3xLogic V250 Hybrid Quick Start Manual

Quick Start Guide

Package Contents

DVR
POWER CABLE
RACK MOUNT EARS
MOUSE
KEYBOARD
TERMINAL BLOCK (FOR ALARMS)

Before You Begin

1. Connect all IP cameras to PoE Camera Switch with Cat5, Cat5e, or Cat6
networking cable.
2. Connect all analog cameras.
3. Connect the Corporate LAN Port to your Site LAN.
4. Connect a monitor to either HDMI or VGA (only one will functi on at a ti me).
5. Connect your mouse and keyboard (included) to any of the three rear USB
ports.
6. Connect power.
a. The V250 will automati cally power on and boot into a Wizard which will
guide you through the confi gurati on of your video recorder.
PART NAME
1 Power Shows the Power On/Off Status
2 HDD Blinks to indicate usage of the Hard Drive
3 Link Shows Network Connecti vity
4 Tx/Rx Blinks to indicate network usage
5 USB USB 2.0 port
Getti ng Started | V250 Hybrid
1 2 3 4
FUNCTION
5
