Summary of Contents for Wagan Power Dome NX 2485
- Page 1 Item No. : 2485 Power Dome ® User’s Manual We are constantly improving our products so specifications are subject to change without notice. Visit our website for the latest product information.
-
Page 3: Table Of Contents
Turning On and Tuning the Radio ..................14 Adjusting the Volume ..................... 14 Setting Radio Station Presets ..................14 3�5mm Audio Input ������������������������������������������������������������������������������������������������������������������ 15 Setting the Clock ���������������������������������������������������������������������������������������������������������������������� 15 Troubleshooting������������������������������������������������������������������������������������������������������������������������ 16 ©2015 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks used by Wagan Corporation. -
Page 4: Important Information
Power Dome NX by Wagan Tech ® ® Thank you for purchasing the Power Dome NX by Wagan Tech . With normal care and proper ® ® treatment it will provide years of reliable service. IMPORTANT INFORMATION • Please read and understand all warnings, cautions, and notes included in this manual before using the Power Dome NX. -
Page 5: Product Features
Charging Time (DC—with engine running) 12 hours Dimensions WxLxH (inches) 10.5 x 14.0 x 12.0 Weight (lb) 14.6 AC Charging Adapter Output 12V, 300mA DC ©2015 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks used by Wagan Corporation. -
Page 6: Front View
Power Dome NX by Wagan Tech ® ® FRONT VIEW 1. Extendable Antenna 4. Radio/Clock LCD Screen 2. Jumper Safety Switch 5. Speakers 3. Red Positive (+) Jumper Cable 6. Radio/Clock Control Panel 7. Audio Input Jack 8. Storage Compartment Audio device and audio input cable not provided. -
Page 7: Rear View
16. DC/USB Switch 27. Air Compressor Hose 17. USB Power Port 28. Red Positive (+) Jumper Cable 18. DC Output Socket 19. Hazard Flasher Lens ©2015 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks used by Wagan Corporation. -
Page 8: Battery Status
Power Dome NX by Wagan Tech ® ® BATTERY STATUS The voltmeter provides the current state of charge on the internal battery. It is the user’s responsibility to periodically monitor the battery’s status and recharge every 3 months in addition to recharging after each use. -
Page 9: Jumpstarter
(NEG, N, −) terminal. If you are unsure, you should refer to the vehicle owner’s manual. ©2015 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks used by Wagan Corporation. -
Page 10: Air Compressor
Power Dome NX by Wagan Tech ® ® 6. Determine the ground system of your vehicle. • If vehicle to be started has the positive battery terminal connected to chassis (this is rare and usually found in older car models from the 1950s or earlier): a. -
Page 11: Power Inverter
2. Prior to plugging in your device, turn your power tool or appliance off. Mobile devices are fine to keep on, but operating them during the charging process will prolong charging time. 3. Open the AC outlet dust cover. ©2015 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks used by Wagan Corporation. -
Page 12: Dc Output Socket
Power Dome NX by Wagan Tech ® ® 4. Connect the electrical plug of your device/appliance to either of the two AC outlets. 5. Set the Inverter Switch to the “|” position. 6. Observe the Inverter Power Indicator. If the LED remains green, proceed to plugging in and turning on the second device/appliance. -
Page 13: Work Light
If you are operating the Power Dome’s inverter and noise is being received on the AM band, turn off the inverter or change the radio to receive an FM frequency. ©2015 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks used by Wagan Corporation. -
Page 14: Turning On And Tuning The Radio
Power Dome NX by Wagan Tech ® ® CH + LCD screen Power & VOL + AM/FM Memory VOL − Audio Input CH − Turning On and Tuning the Radio NOTE: Power Button (PWR) and AM/FM Button are the same button, but with two functions. -
Page 15: 3�5Mm Audio Input
5. When your local or desired time is set, tap the MEMORY button again to confirm the new clock time and the LCD screen will return to regular cock mode. ©2015 Wagan Corporation. All Rights Reserved. Wagan Tech and wagan.com are trademarks used by Wagan Corporation. -
Page 16: Troubleshooting
Power Dome NX by Wagan Tech ® ® TROUBLESHOOTING Problem Cause Solution Air compressor shut-off. High temperature Allow the Power Dome cool for about 10 minutes. protection. Lack of power output. Power Dome battery Recharge the Power Dome immediately. voltage is below 10 volts. -
Page 17: United States
Product is warranted to the original purchaser for a period of one (1) year from the original purchase date, to be free of defects in material and workmanship. WAGAN Corporation disclaims any liability for consequential damages. In no event will WAGAN Corporation be responsible for any amount of damages beyond the amount paid for the product at retail. - Page 20 31088 San Clemente Street Hayward, CA 94544, U.S.A. Tel: +1.510.471.9221 U.S. & Canada Toll Free: +1.800.231.5806 customerservice@wagan.com www.wagan.com ©2015 Wagan Corporation. All Rights Reserved Wagan Tech and wagan.com are trademarks used by Wagan Corporation REV20151217-E...
