- Page 1 Dynamix UM-V2 VDSL2 LAN Extender User Manual Version 1.00 March 2009...
- Page 2 Dynamix UM-V2 VDSL LAN Extender User Manual, V100 Page: 1...
-
Page 3: Table Of Contents
Dynamix UM-V2 VDSL LAN Extender User Manual, V100 Tables of Contents Chapter 1 Introduction ................3 Features ........................3 Specification ........................3 Applications ........................4 Chapter 2 Hardware Installation ..............5 2.1 Front Panel..........................5 2.2 Real Panel..........................7 2.3 Installation ..........................7 Appendix I......................8... -
Page 4: Chapter 1 Introduction
User Manual, V100 Chapter 1 Introduction Dynamix UM-V2 VDSL LAN Extender is a long reach Ethernet media converter with one Ethernet port (RJ-45 connector) and one VDSL port (RJ-45 connector) It is a bridge mode modem, well accommodating VDSL2 (Very-high-data-rate Digital Subscribe Loop) technologies to extend Ethernet service over single-pair phone line. -
Page 5: Applications
Dynamix UM-V2 VDSL LAN Extender User Manual, V100 1.3 Applications LAN Extender Application Page:4... -
Page 6: Chapter 2 Hardware Installation
Dynamix UM-V2 VDSL LAN Extender User Manual, V100 Chapter 2 Hardware Installation This chapter shows the front panel and how to install the hardware. 2.1 Front Panel Please see the side view below configure 2.1: Front panel can be separated into five parts fron left to right:... - Page 7 Dynamix UM-V2 VDSL LAN Extender User Manual, V100 The following table describes the DIP Switchs’ setting. Pin 1 Pin 2 Pin 3 Pin 4 Side Channel Rate Limit Interleave Symmetric Fast Asymmetric Pin 1: CO, CPE switch GO: LAN Extender acts as Central Office (CO) side.
-
Page 8: Real Panel
Dynamix UM-V2 VDSL LAN Extender User Manual, V100 The following table describes the LEDs’ function of the product. LED for ® ¡ VDSL blinking ¡ Power ON Power OFF CPE-mode CO-mode ¡ Slow: Idle Linked Off line ¡ Fast: Training 2.2 Real Panel... -
Page 9: Connector Architecture
Dynamix UM-V2 VDSL LAN Extender User Manual, V100 Appendix I Connector Architecture Ethernet Port Connector (RJ-45) The Ethernet Port interface is a 8 position Modular Jack. The table below displays the pin out assignments. Pin Number Assignment (MDI-X) Figure RX+;... -
Page 10: Chassis Accessory
Dynamix UM-V2 VDSL LAN Extender User Manual, V100 Appendix II Chassis Accessory Dynamix also provide the Mini-Chassis solution for application on the rack in CO side. The major factor of Dynamix UR-V8 is listed below: Ÿ 2 U high Ÿ...
