- Page 1 Dishwasher FOR MODELS DW 15110 NBL00 DW 15111 NBL00 DW 15120 NBL00 DW 15121 NBL00 DW 15140 NBL00 DW 15141 NBL00...
- Page 2 FILLING THE DISHWASHER SALT............16 10. CARE AND MAINTENANCE ..............16 10.1 CARING FOR YOUR DISHWASHER EXTERIOR......16 10.2 CARING FOR YOUR DISHWASHER INTERIOR.......16 11. TROUBLE SHOOTING................18 12. TECHNICAL FEATURES .................25 13. WARRANTY STATEMENT FOR THE BLOMBERG DISHWASHERS ..26 14. HOW TO GET SERVICE................26...
- Page 3 Do not operate your dishwasher unless all the enclosure panels are properly in place. Please read this user manual and particularly the Do not tamper with the controls. safety instructions completely and carefully. They will save you time and effort and help to ensure Do not abuse, sit on, stand in or on the door or optimum dishwasher performance.
- Page 4 Do not store or use flammable liquids or vapours Do not install or store the dishwasher where it in the area of the dishwasher. can be exposed to below freezing temperatures or exposed to weather. Dishwasher must be secured to adjacent When loading items to be washed, position sharp cabinetry using the brackets provided.
- Page 5 FOR MODELS DW 15110 NBL00 DW 15111 NBL00 DW 15120 NBL00 DW 15121 NBL00 DW 15140 NBL00 DW 15141 NBL00 R-44 Upper rack Lower spray arm Guiding track for the upper rack Detergent dispenser Upper spray arm Filters Lower rack Door Salt container (depending on model ) Control panel...
- Page 6 1. Pull the handle to open the door. If the door is opened during operation, the dishwasher will stop running. Once the door is closed the program will continue. CAUTION 2. Remove coarse food leftovers. 3. Now you can load the dishwasher. Top rack load pattern for 12 place settings according to the AHAM DW-1 Standards...
- Page 7 Load the upper rack with dessert plates, cups, The upper rack is equipped with a lifting mechanism glasses etc. which enables you to change the height of the rack even if it is fully loaded, and without having to remove it from the dishwasher. 1.
- Page 8 There is a "folding tines" in the upper rack to allow Ý you more space to accommodate glasses or cups. When placing the glasses or goblets with a long You can fold to create a large empty space. stems, lean them against the glass support, the Simply press the handgrip 1 until the tines fell down edge of the rack or the shelf but, not against the A.
- Page 9 Use the lower rack for plates, bowls, pots etc. You can use this inset in the lower rack for glasses and long-handled cutlery / utensils. There are 4 separate "folding plate support tines" in the lower rack of your dishwasher designed to allow you more space to accommodate saucepans, pots and large bowls in the lower rack.
- Page 10 To put the parts together again, proceed in the opposite direction. Use the basket inset C for your cutlery so that all For cleaning baby bottles or vases. To remove, pull items in the basket are surrounded by a sufficient both holders apart in opposite directions H.
- Page 11 1: Salad Fork 2: Teaspoon 3: Dinner fork 4: Knife-solid handle Variable cutlery basket load pattern Cutlery basket load pattern for 12 5: Serving spoon for 12 place settings according to place settings according to the 6: Serving cold meal fork the AHAM DW-1 Standards AHAM DW-1 Standards Ý...
- Page 12 The combination of high temperatures and dishwasher detergent may cause damage to some items if they are washed in the dishwasher. Ý Remember, if any doubt about any aspect Rust sensitive steel parts like iron and cast iron concerning items to be washed in the dishwasher, that can rust and stain other utensils and damage follow the instructions from the manufacturer of the the interior stainless steel liner of the dishwasher...
- Page 13 1 Program lights 4 Program follow up lights 7 Door handle 2 Rinse aid level indicator light 5 Cycle select button 8 On/Off button 3 Salt level indicator light 6 Start/Pause button 1. Open the door by pulling the door handle 7. On / Off Turn your dishwasher on with On/Off 2.
- Page 14 When this indicator light comes on, you must refill special To change a running program: salt. 1. Press the Start/Pause button. The indicator The salt content can be read on the container for the light on the button will turn off. salt.
- Page 15 Turn the lock to the right. WARNING The detergent container holds a total of 40 ml / 8 tsp of detergent 1. See marking lines on the inside of the detergent container aid in providing the correct amount of detergent. When the dishwasher is fully loaded and the dishes are very dirty, we recommend filling the detergent container up to the 25 ml / 5 tsp mark.
- Page 16 WARNING Ý Only use rinse aids suited for use in dishwashers. Rinse aids allow washing water to rinse off more cleanly and prevent watermarks or streaks on the dishes. If you use "2 in 1" or "3 in 1" detergents / tabs, you do not need additional rinse aid.
- Page 17 1 min. Remove the test strip Turn on the tap and Hold the test strip in Remove the test Wait for 1 minute. The test strip shows the water for about you the hardness from the packet. let the water run for strip from the water a second.
- Page 18 CAUTION Ý Only use special dishwasher salt in your machine to soften the water, e.g Somat salt. Do not use coarse grained salt. Small grains or powdered salt is more easily soluble. manufacturer is not liable for damages resulting from the use of the wrong type of salt.
- Page 19 CAUTION CAUTION 1. Remove the lower rack from the machine. 2. Turn the coarse filter counterclock wise to the Use only soft cloth left and pull it out in an upward direction A. that is lightly dampened with mild detergent. Clean 3.
- Page 20 Ý Is the machine plugged in? Dirt and/or calcium residue may block the nozzles Are all fuses operative? on the spray arms. For this reason, regularly check Is the water supply fully turned on? the spray nozzles. Is the dishwasher door closed securely? Have you pressed the On/Off button? 1.
- Page 21 Improper loading Load the dishwasher as suggested in this manual. Insufficient rinse aid supply Increase the dosage amount of rinse aid and/or refill the rinse aid dispenser. Dishes are removed too soon Do not empty your dishwasher immediately after washing. Open the door slightly so that the steam can escape.
- Page 22 Too little detergent. Increase the amount of the detergent as per the program table. Too little rinse aid. Increase the amount of rinse aid and/or refill the rinse aid dispenser. The lid of the detergent dispenser remained Always ensure that you close the detergent open.
- Page 23 Smell of new machine. The smell of a new machine disappears after a few wash cycles with detergent. Filters are dirty. Clean all strainers as described in this manual. Dirty dishes standing in the machine for a Remove coarse dirt under running water and few days without being washed.
- Page 24 The lid of the salt container is not closed Salt can destroy metal surfaces and cause securely. Salt loss. (models with salt container) rust damage. Check whether the lid of the salt container is firmly closed. Use the funnel to pour in special salt.
- Page 25 Moisture in the detergent dispenser. Ensure that the detergent dispenser is dry before filling it. Detergent stays in the dispenser of the Pour the detergent in just before washing. dishwasher for too long The lid of the detergent dispenser does not When loading the dishwasher, take care to open.
- Page 26 Dish items/parts made from aluminium. Dishes and cutlery of this type are not suited to dishwashers. The lid of the salt container is not closed Check whether the lid of the salt container is securely. Salt loss. (models with salt container) firmly closed.
- Page 27 Clogged filters. Clean all strainers as described in this manual. Drain hose kinked or clogged. Ensure that the drain hose is properly placed and open. Load capacity 12 place settings Permissible water pressure 4.35 - 145 psi (0.3 - 10 bars) Electrical connection 120 V (volts), 12 A (amps), 60 Hz (hertz) Total power...
- Page 28 ++ parts replaced will assume the identity of the original parts + their original warrany. Blomberg will repaýir or replace at no cost to the consumer any defective parts of the dishwasher use under normal household conditions (warranty is void if the product is used commercially- bed + breakfast, nursing home etc.).
