Page 1: Installation Instructions
Installation Instructions Pedestal Models FS 500 LE FS 800 LE Insert Models IS 500 LE IS 800 LE Pecan Engineering Pty Ltd 13 Acorn Road Dry Creek South Australia 5094 Email info@pecan-eng.com.au Phone: (08) 8349 8332 Fax: (08) 8260 6643... - Page 2 These clearance distances can only be reduced if the installing the appliance. surrounding walls are made of non-combustible material, All Blaze wood heaters have been tested to ensure that they eg. Stone, brick, or concrete. If non-combustible material, will meet the appropriate safety Standard requirements if the distance can be reduced to 100 mm.
- Page 3 Hearth Model Side (Z) width (A) depth (B) 12mm—Clearance Factor = 0.40 FS 500 LE Single layer of continuous material with Minimum Air Gap of FS 800LE 1000 25mm—Clearance Factor = 0.30 (Measurements are in millimetres – mm) Two spaced layers of continuous material with Minimum Air Gap of 12mm + 12mm—Clearance Factor = 0.20...
-
Page 4: Installing The Flue
4. INSTALLING THE FLUE The flue system used when installing the heater MUST comply with the current installation standard AS/NZS 2918. Full instructions on the installation of the flue will be supplied with the flue kit. These MUST be followed closely, including the minimum exit height from the top of the floor protector being not less than 4.6m, and the minimum exit height above the roof line of roof ridge as detailed in the instructions. - Page 5 5. INSTALLING INSERT (IS) MODELS 6. INSTALLING BAFFLE PLATE The dimensions given below for the Blaze IS 500 LE and The baffle plate should be installed before installing the fire bricks. 800 LE models represent the minimum clearance to ...
-
Page 6: Technical Drawings
7. INSTALLING FIRE BRICKS 8. TECHNICAL DRAWINGS FS 500 LE & IS 500 LE – Brick Layout Model – FS 500 LE 1) Place two full size (235 x 175 x 25) and one (235 x 140 x 25) along the back... - Page 7 Model – IS 500 LE Model – IS 800 LE...
