Advanced Setup

Select Advanced Setup. Click any of the submenus to configure the corresponding function, for example
Layer2 Interface, WAN Service, LAN, NAT, Security, Parental Control, Quality of Service, Routing, DNS,
DSL, UPnP, DNS Proxy, Interface Grouping, Port Configuration and Multicast.
3.2.1

Layer2 Interface

Select Advanced Setup > Layer2 Interface. You can configure:

ATM Interface: Configure the device to access Internet as a ADSL user. ISP provides you VPI (Virtual
Path Identifier), VCI (Virtual Channel Identifier) settings and the DSL Interface with RJ11 connector.

PTM Interface: Configure the device to access Internet as a VDSL user. Packet Transfer Mode (PTM)
transports packets (IP, PPP, Ethernet, etc.) over DSL links as an alternative to using Asynchronous
Transfer Mode (ATM). PTM is based on the Ethernet in the First Mile (EFM) IEEE802.3ah standard.

ETH Interface: Configure the device to access Internet as an Ethernet user. ISP provides you
Broadband Internet Service and the Ethernet Interface with RJ45 or SC/LC optical connector.
3.2.1.1

ATM Interface

Select Advanced Setup > Layer2 Interface > ATM Interface. The following page opens:

Add: Click the button to add a new ATM PVC identifier.

Remove: Select the checkbox in the table and click Remove.The corresponding interface will be
deleted.
Note: If the interface is used by the configuration of the
remove the corresponding WAN Service entry first before removing it here.
Figure 3-2: ATM Interface
D. Management guide
"WAN Service", you need to
