OPERATOR'S MANUAL
18 GAUGE BRAD NAILER
H125BN
Your brad nailer has been engineered and manufactured to Husky's high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for buying a Husky product.
SAVE THIS MANUAL FOR FUTURE REFERENCE

Advertisement

Table of Contents
loading

Related Manuals for Husky H125BN

Summary of Contents for Husky H125BN

  • Page 1 OPERATOR’S MANUAL 18 GAUGE BRAD NAILER H125BN Your brad nailer has been engineered and manufactured to Husky’s high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS  Introduction..................................  General Safety Rules ...............................3  Specific Safety Rules ..............................4-5  Symbols ...................................6  Glossary of Terms ................................7  Features ..................................8-9  Assembly ..................................9  Operation ................................. 10-16  Maintenance ..................................17  Accessories ...................................18  Troubleshooting ................................18  Warranty ..................................19  Customer Service Information .........................

  • Page 3: General Safety Rules

    GENERAL SAFETy RULES  Do not overreach. Keep proper footing and balance DANGER: at all times. Proper footing and balance enables better control of the tool in unexpected situations. READ AND UNDERSTAND TOOL LABELS AND  Use safety equipment. Always wear eye protection. MANUAL.

  • Page 4: Specific Safety Rules

    SPECIFIC SAFETy RULES OPERATION  Know your pneumatic tool. Read operator’s manual carefully. Learn its applications and limitations, as well  Always assume that the tool contains fasteners. as the specific potential hazards related to this tool.  Do not carry the tool from place to place holding the Following this rule will reduce the risk of electric shock, trigger.

  • Page 5: Specific Safety Rules

    SPECIFIC SAFETy RULES  Do not drive fasteners on top of other fasteners or with  Always disconnect air supply: the tool at an overly steep angle as this may cause • Before making adjustments deflection of fasteners which could cause injury. •...

  • Page 6: Symbols

    AUTHORIZED SERVICE CENTER for repair. When servicing, do not understand the warnings and instructions in the use only identical replacement parts. operator’s manual, do not use this product. Call Husky customer service for assistance. WARNING: The operation of any power tool can result in foreign objects being thrown into your eyes, which can result in severe eye damage.

  • Page 7: Glossary Of Terms

    GLOSSARy OF TERMS Activate (operating controls) Operating control To move an operating control so that it is in a position that A control that separately, or as part of an actuation system, allows the tool to be actuated or that satisfies one requirement can cause the actuation of a tool.

  • Page 8: Features

    FEATURES PRODUCT SPECIFICATIONS Operating Pressure..........70-10 psi Air Inlet .............. 1/4 in. NPT Fastener Type ........18 gauge brad nails Weighted sound impulse power level ....97.3 dBA Emission sound pressure level ......84.3 dBA Fastener Range ........5/8 in. to 1-1/4 in. Magazine Capacity ..........100 nails Vibration ...............3.08 m/s Air Consumption......

  • Page 9: Assembly

    FEATURES DUST CAP KNOW yOUR BRAD NAILER See Figure 1. The dust cap helps prevent dust and debris from entering The safe use of this product requires an understanding of the the air fitting. Cover the air fitting with the dust cap when not in use.

  • Page 10: Operation

    OPERATION APPLICATIONS DANGER: You may use this tool for the purposes listed below: Do not use oxygen, combustible gases or bottled gases  Finish and Trim (Interior and Exterior) as a power source for this tool. The tool will explode and ...
  • Page 11 OPERATION WARNING: DUST CaP Always wear eye protection. Eye protection does not fit all operators in the same way. Make sure the eye protection chosen has side shields or provides protection from flying debris both from the front and sides. PREPARING THE TOOL FOR USE See Figure 2.
  • Page 12 OPERATION ADJUSTING THE EXHAUST aDJUSTaBlE See Figure 5. EXHaUST The adjustable exhaust on the top cap of the tool allows the operator to direct the exhaust according to operator preference. To adjust, turn the exhaust cap until the exhaust blows in the desired direction. WARNING: Disconnect the tool from the air supply before leaving the work area, moving the tool to another location, or handing...
  • Page 13 OPERATION LOADING THE TOOL WITH NAILS See Figures 7 - 8.  Connect the tool to the air supply. WARNING: The tool’s driving mechanism may cycle when the tool is first connected to the air supply. Always connect the tool to the air supply before loading nails to prevent injury from unintended cycling.
  • Page 14 OPERATION DRIVING A FASTENER See Figure 9. WARNING: Never wedge or hold back the workpiece contact mechanism during operation of the tool. Doing so could result in possible serious injury. SINGLE SEQUENTIAL ACTUATION TRIggER Single sequential actuation provides accurate fastener placement.
  • Page 15 OPERATION DRIVE DEPTH ADJUSTMENT See Figure 10. DRIVE DEPTH The driving depth of the nail may be adjusted. It is advisable aDJUSTmEnT to test the depth on a scrap workpiece to determine the required depth for the application. To DECREaSE To determine depth of drive, first adjust the air pressure and DEPTH drive a test nail.

  • Page 16: Operation

    OPERATION WARNING: Disconnect the tool from the air supply before clearing a jammed fastener. Failure to do so could result in serious personal injury. CLEARING A JAMMED FASTENER See Figure 12. If a nail or fastener becomes jammed in the tool, disconnect the air hose and keep the tool pointed away from you while clearing the jam.

  • Page 17: Maintenance

    MAINTENANCE NOTE: Some commercial air line drying liquids are harmful WARNING: to “O” rings and seals. Do not use these low temperature air dryers without checking compatibility. When servicing use only identical replacement parts. Use of any other parts may create a hazard or cause AIR SUPPLy PRESSURE AND VOLUME product damage.

  • Page 18: Accessories

    ACCESSORIES To order parts and maintenance kits, call 1-866-340-391. Overhaul Kit ..............................07907004701 Driver Maintenance Kit .............................0790700470 Driver Assembly Kit ............................07907004703 Oil and Wrench Kit............................07907003700 WARNING: Current attachments and accessories available for use with this tool are listed above. Do not use any attachments or accessories not recommended by the manufacturer of this tool.

  • Page 19: Warranty

    WARRANTy LIMITED WARRANTy STATEMENT One World Technologies, Inc. reserves the right to change or improve the design of any One World Technologies, Inc. One World Technologies, Inc. warrants to the original retail product without assuming any obligation to modify any purchaser that this One World Technologies, Inc.
  • Page 20 OPERATOR’S MANUAL 18 GAUGE BRAD NAILER H125BN • SERVICE Now that you have purchased your tool, should a need ever exist for repair parts or service, simply contact your nearest Authorized Service Center. Be sure to provide all pertinent facts when you call or visit. Please call 1-866-340-391 for your nearest Authorized Service Center.
