Page 3
Contents 60 pin FPC DELPHI Cable 1 DELPHI Cable 2 AV Cable DELPHI interface a. 1 set RGB input b. 2 setsAV input c. 2 sets AV output (2 Video, 1Audio) d. 1 set rear camera input e. support navigation box...
Page 5
A er removal from vehicle, open the upper cover of headunit View of head unit with upper cover removed Remove screws for cd loader on le and right hand side of headunit Remove screws for cd loader on le and right hand side of headunit Disconnect CD loader ribbon cable Disconnect CD loader ribbon cable ...
Page 6
Open 60pin Ribbon Cable Connector Pull down on Pull down on tab to release tab to release the FPC Ribbon the FPC Ribbon cable cable ...
Page 7
Image of cd loader removed Installa on of Directus Volkswagen Delphi Interface Insert Directus 60 pin ribbon cable into interface make sure to keep blue side of cable up. ( as shown in figure 9 ) Open main Delphi 60 pin ribbon cable connector Pull up on ribbon cable cover Pull up on ribbon cable and remove ribbon cable from connector ...
Page 9
Install Volkswagen Interface into Delphi main 60 pin ribbon cable connector Install Volkswagen Interface into Delphi main 60 pin ribbon cable connector Locate the notched out sec on found on the top right rear corner of the radio casing Using electrical tape , insolate all of the metal corners so that wires will not wear or chafe on casing once installa on Is complete Connect Interface to Delphi unit rou ng all wires through notched out sec on ( as shown in figures 17 & 18 ) Connect Interface to Delphi unit rou ng all wires through notched out sec on ( as shown in figures 17 & 18 ) *To configure dip switches please see figure 31 ...
Page 10
Please make the cable keep as flat as possible for CD Loader install . ...
Page 11
Make sure to keep cables as flat as possible on the bo om and rear of radio to insure sufficient amount of room for reinstall of cd loader. Reinstall cd loader making sure to fully connect cd load ribbon cable. Image of cd loader reinstalled Make all cables are clear from any moving parts and are not being crimped or pinched. Locate the tab on the right rear of the top cover of the head unit Cut tab of or cover as shown in figure 23 &24 ...
Page 13
A ach top cover and reinsert 4 screws for the cd loader on le and right side of head unit Rear image of completed head unit install Rear image of completed head unit install Plug in the RGB/Data cable connector from Prodigy One Plug in the RGB/Data cable connector from Prodigy One Use wiring Diagram in Figure 31 to complete all wiring connec ons ...
Page 17
A er installa on if you find that your Prodigy One screen display is off center ( as shown in figure 1 ) please follow instruc ons below to correct display posi on Press and hold any where on the screen for 10 seconds . A er 10 seconds a hash mark will appear. Press the fist hash mark. Another will appear and press this as well . A total of 5 hash marks will appear during this process press on each one. ...
Page 19
A er all hash marks have been pressed, an arrow le , a check mark and an arrow right will appear. Press the corresponding arrow in the direc on you need the screen to shi Once screen is centered press the check mark ( as shown in figure 5 ) Now that the screen is centered, Once again press and hold any where on the screen. This process will calibrate the touch screen ...
Page 21
Again locate and press all five hash marks Once all hash marks have been pressed the arrow le , check mark and arrow right will be displayed. This me press the CHECK MARK. This completes the process for screen centering and touch calibra on for your Volkswagen and your Prodigy One in now ready to be used ...
