Operating and installation instructions
Refrigerator with DynamicCooling
K 14820 SD
K 14820 SD ed/cs
en - AU
To avoid the risk of accidents or
damage to the appliance, it is
essential to read these instructions
before it is installed and used for the
first time.
M.-Nr. 09 029 530

Advertisement

Table of Contents
loading

Related Manuals for Miele K 14820 SD

Summary of Contents for Miele K 14820 SD

  • Page 1 Operating and installation instructions Refrigerator with DynamicCooling K 14820 SD K 14820 SD ed/cs en - AU To avoid the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time.

  • Page 2: Table Of Contents

    Contents Guide to the appliance ..........4 Caring for the environment .
  • Page 3 Contents Adjusting the interior fittings ........25 Moving the shelves .

  • Page 4: Guide To The Appliance

    Guide to the appliance a On/Off sensor f Temperature display b DynamicCooling sensor g "Cooling" symbol c SuperCool sensor h Sensor for setting a higher temperature (Y) d Sensor for setting a lower i Alarm off sensor temperature (X) (only visible when the door alarm e Safety lock indicator light sounds) (only visible when Safety lock is...
  • Page 5 Guide to the appliance a DynamicCooling fan b Ceiling lighting c Butter and cheese compartment d Egg tray/Condiment tray e Universal container f Adjustable shelves g Active charcoal filter holder h Bottle rack i Condensate channel and drain hole j Bottle divider k Bottle shelf l Fruit and vegetable containers...

  • Page 6: Caring For The Environment

    Caring for the environment Disposal of the packing Disposing of your old material appliance The transport and protective packing Electrical and electronic appliances has been selected from materials which often contain materials which, if are environmentally friendly for disposal handled or disposed of incorrectly, and can normally be recycled.

  • Page 7: Warning And Safety Instructions

    Warning and Safety instructions Correct application This appliance complies with all This appliance is intended for relevant local and national safety domestic use only for the cool storage requirements. Improper use can, of food and drink. however, present a risk of both Any other usage is not supported by personal injury and material the manufacturer and could be...

  • Page 8: Technical Safety

    In the event of any damage: - avoid open flames and anything which creates a spark, - disconnect from the mains, - air the room in which the appliance is located for several minutes and - contact Miele for advice.
  • Page 9 Faulty components must only be national and local safety regulations. Repairs and other work by unqualified replaced by genuine Miele original persons could be dangerous. The spare parts. The manufacturer can only guarantee the safety of the appliance manufacturer cannot be held liable for unauthorised work.
  • Page 10 Warning and Safety instructions Correct use Do not use defrosting sprays or de-icers, as they might contain Never store explosive materials in substances which could damage the the appliance or any products plastic parts or which could cause a containing propellants (e.g. spray build-up of gases and pose a danger to cans).

  • Page 11: Disposal Of Your Old Appliance

    Warning and Safety instructions The following applies to stainless steel appliances: Do not place sticky notes, adhesive tape, masking tape or any other adhesive agent on the treated surface of the door. The coating will become damaged and lose its protective properties against soiling.

  • Page 12: How To Save Energy

    How to save energy Normal energy consumption Increased energy consumption Installation In a ventilated room. In an enclosed, unventilated room. Protected from direct sunlight. In direct sunlight. Not situated near a heat source Situated near a heat source (radiator, oven). (radiator, oven).

  • Page 13: Switching On And Off

    The appliance will start to cool, and the interior lighting will come on when the ^ Also apply the Original Miele Care door is opened. product for stainless steel to the side panels after removing the protective To enable the temperature to get foil.

  • Page 14: Switching Off

    Switching on and off Switching off Settings mode Certain settings on the appliance can only be selected in the settings mode. How to select the settings mode and how to change the settings is ^ Touch the On/Off sensor until all of described in the relevant section of the indicators go out.

  • Page 15: Switching The Sensor Tones On/Off

    Switching on and off Switching the sensor tones on/off Activating or de-activating the safety lock The sensor tone which sounds each time a sensor is touched can be The safety lock can be activated to deactivated. prevent the appliance being switched off inadvertently.

  • Page 16: Switching Off For Longer Periods Of Time

    Switching on and off Switching off for longer You have now left the settings mode. periods of time The safety lock indicator will light up in the temperature display when the If the appliance is not going to be used safety lock has been activated.

  • Page 17: The Correct Temperature

    The correct temperature Setting the temperature It is very important to set the correct temperature for storing food in the The temperature inside the appliance appliance. Micro-organisms will cause can be selected by touching the arrow food which is not stored at the correct sensors on either side of the temperature to deteriorate rapidly.

  • Page 18: Temperature Range

    The correct temperature If you have adjusted the temperature, Changing the temperature display wait for approx. 6 hours if the brightness appliance is not very full and for The temperature display brightness can approx. 24 hours if the appliance is be adjusted to suit the lighting full before checking the temperature conditions of the room.

  • Page 19: Alarm

    Alarm To switch off the door alarm Your appliance has been fitted with an alarm to avoid energy being wasted if whilst the door is still open the door is left open and to prevent If you want to keep the door open stored food becoming too warm.

  • Page 20: Supercool And Dynamiccooling

    SuperCool and DynamicCooling DynamicCooling m SuperCool The SuperCool function can be used to When the DynamicCooling function is rapidly reduce the temperature in the not switched on, the natural circulation refrigerator to its lowest setting of air in the appliance will cause (depending on the room temperature).
  • Page 21 SuperCool and DynamicCooling Switching off DynamicCooling ^ Touch the DynamicCooling sensor so that the yellow indicator is dimmed The fan automatically switches off when the door is open.

  • Page 22: Using The Refrigerator Efficiently

    Using the refrigerator efficiently Different storage zones – pre-packed vegetables and other fresh food with a label stating it Due to the natural circulation of the air should be kept at a temperature of in the appliance, there are different approx.

  • Page 23: Food Which Should Not Be Stored In A Refrigerator

    Using the refrigerator efficiently Food which should not be Storing food correctly stored in a refrigerator Food should generally be stored covered or packaged. This will prevent Not all food is suitable for refrigeration, food smells from affecting other foods, as some food is sensitive to cold.

  • Page 24: Unpacked Meat And Vegetables

    Using the refrigerator efficiently – Examples of fruit and vegetables Meat which react strongly to the natural Meat should be stored unwrapped. gases given off by other types of (Undo wrappings slightly to leave meat fruit and vegetables are: loosely covered, and leave containers Kiwis, broccoli, cauliflower, Brussels open).

  • Page 25: Adjusting The Interior Fittings

    Adjusting the interior fittings Moving the shelves To move the split shelf: ^ Take both halves of the split glass The shelves can be adjusted according to the height of the food. shelf out, ^ Raise the shelf, and pull it forwards slightly until the notch at the side is in line with the shelf support.

  • Page 26: Adjusting The Condiment Tray/Bottle Shelf

    Adjusting the interior fittings Fruit and vegetable containers Adjusting the condiment on telescopic runners tray/bottle shelf ^ Lift the tray/shelf up and out of the The fruit and vegetable containers are pushed in and out on telescopic stainless steel frame to remove. runners, and can be completely ^ Push up the stainless steel frame, removed if necessary.

  • Page 27: Moving The Bottle Divider

    Adjusting the interior fittings Universal container Moving the bottle divider The universal container can be used The bottle divider can be moved to the both to store and serve food. left or right to ensure that bottles are held securely in position when the door is opened and shut.

  • Page 28: Automatic Defrost

    Automatic defrost The refrigerator defrosts automatically. Condensate and frost can build up on the back wall of the refrigerator whilst it is in use. You do not need to remove this, as it will defrost and evaporate automatically with the warmth generated by the appliance.

  • Page 29: Cleaning And Care

    – dirt erasers, special coating that is not susceptible to soiling. – sharp metal scrapers. Do not apply the Original Miele Care product for stainless steel to the Before cleaning doors as visible smearing will occur. ^ Switch off the appliance.

  • Page 30: Cleaning The Interior And Accessories

    Cleaning and care Cleaning the interior and ^ The serving trays and containers in the door can be removed from their accessories stainless steel frames for cleaning. ^ Clean the appliance at least once a To remove the stainless steel panel month.

  • Page 31: Cleaning The Door And Side Panels

    The appliance door is treated with a high quality surface coating. It protects ^ Stainless steel components can be against soiling and facilitates cleaning cleaned with the Original Miele Care and care. product for stainless steel. ^ Apply the Original Miele Care...

  • Page 32: Ventilation Gaps

    Cleaning and care Ventilation gaps After cleaning ^ The ventilation gaps should be ^ Replace all shelves and accessories cleaned regularly with a brush or back in the appliance. vacuum cleaner. A build-up of dust ^ Reconnect the appliance to the will increase the energy consumption electricity supply and switch it on.

  • Page 33: Active Charcoal Filters

    If you do not have new active charcoal filters, you can order them from your Miele Chartered Agent or from the Miele Spare Parts Department. You can switch off the Change active charcoal filter indicator early if you would prefer not to have the red indicator showing.
  • Page 34 (in holders) in the appliance. Active charcoal filters and holders ^ At the same time, briefly touch the can be obtained from your Miele On/Off sensor (without letting go of Chartered Agent or from the Miele the X sensor).

  • Page 35: Problem Solving Guide

    ^ Check that the fuse is not defective and that the mains fuse has not . . . the interior lighting is not working. tripped. If it has, contact the Miele Service Department. ^ Was the door left open for too long? The lighting switches itself off .
  • Page 36 ^ Replace the active charcoal filters. You can order replacement filters via your Miele Chartered Agent or the Miele Spare Parts Department.."_F" shows in the temperature display. There is a fault. Call the Service Department.

  • Page 37: Noises

    Noises Normal noises What causes them Humming noise made by the motor (compressor). This noise can Brrrrr ... get louder for brief periods when the motor is switching on. Blubb, blubb..A gurgling noise can be heard when coolant is circulating through the pipes.

  • Page 38: After Sales

    You will find the address and telephone number of Miele on the back cover of the manual. When contacting your Chartered Agent or Miele, please quote the model and serial number of your appliance. This information is given on the data plate inside your appliance.

  • Page 39: Electrical Connection

    Electrical connection Electrical connection WARNING THIS APPLIANCE MUST BE All electrical work should be carried out EARTHED by a suitably qualified and competent person in strict accordance with current local and national safety regulations. The appliance is supplied with a mains cable and moulded plug ready for connection to an AC single phase 220-240 V 50 Hz supply.

  • Page 40: Installation

    Should you for side-by-side installation. require further assistance please contact your Miele customer service Your Chartered Agent will be able to centre. advise you on which models are suitable.

  • Page 41: Ventilation

    Installation Ventilation On stainless steel appliances Air at the back of the appliance gets warm. To ensure sufficient ventilation, the ventilation gaps must not be covered over. The air inlet and outlet must not be covered or blocked in any way.

  • Page 42: Appliance Dimensions

    Installation Appliance dimensions K 14820 SD 1850 mm 600 mm 630 mm K 14820 SD ed/cs...

  • Page 43: Changing The Door Hinging

    Changing the door hinging The appliance is supplied with right-hand door hinging. If left-hand door hinging is required, the hinging must be changed. To change the door hinging, you will need the following tools: – a Phillips head screwdriver, – a flat-bladed screwdriver, –...
  • Page 44 Changing the door hinging ^ Fit restraining clip b (supplied with Removing the SoftClose door mechanism the appliance) onto SoftClose mechanism c. The SoftClose door mechanism is at the bottom of the door. The restraining clip stops the hinge from snapping shut. Do not remove the ^ Open the appliance door.
  • Page 45 Changing the door hinging ^ Remove cover b by pulling it upwards. Caution! The appliance door is not secure once the hinge plate has been removed. ^ Loosen screws d in upper hinge plate c and pull it upwards and off. ^ Carefully lift the door off and place it ^ Slide SoftClose mechanism bracket to one side.
  • Page 46 Changing the door hinging ^ Then fit cover e together with ^ Unscrew bearing h from hinge plate retaining plate f on the opposite f, rotate it by 180° and refit into the side. hole on the opposite side of the hinge plate.
  • Page 47 Changing the door hinging ^ Insert the SoftClose mechanism back into the door, starting at the ^ Fit hinge plate c onto the opposite right-hand side. side and secure it with screws d. If necessary, drill pilot holes for the screws.
  • Page 48 Changing the door hinging Refitting the handle Please make sure you follow the instructions below carefully when you refit the handle. The door seal will be damaged if the handle is fitted incorrectly. ^ Attach panel b to SoftClose mechanism bracket d. ^ Align bracket d to the hinge plate, and insert pin e from above so that the right angle fits into the recess.
  • Page 49 Changing the door hinging It is important to check that the side section of the handle d does not come into contact with the door seal when opening the door as this would damage the door seal permanently. If, after you have refitted the handle, you find that the side section does touch the door seal when the door is opened:...

  • Page 50: Aligning The Appliance Door

    Aligning the appliance door The appliance door can be aligned to the housing using the outer long slots in the lower hinge plate. In the following illustration the door is not shown in the closed position to make it easier to see what happens next.

  • Page 51: Building In The Appliance

    Building in the appliance The air inlet and outlet must not be covered or blocked in any way. They should be dusted on a regular basis. When built into a kitchen run (max. depth 580 mm), the appliance can be installed directly next to a kitchen furniture housing unit.
