- Page 1 AVL240SDI 24” TFT LCD MONITOR USER MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of contents ......................2 Warning ........................3 Precautions ........................ 3 About this user manual ....................5 Items included in package ..................5 1. IR Remote control ....................6 2. LCD Monitor Mounting Guide ................9 3. Monitor controls ....................10 4. -
Page 3: Warning
WARNINGS: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION: EXPLANATION OF GRAPHICAL SYMBOLS Danger: This symbol is intended to alert the user to the presence of un-insulated "dangerous voltage"... -
Page 4: Safety Precautions
Installation Do not install the unit in an extremely hot or humid place or in a place subject to excessive dust or mechanical vibration. The unit is not designed to be waterproof. Exposure to rain or water may damage the unit. -
Page 5: About This User Manual
About this User Manual This manual aims at assisting the user on how to operate the monitors described in this manual. This manual is subject to rigid quality control. However, no guarantee can be given that mistakes are not present. We reserve the right to make changes to the manual without prior notice. -
Page 6: Ir Remote Control
1. IR remote control (1) Power Press this button to turn the monitor on/off. (2) Zoom Press this button to toggle between the different picture formats: Full/Zoom/Subtitle/Regular/Panorama Mute Press this button to disable the sound. Press this button again to turn the sound on again. - Page 7 (13) Swap When in PIP mode, press the swap button to switch the main picture and the sub picture. The swap button is only active if you have defined a sub-picture before. (14) Position When in PIP mode, press the position button to define the position of the sub- picture: Either in one of the four screen corners or centered.
- Page 8 (17.6) Press “Up/Down” Key to select the play file and press Right key to play. Press “Menu” to stop play. Then press “Catalog” return the menu. Press “Menu” into the USB Main menu. (17.7) Press “PC/HD”, “AV1/AV2” or “SV” to exit the USB function.
-
Page 9: Lcd Monitor Mounting Guide
2. LCD Monitor Mounting Guide Desktop Adjust the viewing angle of LCD to fit most comfortable monitoring status. Wall mount Free your space with wall mount design. Please follow the fix-hole size in back panel to install the LCD to the wall. C. -
Page 10: Monitor Controls
3. Monitor controls (1) Power Turn the monitor on/off. LED: Green Monitor on LED: Red: Standby mode (no input signal) (2./3.) Adjust Up / Down ▲/▼ Increase or decrease the values in the OSD menu: Up: Increase the values. Down: Decrease the values. (4) Item/Select Hot key for OSD adjustments of volume, contrast, brightness, hue, saturation, sharpness, and Red, Green, Blue. -
Page 11: Connections
4. Connections NOTE: Connections of Audio Audio 1 Audio 2 PC Audio S-Video 5. Monitor Setting via OSD Menu Various monitor settings can be made using the OSD menu (On Screen Display). Press the Menu/OK button to call-up the OSD main menu. Here you can make adjustments to the following items: •... -
Page 12: Picture
Picture ▲▼ buttons to select adjusts item, Use the and press source button to confirm. Then ▲▼ buttons to increase/decrease the values, or use “source” button to change use the the values. Press the menu button to return to the previous menu item. Item Description Use the ▲▼... -
Page 13: Osd Setup
OSD Setup ▲▼ buttons to select adjusts item, Use the and press source button to confirm. Then ▲▼ buttons to increase/decrease the values, or use “source” button to change use the the values. Press the menu button to return to the previous menu item. Item Description Language... -
Page 14: Pip
▲▼ buttons to select adjusts item, Use the and press source button to confirm. Then ▲▼ buttons to increase/decrease the values, or use “source” button to change use the the values. Press the menu button to return to the previous menu item. Item Description Multi... -
Page 15: Geometry
Geometry Use the ▲▼ buttons to select adjusts item, and press source button to confirm. Then use the ▲▼ buttons to increase/decrease the values, or use “source” button to change the values. Press the menu button to return to the previous menu item. Item Description ▲▼... -
Page 16: Technical Specifications
Technical specifications Monitor model AVL240SDI System PAL / NTSC LCD panel 24“ Visible area (mm) 531.3 x 298.8 Picture format 16:9 Max. resolution 1920x1080 Pixel dot pitch (mm) 0.276.7 x0.276 .7 Colors 16.7M Brightness 250 cd/m² [LED] Contrast 1000:1 Response time(Tr/Tf) 3.5/1.5 ms... -
Page 17: Appendices
APPENDICES TROUBLESHOOTING The tables provided below include some problems that the user may encounter while using the display and the corresponding solutions. Please refer to the contents of this section prior to contacting service personnel. Problem Possible Causes Solutions 1. Is the power cable 1. - Page 18 Please contact the customer service center of your local dealer if you have any questions regarding the unit after reading the information provided above. THANK YOU FOR CHOOSING AVUE PRODUCTS. ...
