Summary of Contents for HPI Racing K5.9 SavageXL

  • Page 5: Exploded View

    Carburetor Factory Setting (Break In Setting) キャブレター工場出荷時設定 (初期設定) High Speed Needle is set flush with groove, Idle Adjustment Screw, Low speed needle and Mid Range Needle are designed to be set flush with the carburetor body. This makes it easy to reset the carburetor to the Factory Break In Setting if needed. 工場出荷時設定...
  • Page 6 Optional Tuning メンテナンス Glow Plug グロープラグ How Glow Plugs Work: Unlike full sized car engines that use spark plugs and a distributor to fire the cylinders in the combustion cycle, glow engines rely on glow plugs. In a Nitro engine, ignition is initiated by the application of a glow igniter.
  • Page 13 Werkseinstellungen des Vergasers (Einlaufphase) Réglage usine du carburateur (réglage de rodage) Alle Nadeln des Vergasers sind so gebaut, dass die Werkseinstellung genau bündig mit dem Vergasergehäuse ist. Dies macht es einfach den Vergaser wieder auf die Grundeinstellung zu bekommen. Le pointeau de haut régime, la vis de ralenti, le pointeau de bas régime et le pointeau de moyen régime sont conçus pour être mis en affleurement avec le corps du carburateur. De ce fait il est facile de remettre le carburateur aux réglages d'usine si nécessaire.
