Quick Start Guide
Package Contents
NVR
POWER CABLE
RACK MOUNT EARS
MOUSE
KEYBOARD
TERMINAL BLOCK (FOR ALARMS)
Before You Begin
1. Connect all cameras to PoE Camera Switch with Cat5, Cat5e, or Cat6
networking cable.
2. Connect the Corporate LAN Port to your Site LAN.
3. Connect a monitor to either HDMI or VGA (only one will function at a time).
4. Connect your mouse and keyboard (included) to any of the three rear USB
ports.
5. Connect power.
a. The V250 will automatically power on and boot into a Wizard which will
guide you through the configuration of your video recorder.
PART NAME
1
Power
Shows the Power On/Off Status
2
HDD
Blinks to indicate usage of the Hard Drive
3
Link
Shows Network Connectivity
4
Tx/Rx
Blinks to indicate network usage
5
USB
USB 2.0 port
Getting Started | V250 GEN 2
