H.264 IP
CAMERA
USER MANUAL
MODEL: DOME IP CAMERA
2013/8/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GST-894i and is the answer not in the manual?

Questions and answers

Related Manuals for Orion Technology GST-894i

Summary of Contents for Orion Technology GST-894i

  • Page 1 H.264 IP CAMERA USER MANUAL MODEL: DOME IP CAMERA 2013/8/12...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this device near water. 6. Clean only with a dry cloth. 7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions. 8.

  • Page 3: Table Of Contents

    Table of Contents IMPORTANT SAFETY INSTRUCTIONS ............................2 1. Product Features ................................. 5 2. Installation ..................................6 3. Accessing the Camera ............................... 12 3.1 Access from a Browser ..............................12 3.2 Accessing the IP Camera from the Internet ........................ 12 3.3 Adjusting the Image ..............................
  • Page 4 4.8.2 Service Port ................................30 4.8.3 RTP ..................................31 4.8.4 E-mail ................................... 32 4.8.5 DDNS ..................................33 4.8.6 UPnP ..................................33 4.9 System ..................................34 4.9.1 User ..................................34 4.9.2 Date/Time ................................34 4.9.3 Maintenance ................................ 35 4.9.4 Information ................................35 5.

  • Page 5: Product Features

    1. Product Features This IP Camera is a high-performance H.264 network camera designed for demanding security installations. It delivers crisp, clear images that disclose every detail thanks to a top quality progressive CMOS sensor and advanced image processing. This IP Camera is supported by a wide variety of video management software solutions and provides a perfect solution for securing banks, offices, airports, and other facilities over an IP network.

  • Page 6: Installation

    2. Installation 1. Remove the Dome Cover: a. Loosen four Trox (T20) and remove dome cover. 2. Control: a. Adjust the IP Camera lens up/down/left/right to fit the desired position.
  • Page 8 3. Surface Mount:...
  • Page 9 4. In ceiling Mount:...
  • Page 10 5. Wall Bracket Mount:...
  • Page 11 6. Ceiling Mount:...

  • Page 12: Accessing The Camera

    3. Accessing the Camera  Follow the instructions in the IP Camera Installation Guide to install the camera. This IP Camera can be accessed on most standard operating systems and web browsers. For the best performance, Windows 7 and Internet Explorer 9 (32bit) is recommended.

  • Page 13: Adjusting The Image

    3.3 Adjusting the Image  To adjust the position of the lens: 1. Open the Live View page in a web browser. Select the Setup tab and open the Installation page. Select Video Format. 2. Connect an analog monitor to the Video Out with a BNC cable. Use the image to confirm the camera is position properly.

  • Page 14: How To Stream H.264

    3.6 How to Stream H.264  Deciding on the combination of protocols and methods to use depends on user viewing requirements a local network properties. Setting the preferred method(s) is done on the Setup page. o RTP+RTSP: This method (actually RTP over UDP and RTSP over TCP) should be the first consideration for live video, especially when it is important to always have an up-to-date video stream, even if some of the images are lost due to network problems.

  • Page 15: Video

    4.2 Video 4.2.1 Codec  These are tools to control the camera network streams, adjust network stream video quality settings, and control the video bit rate. o Codec: H.264 and MJPEG are supported. Both streams cannot be set to MJPEG. Note that NONE is also a selection for the 2 Stream.
  • Page 16 o Size: Video output resolution. o Frame Rate (FPS): Choose the number of image frames per second, from 1-30fps in normal mode or 1- 15fps when slow shutter mode is enabled. If slow shutter mode is enabled and the low light condition is met, the frame rate automatically goes down to half of the normal mode setting.

  • Page 17: Camera

    4.2.2 Camera  This section allows various camera settings to be adjusted. o Exposure Control:  Exposure Mode: Set to AUTO for automatic exposure control, or MANUAL to control the camera exposure manually.  AGC Gain: If Exposure Mode is set to MANUAL, AGC Gain can be set from 0-36dB. For low light conditions, adjust to a higher value.

  • Page 18: Audio

     WDR Control: Wide Dynamic Range (WDR) is a feature that allows for different objects at different exposures to be viewed in the same scene (ex; one object in a bright area and one in a dark area).  DNR Control: use temporal and spatial noise reduction to improve image quality and reduce video noise.

  • Page 19: Live

    4.4 Live 4.4.1 Setup  This section allows for general viewer settings to be adjusted. o Viewer Setup:  LiveView Protocol: Choose which protocol to use for live video. RTP Unicast (UDP), RTP Multicast (UDP), or RTP over RTSP (TCP) can be selected. ...

  • Page 20: Privacy Mask

    4.4.2 Privacy Mask  The IP Camera can support the privacy mask feature so a portion of the frame can be blocked based on personal preference of legal requirements. Select the Area and Color and click Save. Note: if the privacy mask is set, the analog output is automatically toggled off.

  • Page 21: Sd Card

    4.5 SD CARD 4.5.1 Config  This section is provided to set up an SD Card for recording images. o SD Card Configuration:  Overwriting: Enable or Disable the SD Card function for recording images.  SD Status: Check the status of the SD Card. ...

  • Page 22: Event

    4.5.2 Event  This page is for configuring whether or not to write images to an SD card when an event occurs. o Event SD Writing:  SD Writing: Choose whether to Enable or Disable this function.  Directory: Input the desired file path on the SD Card for the uploaded images. ...

  • Page 23: Periodical

    4.5.3 Periodical  This page is for configuring whether or not to periodically write images from the camera to an SD card. o Periodical SD Writing:  SD Writing: Choose whether to Enable or Disable this function.  Directory: Input the desired file path on the SD Card for the uploaded images. ...

  • Page 24: Ftp

    4.6 FTP 4.6.1 Config  This section is provided to set-up a FTP (File Transfer Protocol) server so the IP Camera can send recorded images to the server. o Server Configuration:  FTP Server: Enable or Disable the FTP Server function for downloading recorded images. o Client Configuration: ...

  • Page 25: Event

    4.6.2 Event  This page is for configuring whether or not to send images to an FTP server when an event occurs. o Event FTP Sending:  FTP Sending: Choose whether to Enable or Disable this function.  Directory: Input the desired file path on the FTP server for the uploaded images. ...

  • Page 26: Periodical

    4.6.3 Periodical  This page is for configuring whether or not to periodically upload images from the camera to an FTP server. o Periodical FTP Sending:  FTP Sending: Choose whether to Enable or Disable this function.  Directory: Input the desired file path on the FTP server for the uploaded images. ...

  • Page 27: Motion

    4.7.2 Motion  This page is designed to allow for different motion areas to be selected and saved. Select an area and use the mouse to click and drag the desired area, then click Save. 4.7.3 Mapping  This page is designed to allow a user to select whether or not to have a notification sent to specified users if alarm in or/and motion event occurs.

  • Page 28: Network

    4.8 Network 4.8.1 IP Setup  This page allows for current network settings to be configured, specifically the IP Camera’s IP address. The IP Camera supports IP version 4, which allows the IP address to be set automatically via DHCP (Dynamic Host Configuration Protocol) or manually via a Static IP address.
  • Page 29  If a DHCP server is not available on the network, please assign the IP address as follows: o Execute Admintool.exe and click the ‘Search’ button. o Select the camera after it appears in the camera list. o Type in all of the network information. o Click the ‘Apply’...

  • Page 30: Service Port

    4.8.2 Service Port  This page is for setting the IP Camera port numbers. o Service Port:  HTTP Port: Input a desired HTTP (Hyper Text Transfer Protocol port number).  RTSP Port: Input a desired RTSP (Real Time Streaming Protocol port number). o Port Forwarding: ...

  • Page 31: Rtp

    4.8.3 RTP  This page is for defining RTP (Real-Time Transport Protocol) settings for the IP Camera. RTP is used for delivering audio and video over an IP network, including multiple destinations through multicast. o RTP Port Range:  Start Port: Enter the desired Start Port number. ...

  • Page 32: E-Mail

    4.8.4 E-mail  This page allows users to toggle e-mail notification and specify which e-mail server is used. By default, a user can toggle notifications on and the default e-mail server will function without further setting required. o E-mail Setup: ...

  • Page 33: Ddns

    4.8.5 DDNS  This page allows a user to enable or disable DDNS (Dynamic Domain Name System) and select an address to be used for connecting to the IP Camera. o DDNS Setup:  DDNS: Toggle DDNS ON/OFF.  User Set URL: Input a domain name to connect to the IP Camera (for example, http://ipcamera.dvrlink.net) 4.8.6 UPnP ...

  • Page 34: System

    4.9 System 4.9.1 User  This page is for user management: adding new User IDs within a specific group and specifying the user’s password, e-mail address, and whether or not the user should receive e-mail notifications. A user may also be deleted.

  • Page 35: Maintenance

    4.9.3 Maintenance Browse…  This page is for important system maintenance for the IP Camera. o Maintenance:  System Name: Input the desired name for the IP Camera.  System Reboot: Reboots the IP Camera if clicked.  Factory Default: Resets all IP Camera settings to original factory settings if clicked. ...

  • Page 36: Accessory List & Dimensions (Mm)

    Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the security or signaling aspects of this product. UL has only tested for fire, shock or casualty hazards as outlined in UL’s Standard(s) for Safety, UL60065. UL Certification does not cover the performance or reliability of the security or signaling aspects of this product.

  • Page 37: Dimensions (Mm)

    Dimensions (mm)
