Page 1: Electric Oven
EOS160 electric oven Users Operating Instructions Before operating this oven, please read these instructions carefully... - Page 2 Dear Customer Thank you for choosing one of our appliances which has been carefully designed and built by our specialist staff and thoroughly tested to satisfy your cooking requirement. We suggest that you read this Instruction Booklet so that you will understand fully how to operate the appliances.
-
Page 3: Table Of Contents
Contents Model EOS160 Page Number Installation ............4 The control panel . -
Page 4: Installation
Installation The oven must be installed in accordance with the installation instructions contained in this booklet. Connection to the electricity supply must be made by a competent electrician to a suitable 13 amp. switched socket. Warning this appliance must be earthed. Before use Please ensure that all packing has been removed from the appliance before switching on. -
Page 5: Function Selector & Thermostat Controls
Function selector and thermostat controls When using the oven the function selector control knob and thermostat control knob have to be used in conjunction with one another; first select the function that you require (see table below) and using the thermostat control knob set the cooking temperature. -
Page 6: Preparing The Oven
Preparing the oven Clean the oven thoroughly before using it for the first time; use water and soap, then rinse carefully. Once the above operations are completed, heat the oven to the max. temperature for about one and a half hours so as to eliminate any residual factory grease that might impart unpleasant smells to the meals being cooked. -
Page 7: Cooking Advice: Cooking With The Oven. Grilling
Cooking advice Cooking With the Oven Turn the function selector control knob to position Oven. It is necessary to pre heat the oven before use. First set the thermostat control knob to the chosen temperature. When the oven has reached the chosen temperature the temperature indicator light will go off and cooking can commence. -
Page 8: Cleaning And Maintenance
Cleaning and Maintenance Removal of the inner glass door panel The inner glass door panel can easily be removed for cleaning by unscrewing the two screws. Figure 4. During re-assembly, ensure that the inner glass is correctly aligned and do not over tighten the screws. -
Page 9: Important Notes
Important notes Installation, and any demonstration, information or adjustments are not included in the warranty. We recommend that the installation is carried out by qualified personnel. To replace the interior oven lamp, unscrew the glass guard and make sure that the new lamp has identical specifications, i.e. -
Page 10: Do's And Do Not's
Do’s and do not’s Do’s and do not’s • Do always grill with the oven door closed. • Do always remove the detachable handle when using the grill pan. • Do read the user instructions carefully before using the cooker for first time. •... -
Page 11: For The Installer
For the installer Building in the oven All our ovens are designed for being easily built in - whether masonry or a cabinet made of wood laminated plastic or metal, provided it is heat resistant. To fit the oven properly, any such enclosure, should be as shown in figures 5 and 6. The oven should then be secured by 4 screws fitted into the holes provided at the sides of the oven. -
Page 12: Fixing The Oven
Fixing the oven Introduce the oven into the furniture opening and fix it with screws as figure 7. It is essential that the oven rests on a surface which will support its weight, as the screw fixing is only complementary. Warning! It is very important that the upper slits of the control panel are not obstructed. -
Page 13: Electrical Connection
Electrical connection All electrical wiring must be in compliance with the appropriate I.E.E. and local Electricity Board regulations and carried out by a qualified electrician, e.g. your local Electricity Board or a contractor who is on the roll of the National Inspection Council For Electrical Contracting (N.I.C.E.I.C.). - Page 14 How to wire a 13 amp plug Important. The wires in the mains lead on this appliance are coloured in accordance with the following code: Earth 13 amp Green and Yellow - Earth Green & fuse Yellow Blue - Neutral Brown - Live Neutral Live...
-
Page 15: Technical Data
Technical Data Width 594 mm Overall dlmensions Height 594 mm Depth 560 mm Width 560 mm Aperture sizes for kitchen base unit Height 591 mm Depth 550 mm Width 560 mm Aperture sizes for tall housing unit Height 585 mm Depth 550 mm Rated voltage and frequenoy 230V - 50 Hz... - Page 16 EOS160 electric oven 1101084 ed. 2 - ß6...
