Manual Set up parameter, then click “Next”,after see below image, click “finish”to exit installation guide. 3.2 access to ip camera 1） Please enter into http://192.168.1.88 on IE, then type in user name: admin, password:...
  • Page 9 SunEyes V Series IP Camera Quick Installation User Manual 2） click “confirm”, then you can see below: 3)click “PC view”, as shown below: Page on Page 41...

  • Page 10: Configurating Manufacturer's Ddns To Access The Camera

    SunEyes V Series IP Camera Quick Installation User Manual 4)click “download Active X”, popup below image, then click “run”(please don’t use “thunder”, using IE browswer) 5） After Active X installation finished, click “real-time view”, then you can see below interface: 3.3 Configurating manufacturer’s DDNS to access the camera...

  • Page 11: Ddns

    SunEyes V Series IP Camera Quick Installation User Manual Operation Steps: After login the interface of the router，choose “Port Forwarding”; Choose “Add custom Service” ; Input IP camera port; Input IP camera IP address， click “Apply” （ the http port and ip address should be the same as figure 4 which set by you own).

  • Page 12: Manufacturers Domain Name Visit

    SunEyes V Series IP Camera Quick Installation User Manual address. Note: dynamic domain name by manufacturer manufacturer provides the user name and password Third Part Domain Name: User can also use third part DDNS, such as www.dyndns.com User must apply a free domain name from this website and fill the info into the below blanks (Figure 12) and save the settings.

  • Page 13: Third Party Dynamic Domain Name Visit

    SunEyes V Series IP Camera Quick Installation User Manual 3.3.4 Third party dynamic domain name visit the product also can support third party ddns, such as oray Note:the third party ddns realizes the function by analytical methods,after inputting the ddns in browser,the characers would not change,if the port is not 80,need to add a colon and port behind the ddns such as：http://demo.dyndns.org:1024...
  • Page 14 SunEyes V Series IP Camera Quick Installation User Manual Note: if the router to wireless set not set password, it does not need to enter the password and click "check" Pop-up is shown below, says WIFI is set correctly, click on the "application" save Settings, if tip connection, please enter a password, and then click on the "check"...

  • Page 15: Vlc Streaming Media Player Monitoring

    SunEyes V Series IP Camera Quick Installation User Manual 3.7 VLC Streaming media player monitoring This camera supports RTSP streaming, here you can view the camera using VLC player. For example: IP: 192.168.1.88 RTSP Port number: 554 Here I can enter one of the following URLs in the VLC.
  • Page 16 SunEyes V Series IP Camera Quick Installation User Manual Note: RTSP using TCP connection need to type in “ :rtsp-tcp ”(do not include “”) in editing options. UDP： 1.Open VLC Player, click “media”--- “open newtork streaming”, or press combination key “Ctrl+N”, as shown in below: 2.Inputting URL Address: RTSP://IP:port/11(first stream)
  • Page 17 SunEyes V Series IP Camera Quick Installation User Manual RTSP://IP:port/12(second stream), RTSP://IP:port/12(third stream) (the port is RTSP Port, default is 554, can be omitted) If you need RTSP monitoring by public network, you should mapping below ports: RTSP port RTSP port...

  • Page 18: Function Setting

    SunEyes V Series IP Camera Quick Installation User Manual 4 Function setting 4.1 Monitor 4.1.1 Main Menu All page includes two types of menu bar: including real-time monitoring and parameter setting; real-time monitoring is to display camera images and related opertions function keys;...

  • Page 19: Monitoring

    SunEyes V Series IP Camera Quick Installation User Manual 3） :Audio sending button: It can send voice to the device that captured by computer, click again, the function will be shut down. 4） File saving location setting:you may set the location for recording and capturing,the default location is D:/record 4.1.3 Monitoring...

  • Page 20: Playback

    SunEyes V Series IP Camera Quick Installation User Manual Click record button again, it stops recording. 4.1.8 Playback Click playback button, Will pop up a player, as shown, can play recorded on the local hard disk and SD card video.

  • Page 21: Audio/Video Setting

    SunEyes V Series IP Camera Quick Installation User Manual 4.2 Audio/Video setting 4.2.1 Image setting 1） Color adjustment Drag the slider above, you can adjust brightness, saturation, contrast, sharpness, exposure, then meet each user’s visual preferance. 2） Flip and mirror image It can adjust pictures flip up and down &...

  • Page 22: Video Setting

    SunEyes V Series IP Camera Quick Installation User Manual 4.2.2 Video setting 1） Video coding setting: mainprofile and baseline adjustable, default is mainprofile 2） stream definition adjustment The equipment support first stream: 720P(1280*720) and Q720P(640*352), second stream: Q720P(640*352), QQ720P(320*176); third stream: QQ720P(320*176); the greater the resolution, image is more clearer, but also greater stream, and greater network bandwidth.
  • Page 23 SunEyes V Series IP Camera Quick Installation User Manual stream configuration should be combined with network bandwidth, when network bandwidth is narrow, and configurating greater stream, it may cause the video stream can not transmit normally, visual effect is very bad.

  • Page 24: Audio Setting

    SunEyes V Series IP Camera Quick Installation User Manual 4.2.3 Audio setting 1） Collecting audio: choose “open” means add audio singal when coding, choose “close” means do not add audio singal when coding. You can choose whether open audio collection for first stream, second stream and third stream separately.

  • Page 25: Network Setting

    SunEyes V Series IP Camera Quick Installation User Manual 4.3 Network setting 4.3.1 Network parameter setting 1） LAN setting The IP Address of factory default is 192.168.1.88; Users can run “IP Camera rapid installation guide” to configurate network parameter. 2） Http port...

  • Page 26: Wireless Setting

    SunEyes V Series IP Camera Quick Installation User Manual When using RTSP Connection, if choose open, you need to input login user name and password; if choose close, you don’t need to input camera’s user name and password, then can enter into camera.

  • Page 27: Remote Access Setting

    SunEyes V Series IP Camera Quick Installation User Manual 4.3.3 remote access setting 5） Show Internet IP address Click the “Show” button as above Figure , it will show you another new page displaying the WAN IP address when it is connected to the Internet.

  • Page 28: Platform Setting

    SunEyes V Series IP Camera Quick Installation User Manual Note: users in the use of the function, need to confirm a router also is enabled UPNP; Because many router model, not necessarily can very good support UPNP, testing and supporting the router is very good with, or suggest not start the function. At present test and TP-LINK router cooperate good.

  • Page 29: Onvif Setting

    SunEyes V Series IP Camera Quick Installation User Manual 4.3.5 ONVIF setting ONVIF switch: default is open Port: default is 8080 Permission: default is not verify (It depends on back end equipment. Mainly considering some back end equipments do not support permission verify)

  • Page 30: Alarm Setting

    SunEyes V Series IP Camera Quick Installation User Manual It can obtain P2P platform related parameters: server address, server port and equipment serial number (Note: The serial number of each equipment is unique, can not repeated ) 4.4 Alarm setting 4.4.1 External alarm...

  • Page 31: Motion Detection

    SunEyes V Series IP Camera Quick Installation User Manual 4.4.2 Motion detection If you want to monitor a zone fixed, when the zone has exception, it enables alarm, you can choose motion detection function. Settings like below. The equipment can support 4 zones setting, you can enable it through tick the option box at the bottom of page.

  • Page 32: Alarm Time

    SunEyes V Series IP Camera Quick Installation User Manual  relay output  capture a picture, then save to TF Card  Recording a video for 15 seconds, then save to TF card (including 1-3 seconds warning before video) ...

  • Page 33: Advance Setting

    SunEyes V Series IP Camera Quick Installation User Manual 4.5 Advance setting 4.5.1 User management The system set 3 levels user permission, user name: admin/user/guest. Admin has highest authority, can do any setting. User can only operate PTZ, browse video, PC Client recording and image capture, etc, but can not do setting.

  • Page 34: Timing Record

    SunEyes V Series IP Camera Quick Installation User Manual 4.5.3 Timing record Video file duration: can set video file duration, default is 600 seconds. Open video: can choose whether open video to TF Card Stream: can set recording stream recording time: set timing recording time as required 4.5.4 Email...

  • Page 35: Ftp Setting

    SunEyes V Series IP Camera Quick Installation User Manual testing, it will reminder testing successfully when finished. Note: 1. The server of sending email should support POP3 protocal. In order to strengthen security and reduce spam, Many mail server closed this protocal at present.

  • Page 36: System Setting

    SunEyes V Series IP Camera Quick Installation User Manual Cruise laps: can set the cruise laps, default is 1 PTZ Speed: fast, medium, slow adjustable, default is fast self-checking centered: when power on, it is self-checking, after completed, PTZ will in center;...

  • Page 37: Initial Setting

    SunEyes V Series IP Camera Quick Installation User Manual 4.6.2 Initial setting  click restart button, the device will restart. If setted preset, PTZ will rotate to preset position.  click factory default, all settings will recover to factory default setting , and restart ...

  • Page 38: Equipment Information

    SunEyes V Series IP Camera Quick Installation User Manual 4.6.3 Equipment information  If using wired connection, the network connection statu is wired connection; if using wireless connection, the network connection statu will show wireless connection.  If you have inserted TF Card, TF status bar will have prompt, and indicates how many space left.

  • Page 39: Faq

    SunEyes V Series IP Camera Quick Installation User Manual 5 FAQ  How to do if forgot login password? Solution: There is a “RESET” button in the back panel of IP Camera or connection wire, in the condition of power on, please press this button for more than 5 seconds, then all parameters recover to default value (factory default).
  • Page 40 SunEyes V Series IP Camera Quick Installation User Manual Possible reason 1: disconnect audio input Solution: Please check the audio connection. Possible reason 2: The audio option do not enable on IP Camera. Solution: Please check audio parameter of IP Camera, enabled monitoring function.
  • Page 41 SunEyes V Series IP Camera Quick Installation User Manual Thank you for using the IP Camera.Because of different model or system software upgrade, there maybe a little difference in apperance and function with this manual, please feel free to contact us. Sorry for the inconvenience of not informing you these changes in time.
