- Page 1 OPERATION AND MAINTENANCE MANUAL Reversible air drill Art. 0418 TRANSLATION OF THE ORIGINAL INSTRUCTIONS...
- Page 2 Manual on the date of issue, listed on this page; however, the machine may be subject to potentially major technical changes in the future, without the Manual being updated. Therefore, contact FERVI for information about modifications that may have been implemented. REV. 2...
-
Page 3: Table Of Contents
HARDWARE CONTENTS GENERAL SAFETY INSTRUCTIONS............. 4 Risks Associated with the Work Area ................4 Risks Associated with the Presence of Rotating and/or Moving Parts......4 Personal Protective Equipment ..................5 Technical Assistance .....................5 DESCRIPTION OF THE DRILL AND INTENDED USE ........6 Technical specifications ....................6 Pictograms ........................7 Identification plate .......................7 IMPROPER USES AND PRECAUTIONS ............ -
Page 4: General Safety Instructions
HARDWARE 1 GENERAL SAFETY INSTRUCTIONS During use, maintain control of the tool. The operators represent the most important aspect of safety. Working cautiously and carefully is the best protection against the risk of injury. The pneumatic tool should not be used and repaired by someone under the influence of drugs or alcohol. -
Page 5: Personal Protective Equipment
HARDWARE 1.3 Personal Protective Equipment When using the pneumatic tool, always wear the following: Safety shoes; Work gloves; Hearing protection Protective goggles. (cap, earplugs, etc.); 1.4 Technical Assistance For any problems and/or concerns, please contact, without hesitation, the Customer Service Department of the dealer, who has specialised staff, specific equipment and spare parts. -
Page 6: Description Of The Drill And Intended Use
HARDWARE 2 DESCRIPTION OF THE DRILL AND INTENDED USE The Air drill is a portable pneumatic tool, to be used for drilling holes in various kinds of material such as wood, metal, plastic, etc. The drill is made up of the following parts (see Figure 1): "Gun"... -
Page 7: Pictograms
HARDWARE 2.2 Pictograms Attached to each machine there is an obligation pictogram: CAREFULLY READ OPERATION MAINTENANCE MANUAL BEFORE USING THE TOOL! Figure 2 – Close-up of the pictograms 2.3 Identification plate There is an identification plate on each machine, which shows the following data: ... -
Page 8: Improper Uses And Precautions
HARDWARE 3 IMPROPER USES AND PRECAUTIONS IT IS STRICTLY FORBIDDEN !! To allow the tool to be used by untrained personnel and those who have not read the instruction manual; To use the tool for different purposes and uses other than those for which it was designed, i.e. -
Page 9: Commissioning
HARDWARE 4 COMMISSIONING 1. Remove the air inlet cap, then screw the supplied nozzle into the hole: 1/4" NPT Male Quick-Release Coupling 2. Put a few drops of lubricating oil (without resin acid) in the air inlet nozzle. 3. Check the flexible air supply hose. If it is damaged, broken, torn or deformed it must not be connected to the tool. -
Page 10: How To Use
HARDWARE 5 HOW TO USE 5.1 Mounting the drill bits Crushing and Cutting Before mounting and/or removing the cutting bits, always disconnect the air supply hose. Protective gloves Before mounting and/or removing the cutting bits, wear suitable protective gloves. 1. Insert a cutting tip (with a diameter between 1.5 mm and 10 mm) inside the spindle. 2. - Page 11 HARDWARE Precautions for use When drilling on small or irregularly shaped objects, secure the work piece in a vice with soft jaws. After mounting the cutting bit and connecting the flexible compressed air supply hose, hold the drill by its "gun" handle. Turn the selector lever to choose the direction of rotation (Ref.
-
Page 12: Maintenance And Cleaning
HARDWARE 6 MAINTENANCE AND CLEANING The purpose of this section is to provide all the information on maintenance procedures and frequency that the drill requires. Frequency INTERVENTION Daily Weekly 1. General visual inspection 2. General cleaning 3. Clean the air outlet nozzle 4. -
Page 13: Bill Of Materials And Spare Parts
HARDWARE 7 BILL OF MATERIALS AND SPARE PARTS Ref. Description Ref. Description 0418/01 Body of the Machine 0418/19 Rear cylinder head 0418/02 Rotation direction lever. 0418/20 Pin 0418/03 Screw 0418/21 Blade 0418/04 O-Ring 0418/22 Rotor 0418/05 Pin 0418/23 Cylinder 0418/06 Trigger...
