Flexit S3 R Operating Instructions Manual page 3

15 important Safety instructions
16 Functional Description
16.1 Heating elements
16.2 Operation via Kitchen Hood (S3 R/Sl4 R)
17 Cleaning - Maintenance, S3 R
18 Cleaning - Maintenance Sl4 R
19 Cleaning - Maintenance S4 R/S7 R
20 Fault location
21 Ce Declaration of Conformity
22 Product/environmental Declaration
!
Symbols used
This product has a number of symbols that are used to label the product itself and in the installation and user docu-
mentation. Here is an explanation of some of the commonest symbols.
SUPPLY AIR EXTRACT AIR
OUTDOOR AIR
EXHAUST AIR
Our products are subject to continuous development and we therefore reserve the right to make changes.
CAUtiON: When a text bears this symbol, it means that personal injury
or serious damage to the equipment may follow if the instructions are
not followed.
NB: When a text bears this symbol, damage to equipment or a poor utili-
sation ratio may be the consequence of not following the instructions.
DANGER! ELECTRICITY
DANGER! DO NOT TOUCH
We also disclaim liability for any printing errors that may occur.
TOP
B1
0.5-1 m
3
30
30
30
30
31
32
33
34
35
36
B1
0.5-1 m
BOTTOM
EXAMPLES OF DUCT LOCATIONS
