This installation guide will help you install the Inteno DG201. Your
a
service provider will supply you with information about log in and
access. DG201 can be connected to an ADSL/VDSL2 network or to an
Ethernet based broadband network.
W iF i
8 0 2 .1 1 n
Start Box
b
Check that the following items
are in the Start Box:
• Inteno DG201
• Power adapter
• RJ45 Network cable (white)
(large contact)
• RJ11 Telephone cable (grey)
(small contact)
• DSL splitter
CAT V
Connecting the
c
DSL/telephone jack
It's important to connect the broadband
service to the first telephone jack in your
home. Otherwise you may get trouble with
your telephony service, as well as your
data service. In an apartment you'll usually
find the first telephone jack close to the
entrance door. In a villa, the location of the
jack may be harder to detect, as you need
to find out where the telephone cable
connects to the house. If you previously
U SB 2
C ATV
have had a broadband service and it has
worked without troubles you'll know that
you should install the modem in the same
telephone jack as before. If you haven't
had a broadband service you'll need to
localize the first telephone jack.
Do as follows:
1. Shut down your computer.
2. Connect the DSL splitter adapter to the
first telephone jack inside the house.
3. Connect the grey telephone cable
between the DSL splitter and the
DG201 (DSL).
Connecting the WAN/
d

broadband connection

Do as follows:
1. Shut down your computer.
2. Connect a RJ45 network cable
between your broadband outlet and
the DG201 WAN port (WAN/GbE1).
DG201
Multi WAN Residential Gateway
