Your Printer - LabelTac 6 Reference Manual

Your Printer

Ribbon Rewind
Spindle
Ribbon Supply
Spindle
Print Head Pressure
Adjustment Knobs
Media Sensor
(green fork)
Gap Sensor
(green square)
Ribbon Guide Bar
Alignment
Guide
Not Pictured / Not Visible: Ribbon Sensor (black fork), Platen Roller (black roller)
Parallel Port
USB 2.0 Port
RS-232C Port
Power Jack Socket
4 Unboxing
Rear Panel
Your Printer
Label Supply
Spindle
Supply Alignment
Wing
Media Guide Bar
Print Head Release
Lever
SD Card Slot
Ethernet Port
PS/2 Port
Power Switch
