- Page 1 DEHUMIDIFIERS www.refine-dehumidifiers.com Armored 70L Installation and Operations Manual Refine Dehumidifiers P: +86-574-55841701 +86-574-55841702 E-mail: sales@refine-tec.com Add: NO.8, Mo gan shan Road,Beilun,Ningbo,Zhejiang,China...
-
Page 2: Safety Notes
The Refine Dehumidifiers must be maintained and serviced by qualified technicians. Ÿ The Refine Dehumidifiers are intended for use only when the unit is installed in a level Ÿ and upright position. Operating the unit in any other position could cause water to come in contact with the electrical components. -
Page 3: Table Of Contents
For future reference, write down the model, serial number, and date of purchase so you can identify your unit when seeking assistance. NOTE: data label on back of unit includes Warranty............................17 serial number. Model Number Armored 70L Serial Number__________________________ Date of Purchase__________________________ Customer Service: For additional questions concerning the operation of your dehumidifier,... -
Page 4: How Your Armored Dehumidifier Works
How Your Armored Dehumidifier Works ※ Front View The Refine Armored Series Dehumidifier utilizes either its integral humidistat to monitor the conditioned space or a manual on/off control to energize the compressor when needed. Air is drawn across an evaporator coil. The evaporator coil is cooler than the dew point of the air so water vapor will turn into liquid condensation. -
Page 5: Operating Instructions
REFINE-DEHUMIDIFIERS REFINE-DEHUMIDIFIERS Timer setting:Timing for the start/Timing Shutdown/Cycle Timing ※Operating instructions※ Temperature Scale Switch:Degrees Celsius or Fahrenheit selection Return:Return to display the main page NOTE: See Section 8 for more detailed programming instructions. Select/OK Drain Pump 4. Select/OK Button Menu On/Off Use to confirm a selection. - Page 6 REFINE-DEHUMIDIFIERS REFINE-DEHUMIDIFIERS Time remaining to Auto opening i m e H u m i 5 0 % Time remaining to Auto Closing （ ） When you press the Power Offbutton, two lines of data will be displayed. The top i m e line will read “Unit Off”.
- Page 7 REFINE-DEHUMIDIFIERS REFINE-DEHUMIDIFIERS H u m i i m e 16 hours. Note: You are selecting on and off periods of time, not set clock times. T e m p U a. Press the M button until the T.I/O selection is flashing. Press OK button to select.
-
Page 8: Preparing The Unit For Use
REFINE-DEHUMIDIFIERS REFINE-DEHUMIDIFIERS the unit features an integral drain pump, drain line may go vertically up 18’prior to reaching final drain location. Discharge Ducting The quick connector into 10.Handlebar Mounting Quick connection to draining tube the socket on the connector Handle rotates 180 °, after aligning with locating pin holes will be fixed. -
Page 9: Maintenance
The filter insert the filter box then close the wind panel ※Maintenance Your Refine Armored is equipped with an integral Pump condensate pump designed to pump condensate from Open the rear cover and your dehumidifier out to the desired drain. -
Page 10: Storing Your Dehumidifier
REFINE-DEHUMIDIFIERS REFINE-DEHUMIDIFIERS 1 year parts warranty. Only a defective pump will be repaired or replaced during the Coil- warranty period. If necessary, clean your coils with a vacuum or approved coil cleaner. Preventative Maintenance ※ Storing Your Dehumidifier ※ As with all pumps, preventative maintenance is necessary to prevent issues from dirt and slime that may accumulate in the drain system –... -
Page 11: Warranty
Refine shall not be responsible for loss of use of any product, loss of time, inconvenience, or damage to other equipment, or any other indirect or consequential damage with respect to property whether as a result of breach of warranty, neglect, or otherwise. - Page 12 REFINE-DEHUMIDIFIERS The foregoing shall constitute the total liability of seller in the case of defective performanceof all or any of the equipment or services provided to Buyer. Buyer agrees to accept and hereby accepts the foregoing as the sole and exclusive remedy for any breach or...
