Microtech e-tab style Quick User Manual page 9

ESC
1.
Power and
2.
lock
Jack
3-
charge
HDMI
4-
MIC
5-
USB-data
6-
USB HOST
7-
Headphone
8-
Jack
TF card slot
9-
Front
10-
camera
Light sensor
11-
Rear
12-
camera
Left speaker
13-
Right speaker
14-
Microtech S.r.l e-tab Style 9
Press to return to the previous screen
application.
Press and hold to start e-tab. Touch for short
periods to lock or unlock the screen.
Used to charge the battery via the included power
supply.
To connect the TV via HDMI cable (optional).
Microphone
Used for data traffic to and from your computer (e.g.,
music, videos, photos).
Used for USB OTG, mouse, keyboard, USB stick with
special converter.
Used to connect headphones.
Insert here your Micro SD (maximum capacity 32 GB).
2 MPixels.
It improves the brightness of the screen depending on the
environmental conditions.
8Mpixels with LED flash and autofocus
AAC Speaker
AAC Speaker
