- Page 1 LCD TV with LED backlight User Manual LE32A0321 LE39A0321 HIGH-DEFINITION MULTIMEDIA INTERFACE www.aoc.com 2012 AOC. All Rights Reserved.
- Page 3 This manual provides as an operational guide to user. All statements, technical information, and recommendations in this manual and in any guides or related documents are believed reliable, but the accuracy and completeness thereof are not guaranteed or warranted, and they are not intended to be, nor should they be understood to be, representations or warranties concerning the products described.
-
Page 4: Table Of Contents
DVI/ PC HDMI INPUT SIGNAL REFERENCE CHART ....................15 VIDEO INPUT SIGNAL REFERENCE CHART ....................... 15 VIDEO SYSTEMS SUPPORTED BY THE TV,VIDEO MODES ..................15 USING AOC TV ................................. 16 Switching Input Source ............................................16 MAIN MENU .................................................17 PICTURE MENU ..............................................17 SOUND MENU ..............................................18... -
Page 5: Important Information
Use the Wall-Mount bracket or TV stand which was recommended by the TV immediately and have it checked by qualified service AOC, and please consult your dealer for detailed information. personnel before operating it further. Use with other Wall-Mount Bracket or TV stand may cause instability 15 ) Avoid operating the TV at temperatures below 32°F (0°C). -
Page 6: Usage Instructions
If the AC power cord is damaged, it may result in a fire or Outdoor Use an electric shock. Stop using it and ask your dealer or AOC service center to exchange it. Do not install this TV outdoors. If the TV is exposed to rain, it may result in a fire or an electric shock. -
Page 7: Lcd/Led Screen
LCD/LED Screen Electric Shock Do not touch the AC power cord or the TV with a wet hand. If you Although the LCD/LED screen is made with high-precision plug/unplug the AC power cord from the TV with a wet hand, it may technology and has effective pixels of 99.99% or more, black dots cause electric shock. -
Page 8: Optional Equipment
Optional Equipment Batteries Do not install optional equipment too close to the TV set. Keep Do not dispose of batteries in a fire. optional equipment at least 11.875 inches (30 cm) away from the TV Do not short circuit, disassemble or overheat the batteries. set. -
Page 9: Sound
Sound Install on the wall If a snapping or popping sound from the TV is continuous or frequent 11 7/8 inches 30 cm while the TV is operating, unplug the TV and consult your dealer or service technician. It is normal for some TV’s to make occasional snapping or popping sounds, particu larly when being turned on or off. -
Page 10: Volume Adjustment
Ask a qualified service technician to dispose of the Thank you for purchasing this AOC high-definition television. The quality of the image you see on your AOC TV is only as good as the quality of the signal it receives. To experience the stunning detail of your new AOC TV, you need access to HD programming. -
Page 11: Contents In The Box
Contents in the Box After unpack the TV box, please check the TV and all accessories are well presented and undamaged. AOC TV Base Screw x 4 HDMI Ypbpr Back Source V O L Mute Display Sleep Zoom Menu Freeze... -
Page 12: Controls & Connections
Controls & Connections CVBS OUT CVBS VOL + Press to increase the sound volume level. VOL - Press to decrease the sound volume level. CH ▲ Press to select the next higher program number. CH ▼ Press to select the next lower program number. INPUT Press to select the input source. - Page 13 Buttons located at the right side of the TV will operate the same as these buttons on the remote control. Button Description Press to turn on and off the TV. The TV will never completely power off POWER unless it is physically unplugged. Press to choose TV source mode.
-
Page 14: Set-Up
TV, especially to determine the strength of the wall for withstanding the TV’s weight. For product protection and safety reasons, AOC strongly recommends that you use the Wall-Mount Bracket model designed for your TV and the Wall-Mounting of your TV should be performed by AOC dealer or licensed contractor. -
Page 15: Connecting Tv
Connecting TV Cable System or VHF/UHF Antenna System You can enjoy standard analog definition programming with your new LCD TV using cable or VHF/UHF antenna signal. It is strongly recommended that you connect the antenna/cable input using a 75-ohm coaxial cable to receive optimum picture quality. A 300-ohm twin lead cable can be easily affected by radio frequency interference, resulting in signal degradation. -
Page 16: Composite Signal Connection
Composite Signal Connection AV IN AV Out Signal Connection CVBS OUT CVBS OUT PC Connection Use the TV as a monitor for your PC shown below with the HD15 to HD15 connection. This TV can also be connected to a PC with DVI or HDMI output. -
Page 17: Pc Input Signal Reference Chart
PC Input Signal Reference Chart Connect a computer to your TV set and set up the computer output signal in accordance with table below. Default computer mode Standard Resolution Vertical Frequency(Hz) 720 x 400 SVGA 800 x 600 1024 x 768 WXGA 1360 x 768* *Recommended resolution... -
Page 18: Using Aoc Tv
Switching Input Source On AOC TV, you can choose signal source on the remote control directly, or Press “source” to choose the signal source on the display menu. 1. When choosing signal source on the remote control directly: Press the following keys to switch input source. -
Page 19: Main Menu
MAIN MENU Press [MENU] to enter main menu, included: CHANNEL, PICTURE, SOUND, SETTING, MEDIA. Press◄/►to select, Press [OK] to enter. Press [Display] to exit. Sound Setting Media Channel Picture Standard Sport Cinema Game Vivid Personal Mild Select Menu Back Display Exit PICTURE MENU Press [MENU] to enter the main menu,Press ◄/►... -
Page 20: Sound Menu
SOUND MENU Press [MENU] to enter the main menu,Press ◄/► to select,Press [OK] to enter, Press [Display] to exit or back to parent menu. Sound Setting Media Channel Picture Standard Theatre Voice Personal Music Select Menu Back Display Exit Press▼/▲/◄/►to select the sound mode ,Press [OK] to enter and adjust.Press [Display] to exit. Standard Standard sound. - Page 21 CHANNAL SEARCH: Note: Computer menu is displayed only in the TV channel ,Press [Source] to select TV channel. Setting/Channel Search Auto Search Tune Type Cable Manual Search Menu Display Select Back Exit Auto Search: Press the ▼/▲ choose to auto search,Press [OK] to start searching. The search process If you want to stop the channel search press [MENU].
-
Page 22: Other Adjustments
OTHER ADJUSTMENTS Setting/Other Adjustments Password Setting TV Lock Blue Screen Sleep Time Zoom Wide Noise Reduction Medium Select Reset Menu Back Display Exit Press the ▼/▲ choose to update the channel search,then Press the ◄/► to modify . Password Settings: Set up the TV lock password, enter 4 digits, default is “0000”. PASSWORD Password TV lock... - Page 23 Language Setting the menu display language. Menu Transparency Setting the menu transparency. Menu Timeout Settings menu is displayed when no signal time. Open or close the only volume control, even if the volume disparity can also maintain a fixed volume Caption Setting/PC Auto Adjust...
-
Page 24: Media Menu
MEDIA MENU Press [Source] to select the media channel , connect to the USB or other Removable storage devices. Media Channel Sound Setting Picture Photo Music Video Text Select Menu Back Display Exit Make sure that the TV recognize USB storage device, press the ▼ / ▲ / ◄ / ► to select the photo / music / video / text,press [OK] to enter. Photo / music / video / text manipulation is basically the same, press [OK] to display the Actions menu in the process. -
Page 25: Channel Menu
Video Press ▼/▲/◄/► Select the Video menu, Press [OK] to enter the folder. Press ▼/▲/◄/► to select the file,Press [OK] to open the selected file. Select one and press [OK] to display the menu. TEXT Press ▼/▲/◄/► Select the Text menu, Press [OK] to enter the folder. Press ▼/▲/◄/►... -
Page 26: Troubleshooting
Troubleshooting Condition Explanation / Solution No picture No picture Check the Power Saving settings. Make sure the power cord is connected securely. Turn on the power of the TV. Cannot receive any channels Check antenna/cable connections. Make sure the Cable setting is correct for your TV signal source. TV is locked to one channel Perform Auto Program to add receivable channels that are not present in the TV’s memory. -
Page 27: Dimensions & Specifications
Dimensions & Specifications Model LE32A0321 LE39A0321 Panel size 800 mm diagonal (31.5” viewable) 977.9 mm diagonal (38.5” viewable) Resolution 1366 x 768 1920 x 1080 NTSC NTSC TV System PAL M/N PAL M/N Speaker 10 W x 2 10 W x 2 Antenna impedance 75Ω...
