Orion Technology X20 Quick Start Manual

3
You should run the activities after installing corresponding Active-X.
3.
If the Active-X installation window does not appear in the top right area for a
4.
long time (longer than 1 minute), change the
Web Viewer
"Control Panel > Internet Options > Security" menu, press [Custom
5.
level...] button.
Select all the ActiveX-related options as available.
6.
Learning the Live screen
\ \
a
b
Internet Options
settings.
" "
Item Name Description
Display
Selected Consists of Live and Setup menu.
a
Tab
You can select in which language the Web
Language
b Viewer is displayed.
Full Screen Displays the image in full screen.
c
c
If selecting Dual Stream, the streams are
d
Stream
shifted in the order of the 1st (the first
e
d
Change
stream) 2nd (the second stream).
<
Playback Starts to transmit the image manually.
e
f g h i j
Digital
Zooms in or out on the screen.
f Zoom
Capture Saves current image as .jpg image file.
g
Panorama Conveniently control PTZ with the Panorama
h
Map Map.
Lens Adjusts the zoom (zoom in/out) and focus of
i Adjustment lens.
Stop Stops transmitting the image manually.
j
Quick Guide
NETWORK IR PTZ CAMERA
(X20/X30)
What's Included
1
\ \
Overview
Camera CD Manual
Cable Sponge L-Wrench (4mm 1ea, 2.5mm 1ea)
At a Glance
\ \
Appearance
a
b
c
Item Name Description
Mount Adaptor Accessory for connecting a camera to a bracket.
a
Zoom Camera Camera with ZOOM LENS.
b
Zoom IR LED IR angle is automatically adjusted by optical zoom. IR LED is on when zoom ratio is above x2.
c
Illumination Sensor Detects incoming light to control the IR LED.
d
Wide angle IR LED IR LED is on when zoom ratio is below x2.
e
Quick Guide BNC Cable
7-position Terminal Block (2ea) Ferrite Core
d
e
