Manual
Handling
The Global Positioning System (GPS) consists of a total 24 GPS satellites that orbit the earth,
enabling you to determine your position anywhere in the world, 24 hours a day, if you can receive
satellite signals. During actual navigation, carefully compare the position data with all available
navigation sources such as Loran C, Decca, other navigators, charts, visual navigation, depth, water
temperature and others. It is your responsibility to make navigation judgments.
DGPS Operation Note :
Your position can be improved by DGPS correction. However, when you are communicating with other
ships, you may use a DGPS corrected position but they may not. Make your position source known
during communication.
The Electronic Chart :
Only official authorized charts and notices to mariners contain all the information needed for the safety
of navigation and, as always remember, the user is responsible for their prudent use.
Pictorials
This manual uses the following symbols for easy understanding safety instructions. Always follow
these instructions carefully.
WARNING
CAUTION
WARNING
Important Notice
Keep this manual in a safe place where you can access it quickly.
This Manual must be passed to a new owner of the HIS-70R when it is
transferred.
Always follow this safety instruction to prevent death or injury.
Follow this safety instruction to avoid possible injury or damage to your
property.
Symbol "△" is a CAUTION or WARNING label indicating the safety
instruction.
This symbol is an Electrical Shock WARNING label.
Symbol " " is an instruction that you must not violate.
(This symbol instructs NOT to disassemble the system components)
Symbol " " is an operation instruction that you must follow.
(This symbol shows the main power OFF instruction.)
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIS-70R and is the answer not in the manual?

Questions and answers

Related Manuals for Haiyang HIS-70R

Summary of Contents for Haiyang HIS-70R

  • Page 1 Important Notice Keep this manual in a safe place where you can access it quickly. Manual This Manual must be passed to a new owner of the HIS-70R when it is Handling transferred. The Global Positioning System (GPS) consists of a total 24 GPS satellites that orbit the earth, enabling you to determine your position anywhere in the world, 24 hours a day, if you can receive satellite signals.
  • Page 2 WARNING <For System Operators> Always follow this instruction to prevent death or personal injury. If smoke or a small of burning occurs, a fire or an electrical Turn power off short circuit may result. Turn the power switch OFF and shut During down the power supply immediately.

  • Page 3: Installation Cautions

    Installation Cautions <For service Personnel> Follow installation instructions to avoid personal injury and system malfunction. Installation in Mount your AQUA on a rigid frame or base to prevent your unit from working loose. rigid location Use the installation materials provided in the standard accessory pack Use correct only.

  • Page 4: Operation Notes

    Operation Notes <For operators> Observe the following operation notes, otherwise the system failure or deterioration can result. And periodical inspection and maintenance are required for keeping the system in an optimum condition. The waypoint and other registered data may become unreadable by Backup important data.
  • Page 5 HIS-70R System Welcome The HIS-70R System opens a new chapter of performance and integration in vessel navigation system display and management. Whether you are a Cruiser or Sport fisherman or both, HIS-70R gives you the information you need. CAUTION The HIS-70R is Color LCD Charting Systems employs the latest in proven technology to provide accurate navigation information.
  • Page 6 The HIS-70R is a premium multifunction command and control center. HIS-70R front panel keyboard and its wide screen with wide viewing area make placement easy. Although HIS-70R offers many advanced features, operation is simplified through the use of popup menus similar to those found on personal computers.
  • Page 7 HIS-70R System Standard Equipment Configuration List (Plastic) GPS ANT. Power cable Display unit Protector Mounting Bracket Knobs Manual - 7 -...

  • Page 8: Getting Started

    This getting Started section will help you become acquainted with the displays and the front panel keyboard functions of your HIS-70R System. This section is intended to demonstrate the main functions and basic operation of your HIS-70R System. More detailed procedures may be found in the Operation section.

  • Page 9: Specification

    HIS-70R System SPECIFICATION GENERAL SPECIFICATION 1. Display Screen wide 7 inch color TFT LCD(480 X 800 pixels) 2. Operating Temperature Display Unit: -15°C ~ 50°C Antenna Unit: -25°C ~ 70°C 3. Performance Standard IMO Resolution MSC.112(73) 4. Back-up SD Card (Optional) CHARTPLOTTER SPECIFICATION 1.
  • Page 10 HIS-70R System 3. Accuracy Position 2.5m CEP DGPS/SBAS 2.0m CEP 4. Sensitivity Acquisition -140 dBm Tracking -149 dBm 5. Data Update Rate 1 Second 6. Support DGPS, SBAS (WAAS, EGNOS,etc) AIS SPECIFICATION 1. Electrical Interfaces RS232 38.4kBaud bi-directional RS422 NMEA 38.4kBaud bi-directional 2.
  • Page 11 HIS-70R System Keypad Description [Cursor With MENU: Choosing the menu. Key] Without MENU: Cursor on. [ENTER] Button: Enter when menu table on the screen. [+] &[-] Change the chart of scale. One step: Quick menu is displayed. [MENU] Two step: Main menu is displayed.
  • Page 12 HIS-70R System HIS-70R Metal <Front> Main Screen Keypad Knob Mounting Bracket <Rear> Connector - 12 -...
  • Page 13 HIS-70R System HIS-70R Plastic <Front> Main Screen Keypad Knob Mounting Bracket <Rear> Connector - 13 -...
  • Page 14 HIS-70R System SPEC of the connectors Metal Plastic - 14 -...

  • Page 15: Ais Menu

    Operations AIS MENU To obtain more information on AIS vessels or to configure the AIS ▶ Press [AIS] 1. List of Vessels. Pressing the [ENTER] key will display a list of current AIS vessels inview. Initially these are sorted by showing the nearest first, additional pages of vessels can be displayed by pressing the [►] arrow key.

  • Page 16: Display Radius

    Operations 2. Display radius Displays range rings centred on your current position. ☞ The default setting is OFF. 3.Display vessels by color. You can choose to display certain types of vessels by different color to help in quickly identifying what type of vessels are showing on the chart. Scroll down the list until the vessel type you want to alter is highlighted in blue, pressing the [►] arrow key will scroll you through the choice of colors, press the [◄] arrow key to go backwards, leave the color selection of your choice showing and press the [CLEAR] key to exit.
  • Page 17 Operations 6. Alarm The two alarm parameters can be changed to suit your particular circumstances. The CPA alarm is the closest approach alarm, this allows you to set a distance when the alarm will sound if a vessel comes within that distance. The alarm can be turned ON or OFF by use of the [◄] or[ ►] keys. The range at which you want the alarm to sound can be adjusted by selecting CPA limit, pressing the [►] key will increase the range, and pressing the [◄] key will decrease the range, pressing [CLEAR] will exit the function.

  • Page 18: Messages List

    Operations 9. Cursor Box info. When you move the cursor in chart mode over an AIS target a box appears showing details of that vessel. You can configure that box to show various details by turning ON or OFF the features in the menu with the [►] [◄] keys.
  • Page 19 Pages Select Page Press [Page] key and then go to “Pages” screen Selectable Pages by red box and then press [ENTER] key. red box - 19 -...
  • Page 20 Customize Customize of screen Press [PAGE] key on the Pages which selected red box.(*Refer Fig. 1.1.1 as below) Select the layout of the formation of screen.(*Refer Fig. 1.1.2 as below) Select displays .(*Refer Fig. 1.1.3 & 1.1.4 as below) <Fig. 1.1.2> <Fig.
  • Page 21 Customize Customize of data bar ▶ [MENU]->Setup->Customizing->Datadar->Edit Select the section to edit by red box. .(*Refer Fig. 1.2.1 as below) Press [ENTER] key and select the data as a user want.(*Refer Fig. 1.2.2 as below) Finish the formation of data bar, press [CANCEL] key to complete. <Fig.
  • Page 22 Customize Navigation data edit ▶ [MENU]->Setup->Customizing->Navigation Data->Edit Select the section to edit .(*Refer Fig. 1.3.1 as below) Press [ENTER] key and select the data as a user want. .(*Refer Fig. 1.3.2 as below) Finish the formation of data bar, press [CANCEL] key to complete (* If no navigation data on present activated display, it is not available to edit) <Fig.

  • Page 23: Map Orientation

    Map Orientation 1. True Motion The True Motion is in the way the vessel position is presented. In True Motion mode, the vessel position symbol moves over the map while the map remains stationary. Select True motion. (* It is not available to operate on Course up and Head up.) 2.
  • Page 24 The Track function provides a record of the path over which your vessel has traveled. A track is a series of lines connecting points of vessel present position which are plotted at wither time or distance intervals. Tracks are recorded and stored one at a time. HIS-70R supports 50,000 points of track history.
  • Page 25 Menu 9. Track color Changes the color of the track line. 10. WPT symbol Changes the color of the WPT 11. WPT color Changes the symbol of the WPT 12. Recording This is the function of recording current screen. Marked [● REC] in red color on the upper right on the data bar during recording. Note: The recording file is stored in SD card.

  • Page 26: Advanced Menu

    Advanced menu The advanced menu and explanation of operation are displayed. ▶ [MENU] ->Advance or [MENU]->[MENU] 1. Userdata 1.1. WPT Waypoints may be entered and stored in the waypoint library by any of two different methods. You may use the cursor to select locations from a chart, or store vessel present position as a waypoint 1.1.1.
  • Page 27 Advanced menu 1.1.3. Symbol size You can select the size of “WPT symbol” (☞ The default setting is Auto.) 1.1.4. Color You can select the color of WPT symbol (There are 16 sort of * WPT symbols as picture) 1.2. Route Use waypoints to create a instant route for your sailing.
  • Page 28 Advanced menu 1.3. Track 1.3.1. Color You can select the color of “Track” (There are 16 sort of * WPT symbols as picture) 1.3.2. Erase You can erase all tracts by the selected color. (* If you want to delete to be being used the track , choose “All Erase”) - 28 -...
  • Page 29 Advanced menu 1.3.3. Setup 1.3.3.1. Thickness The size of a track is selectable between thin and pan. ☞ The default setting is Thin.) 1.3.3.2. Record setup Track display interval is adjustable by distance or time. ☞ The default setting is Time.) 1.3.3.3.
  • Page 30 Advanced menu 2.GPS It is available to control and confirm information in GPS receiver. 2.1. Coordinate System It sets coordinate system of GPS or Loran. (☞The default setting is GPS.) 2.2. Datum It shows GPS Datum. WGS-84, which is the worldwide standard is only available. (☞...
  • Page 31 Advanced menu 3.Setup It is available to set the menu or units for user’s visual confidence. 3.1. Unit 3.1.1. DIST/Speed Select desired unit of measure for distance and speed. Choose from: nautical mile/knots (nm/kt), kilometer/kilometers per hour(km/kmh), yard/knot(yd/kt). cf) 1nm = 1.852km, 1kt /h= 1.852km/h, less than 1nm display in yard and over 1nm display in mile ☞...
  • Page 32 Advanced menu 3.3.3. Date Format Sets you preferred date among YY-MM-DD, MM-DD-YY or DD-MM-YY. ☞ The default setting is YY-MM-DD.) 3.3.4. Month format Sets you preferred date between Character or Number. 3.3.5. Calendar setup 3.3.5.1. Week starts on You can select the first day of week. (☞...

  • Page 33: Backlight Time Out

    Advanced menu 3.6. Backlight time out It is the screen sets the time to sleep mode. ☞ The default setting is off.) 3.7. Customizeing 3.7.1. Databar 3.7.1.1. Display Setting up shown/hide the databar on the display. (☞ The default setting is shown.) 3.7.1.2.

  • Page 34: Maintenance

    Advanced menu 4. Maintenance It is necessary to check the system or the version for maintenance and demonstrate HIS-70R with the simulators 4.1. Program VER. It contains ID and the program version, and it has important information for maintenance and upgrade.
  • Page 35 Advanced menu 5. Others 5.1. Recording List Available to display and delete the recording file 5.2. Capture List Available to display and delete the capture file 5.3.Calendar It is available to check the solar/moon calendar and tide. 5.4. Key Setup It is available to set up [FUNK] key and [EVENT] key on the HD-70F.
  • Page 36 It set the maps are displayed in ordered to use colors as similar as possible to the ones used in the original paper charts. 1.4.2. Sunlight It is designed to enhance the visibility of the screen when HIS-70R is exposed to the sunlight. The maps are much brighter than in the other displays. 1.4.3. NOAA Allows setting NOAA paper chart colors presentation.
  • Page 37 Chartplotter menu 1.8-1. HY-Map (*Only for *HY-MAP mode.) 1.8-1. 1.2M Setting up 2m of the depth line on the HY-MAP. 1.8-1.2. 5M Setting up 5m of the depth line on the HY-MAP. 1.8-1.3. 10M Setting up 10m of the depth line on the HY-MAP. 1.8-1.4.
  • Page 38 Chartplotter menu 1.8-2. C-Map (*Only for *C-MAP mode.) 1.8-2. 1. SAT.Image Setting up the overlay Satellite Image on the C-MAP. (☞ The default setting is shown.) 1.8-2. 2. Font&Symbols On charts it is possible to set the size of all names and symbols drawn on the charts, selecting between Normal size and Large size.
  • Page 39 Chartplotter menu 1.8-2. 7. QuickView It is available to set up. Place the cursor on buoys or icons on the C-MAP, the information window is shown up automatically. ☞ The default setting is hidden.) 2. Vessel 2.1. Vessel Icon Size The size of the present position is adjustable from 0 to 9.
  • Page 40 Chartplotter menu 3.2. Anchor 3.2.1. Anchor Alarm: It is necessary when your vessel anchors. ☞ The default setting is OFF.) 3.2.2. Anchor Radius: If you vessel is out of the range of the anchor, it gives you notice with alarm. ☞...

  • Page 41: Ais Classes

    Introduction How AIS Works The marine Automatic Identification System (AIS) is a location and vessel information reporting system. It allows vessels equipped with AIS to automatically and dynamically share and regularly update their position, speed, course and other information such as vessel identity with similarly equipped craft. Position is derived from a Global Navigation Satellite System (GNSS) network and communication between vessels is by Very High Frequency (VHF) digital transmissions.
  • Page 42 Introduction Class A ship borne reporting intervals Ships dynamic conditions Rate Ship at anchor or moored 3 min Ship 0-14 Knots 10 sec Ship 0-14 Knots and changing course 3.3 sec Ship 14-23 Knots 6 sec Ship 14-23 Knots and changing course 2 sec Ship >...

  • Page 43: Nmea 0183 Messages

    NMEA 0183 Messages Receipt of a VHF transmission on either AIS radio channel causes a VDM message to be output via the data port. VDM Message Format !--VDM,x1,x2,x3,a,s--s,x*hh<CR><LF> x1 = Total number of sentences needed to transfer the message , 1 to 9 x2 = Sentence number, 1 to 9 x3 = Sequential message identifier, 0 to 9 a = AIS Channel, "A"...
  • Page 44 ACK Message Format Can be generated by a minimum keypad and display (MKD) unit, chart plotter or other display device connected to the HIS-70R to acknowledge an alarm condition reported by the SAS SERIES. $--ACK,xxx*hh <CR><LF> xxx = Unique alarm number...

  • Page 45: Installation

    Installation GPS Antenna The GPS antenna used must be of the active type (i.e. it should incorporate an LNA) and must be suitable for marine shipboard applications (index of protection, ruggedness, means of mounting, etc.). An antenna should be selected with a gain (in dB) depending on the length of cable between the antenna and the AIS unit;...

  • Page 46: Display Unit Location

    HIS-70R integrated features. Display Unit Location Select a location for your HIS-70R display unit that provides easy viewing from all likely operator’s positions. The display unit is designed to be mounted on either a console or from an overhead surface.

  • Page 47: Display Unit Installation

    - Power Connection Power is supplied to the HIS-70R System through a connector on the rear panel of the display unit. Route the power cable from the HIS-70R location to the ship’s power distribution panel.

  • Page 48: Care And Cleaning

    Reference - Care and Cleaning Your HIS-70R is made to withstand marine elements but a little care ensures a trouble free life. Accumulations of salt and sand, if not removed, will eventually mar the finish. No solvents or harsh cleaners should be used. The display unit may be wiped down with a damp cloth while avoiding the display window.

  • Page 49: How Gps Works

    For centuries, sailors haven en searching for a reliable and precise method of travelling the world’s waterways. From celestial navigating to the modern navigation techniques as Loran, Decca navigator, Omega or Transit Satnav, each system has had its problems with weather, range and reliability. Without doubt, the “Global Positioning System”, or GPS for short, is the most significant advance in navigation: it fives the navigator a position 24 hours a day, 365 days a year in any weather condition.
  • Page 50 the "Spread Spectrum Modulation" method. Excellence in GPS's position-fixing accuracy is mainly due to this technology. 3. When the satellite locations and their distances are known, the GPS receiver fixes its own position by triangulation: [The GPS position calculation] As illustrated in the previous figure, the position is calculated as the meeting point of three spheres which are drawn around the three satellites with diameters d1, d2 and d3.
  • Page 51 The installation of the GPS ANT. The GPS ANT must be installed at the highest area of the boat and the easiest place to catch the signal from the satellites. If there are obstacles around the GPS ANT, it isn't able to catch all signals. The receiving time would be longer or the receiving power would be weaker.
  • Page 52 - 52 -...
  • Page 53 - 53 -...
  • Page 54 - 54 -...
  • Page 55 - 55 -...
  • Page 56 - 56 -...
  • Page 57 - 57 -...

  • Page 58: Declaration Of Warranty

    Web-site: http://www.haiyang.co.kr Guarantee for One Year Haiyang Electronic Equipment Co., LTD warrants the produced equipment, Equipment for One (1) year for guarantee as bellows. 1. Main Unit: One (1) year guarantee after a user purchases the product within one (1) year 2.
