- Page 1 CD+G/MP3+G Karaoke System INSTRUCTION MANUAL KS800 Thank you for purchasing this Karaoke System. Please read this instruction manual carefully before using this product to ensure proper use. Keep this manual in a safe place for future reference.
-
Page 2: What's In The Box
WHAT’S IN THE BOX Contents 1. KS800 Karaoke System 2. AV Cable 3. Pre-recorded Karaoke CD+G Disc 4. Dynamic Microphone 5. AC-DC Power Adaptor 6. Instruction Manual 7. Warranty Card If you are missing any parts above, please contact ADT Digital LLC. - Page 3 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
- Page 4 FCC AND CANADIAN ICES NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence in a residential installation.
- Page 5 WARNINGS: • To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Avertissement: pour réduire le risque d’incendie ou de choc électrique, ne pas exposer cet appareil sous la pluie et l’humidité. •...
-
Page 6: Control Location
CONTROL LOCATION FRONT SIDE RIGHT SIDE SPEAKER LEFT SIDE SPEAKER TFT SCREEN CD DOOR OPEN AREA CD DOOR CONTROL PANEL SKIP BUTTONS MODE / STOP BUTTON PLAY / PAUSE BUTTON PROGRAM/REPEAT BUTTON MIC VOLUME BALANCE CONTROL ECHO CONTROL MASTER VOLUME CONTROL POWER ON INDICATOR USB SOCKET ON / OFF BUTTON... - Page 7 TFT DISPLAY ICON TRK 8/8 00:16:04 PLAYING TIME REPEAT MODE REPEAT ONE REPEAT ALL REPEAT FOLDER NO REPEAT PROGRAM MODE PROGRAM MODE PLAYING NO PROGRAM MODE PLAY PLAY / PAUSE / STOP INDICATOR PLAYING MODE PAUSE MODE STOP MODE PLAYING TRACK NUMBER AND TOTAL TRACK NUMBER PLAYING DISC MODE CD DISC PLAYING CDG=...
-
Page 8: Making The Connections
MAKING THE CONNECTIONS CONNECTING POWER Plug the supplied power adapter small end into the DC jack located on the rear panel, plug the adapter into the standard AC wall socket. CAUTION: The unit is designed to operate from a mains supply of AC 120V~60Hz. If the adapter does not fit properly, turn it over and again. -
Page 9: Audio Connection
MAKING THE CONNECTIONS (Cont’d) SELECTING YOUR KARAOKE MACHINE AS YOUR SOURCE/INPUT Selecting your Karaoke Machine as a source / input on your TV is very similar to connecting a VCR/DVD or Satellite system. We’ve listed below the most common ways of selecting the source from your TV or VCR / Home Theater: 1. - Page 10 MAKING THE CONNECTIONS (Cont’d) Line-out connection Except the RCA connection, there is another audio line-out with 3.5mm jack on the unit. User can use a 3.5mm to RCA cable (not included) to connect the audio signal from the unit to your TV/ Home theater and other stereo audio system.
-
Page 11: Turning Power On/Off
MAKING THE CONNECTIONS (Cont’d) SETTING UP YOUR MICROPHONE 1. Plug a microphone into the MIC1 or MIC2 jack at the rear of your Karaoke Machine. Their output is mixed with playback from CD/CD+G. 2. Located on the microphone, there is an ON/OFF switch. 3. - Page 12 CD OR CD+G / MP3+G OPERATION (Cont’d) PLAY/PAUSE 1. To start playing, press the PLAY/PAUSE button once, the currently track number and PLAY indicator will appear on the screen. (If a CD+G is loaded, the CDG will be shown on the screen.
- Page 13 CD OR CD+G / MP3+G OPERATION (Cont’d) REPEAT PLAY (For both CD and CD+G/MP3+G discs) 1. During playback, press PROGRAM/REPEAT button once, the REP ONE indicator will appear on the TFT screen, it can keep repeat the current track. 2. To repeat the Directory/Folder, press PROGRAM/REPEAT button twice, the REP FOLDER indicator will appear on the TFT screen.
- Page 14 CD OR CD+G / MP3+G OPERATION (Cont’d) BALANCE Adjust the BALANCE control between the pre-recorded singer’s voice and the music when using a multiplex karaoke disc. AUTO VOICE CONTROL AUTO VOICE CONTROL can be activated and adjusted by the AVC control knob. The vocals on the Multiplex recording will be muted when the singer starts to sing through the microphone.
-
Page 15: Usb Operation
USB OPERATION INSERTING USB FLASH DRIVE 1. Insert a USB flash driver into the USB socket on the front of your karaoke system. 2. Make sure that USB is selected as the audio source. See "SELECTING THE AUDIO SOURCE” 3. Press PLAY/PAUSE to start playback. PLAY/PAUSE 1. -
Page 16: Repeat Play
USB OPERATION (Cont’d) REPEAT PLAY 1. During playback, press PROGRAM/REPEAT button once,the REP ONE indicator will appear on the TFT screen, it can keep repeat the current track. 2. To repeat the Directory/Folder, press PROGRAM/REPEAT button twice, the REP FOLDER indicator will appear on the TFT screen. 3. -
Page 17: Care And Maintenance
CARE AND MAINTENANCE Cleaning Disc POWER SWITCH Cleaning will not normally be necessary. After use, turn off the power by pressing the However, should fingerprints, dust or dirt appear, POWER ON/OFF button. you can wipe them off with a soft, lint-free cloth. CLEANING THE UNIT Wipe the disc in a straight line from center to edge. - Page 18 TROUBLE SHOOTING (Cont’d) PROBLEM POSSIBLE CAUSE SOLUTION No power when POWER AC adaptor is not plugged into a Plug the AC adaptor into a wall is on. wall outlet or the connector is not outlet and plug the connector into plugged into the power supply jack the supply jack on the unit.
- Page 19 TROUBLE SHOOTING (Cont’d) PROBLEM POSSIBLE CAUSE SOLUTION No sound - when audio • Source Selection on your stereo • Select AUX IN as the source for is connected to a home is not set properly your home stereo stereo. • Improper Connection to stereo •...
-
Page 20: Specification
SPECIFICATION Audio Section Output power 5 watt + 5 watt RMS Output impedance 8 Ohms CD OR CD+G player Frequency response 100 Hz - 20 kHz Signal - to - noise ratio 50 dB Number of programs 20 STEPS RANDOM ACCESS PROGRAMMING Microphone -73 dB 600 OHMS IMPEDANCE WITH Ø... - Page 21 THE KARAOKE MACHINE (GLOSSARY OF TERMS) Following are some brief descriptions of karaoke terms you may need: Echo: By adding some minor feedback to your voice the Echo feature adds depth and resonance to a singer's voice. Echo affects only your voice and not the music. It will make you sound like you are singing in a big concert hall.
