Summary of Contents for Outdoor Order Curve MTC-CURVE-GM-LP
- Page 2 CURVE PATIO HEATER DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department. WARNING Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 3: Warnings And Cautions
WARNINGS AND CAUTIONS DANGER CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide which has no odor. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent or home. WARNING: Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. - Page 4 WARNINGS AND CAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: The installation must conform with local codes Any guard or other protective device or, in the absence of local codes, with the removed for servicing the heater must be National Fuel Gas Code, ANSI Z223.1/NFPA 54, replaced prior to operating the heater.
- Page 5 WARNINGS AND CAUTIONS NOTE:PLEASE READ THE FOLLOWING SAFETY RULES WARNING: Within a partial enclosure which includes an The pressure regulator and hose assembly sup- overhead cover and three side walls, as long as plied with the appliance must be used, replace- 30 percent or more of the horizontal periphery of ment pressure regulators and hose assemblies the enclosure is permanently open.
-
Page 6: Tools Needed
WARNINGS AND CAUTIONS NOTE: PLEASE READ THE FOLLOWING SAFETY RULES: Perform a leak test with a soapy solution: 1. To check gas connections. 2. After connecting a new cylinder. 3. Upon re-assembly after disassembly. This heater is designed to operate with a standard 20 Ib propane cylinder with Approved Cylinder Connection. -
Page 7: Exploded View
EXPLODED VIEW... -
Page 8: Parts List
PARTS LIST Part # Description Picture Transom assembly Pole & base assembly Decorative cover Cylinder fixing hook... -
Page 9: Before Assembly
BEFORE ASSEMBLY NOTE: PLEASE FOLLOW THE FOLLOWING STEPS TO REMOVE THE PALLET STEP 1 Unscrew 6pcs M5 x 12 bolts to remove the heater from the pallet, and then screw these 6pcs M5 x 12 bolts back to the base of the heater. M5 x 12 bolts M5 x 12 bolts STEP 2... - Page 10 ASSEMBLY INSTRUCTIONS STEP 1 Put the decorative cover (3) through the pole (2) and place it on the tabletop. Shoulder screw on pole Pole fixing sleeve Table of base assembly STEP 2 Unscrew M8 x 85 bolt and M8 cap nut on Transom assembly (1). M8 x 85 bolt M8 cap nut...
- Page 11 ASSEMBLY INSTRUCTIONS STEP 3 Half-loosen other 3pcs M8 cap nuts on Transom assembly (1). Note: Do not take out! M8 cap nut STEP 4 Make sure the reflector is at the same side as wheels. Insert the hose and regulator through the pole (2) and place the transom assembly (1) on the pole (2). Insert M8 x 85 bolt through the hole of transom assembly (1) and pole (2) and secure them with M8 cap nut.
- Page 12 ASSEMBLY INSTRUCTIONS STEP 5 Insert cylinder fixing hook (4) into holes on base assembly (2). Place the gas cylinder (not included) into the base assembly (2) and fix it with cylinder fixing hook (4). Attach the regulator to the cylinder and turn clockwise to securely tighten the valve. Close and latch the door. Note: Make sure to check for leaks after attaching the cylinder.
-
Page 13: Safety Check
SAFETY CHECK WARNING : ONLY AN AUTHORIZED GAS TECHNICIAN SHOULD INSTALL THIS PRODUCT. Check for leaks All connections on the patio heater have been checked for leakage at the factory. In transportation and handling some connections may have loosened. Follow these steps to check the gas hose/regulator/cylinder connections: 1) Make leakage solution by mixing 1 part liquid dish soap and 3 parts water. - Page 14 SAFETY CHECK WARNING: ONLY AN AUTHORIZED GAS TECHNICIAN SHOULD INSTALL THIS PRODUCT. battery compartment cover 4pcs M4 x 10 bolts. inlet pipe fitting and metal Battery compartment cover hose fitting. e. If no bubbles appear, the connection is safe. f. If bubbles appear, there is a leak. Shut off the LP gas cylinder valve, loosen and then re-tighten this connection.
- Page 15 1) Turn LP Cylinder gas valve to fully open position and press “ ” button on the control panel. If the sparks stop and burner does not stay lit, press the button “ ” again to ignite after 10 seconds. 2) When the burner is lit, press “...
- Page 16 SRPH72 WIRING DIAGRAM THERMOCOUPLE SPARK PIN TILT SWITCH - SAMPLE CONTROL PANEL BLACK WIRE GAS OUT + SAMPLE RED WIRE HIGH VALVE HIGH HV OUT LOW VALVE -POWER+ BLACK WIRE RED WIRE DC3.0V GAS IN D#1.5X2 BATTERY The flames pattern at sintered metal wire, normally, the burner flame is red, but little flame is accpectable.
- Page 17 press the control knob to the “ ” press...
-
Page 18: Locating Heater For Use
LOCATING HEATER FOR USE CAUTION: WHEN CERTAIN MATERIALS OR ITEMS ARE LEFT, ABOVE, BESIDE OR UNDER THIS HEATER WHILE IN USE, THEY WILL BE SUBJECT TO RADIANT HEAT AND COULD BE SERIOUSLY DAMAGED. This heater is primarily used for the heating of outdoor patios, decks, spas, pools and open working areas. -
Page 19: Maintenance & Storage
MAINTENANCE/STORAGE CLEANING AND MAINTENANCE : WARNING: To enjoy years of outstanding performance from your FOR YOUR SAFETY ; heater make sure you perform the following maintenance DO NOT touch or move heater for activities on a regular basis: at least 45 minutes after use. Allow all burner elements to cool before Keep exterior surfaces clean. - Page 20 MAINTENANCE/STORAGE Spiders and insects can nest in burner or orifices. This dangerous condition can damage heater and render it NOTE: unsafe for use. Clean burner holes by using a heavy-duty wait until heater is cool before pipe cleaner. Compressed air may help clear away covering.
- Page 22 1 OUTDOOR ORDER LLC. 1-866-814-0585 cs@outdoororder.com...
- Page 23 Dear Valued Customer, Thank you for your recent purchase from Outdoor Order. We pride ourselves in providing the most innovative, reliable and stylish outdoor comfort products in the industry. Our mission is simple, bring order to the outdoors. Our collection meets the highest manufacturing standards and is backed by an unmatched industry warranty.
