Asus ET2221I/A6410 Series User Manual page 52

Configuring a dynamic IP/PPPoE network connection
To configure a dynamic IP/PPPoE or static IP network connection:
1. From the Start screen, click Desktop to launch the Desktop mode.
2. From the Windows
Sharing Center.
From the Open Network and Sharing Center screen, click Change Adapter settings.
3.
4. Right-click on your LAN and select Properties.
Click Internet Protocol Version 4(TCP/IPv4) and click Properties.
5.
Click Obtain an IP address automatically and click OK.
6.
NOTE: Continue to the next steps if you are using PPPoE connection.
7. Return to the Network and Sharing Center and then click Set up a new connection or
network.
Select Connect to the Internet and click Next.
8.
9. Select Broadband (PPPoE) and click Next.
10. Enter your Username, Password, and Connection name. Click Connect.
11. Click Close to finish the configuration.
12. Click the network icon in the taskbar and click the connection you just created.
13. Enter your user name and password. Click Connect to connect to the Internet.
52
taskbar, right-click the network icon
®
and click Open Network and
All-in-One PC ET2221I / A6410 Series
