Ⅲ．DIP Switch Function
The DIP locates at the bottom of the printer. Open the DIP cover and the DIP is
shown as in the figure. The user needs to adjust DIP to ON / OFF according to the
actual needs.
DIP switch
DIP1 DIP2
ON ON
ON OFF
OFF ON
OFF OFF
Baud rate
DIP5
(bps）
9600
ON
(Default)
19200 ON
38400 OFF
115200 OFF
self-test page's DIP default setting
Verification
DIP6 mode（Valid in
serial state）
ON -
OFF -
Odd Parity
ON
Check (Default)
Even parity
OFF
check
5
Parallel
interface mode
（Valid in
parallel state）
-
-
-
Print server
mode
