- Page 1 HTP‐T800 H.264 VIDEO SERVER User Manual Ver. 1.0...
- Page 2 We appreciate your purchasing HTP-T800. Before installing the product, please read the following with care. Make sure to turn off the power before installing HTP-T800. Do not install under the direct sunlight or in dusty areas. Make sure to use the product within the temperature and humidity specified in the specification.
-
Page 3: Table Of Contents
HTP-T800 User Manual Table of Content Table of Content ........................... 2 1. Introduction ............................4 1. About User Manual........................4 2. Feature............................4 3. Product and Accessories ......................6 4. Part Names and Description...................... 7 5. System Modes and Connections ....................8 2. - Page 4 HTP-T800 User Manual 3. Server Connection Management ..................... 48 4. Server Status Monitoring ......................48 5. Network and System Diagnostics .................... 49 6. F/W Upgrade ........................... 52 7. Remove Configuration and Video Monitoring ................53 6. Trouble Shooting ..........................53 Appendix A: Sensor and Alarm Port ....................
-
Page 5: Introduction
HTP-T800 2. Feature HTP-T800 is a video and audio surveillance transmission system based on IP network through LAN, ADSL/VDSL, and Wireless LAN. The HTP-T800 series operates as one of the two modes: Encoder, Decoder. Encoder system compresses and transmits video data. Decoder receives and decompresses the video data. - Page 6 HTP-T800 User Manual Sensor and Alarm Support direct connections of external sensor and alarm devices. Event Alarm Connection to internal or external USB storage for remote access User Interface System status display utilizing OSD(On Screen Display) Diagnose and upgrade through dedicated program called True Manager...
-
Page 7: Product And Accessories
HTP-T800 User Manual 3. Product and Accessories HTP-T800 System Quick Manual Power adaptor and cable User Manual & S/W CD Screws Brackets <Picture 1> Product and Accessories... -
Page 8: Part Names And Description
HTP-T800 User Manual 4. Part Names and Description Front View Parts Function LEDs Display power On/Off condition, Link, Status and data Audio In, Out Audio Input and Output HDMI Output HDMI Output USB port for any USB device LAN(Ethernet) 100/10-base-T Ethernet interface... -
Page 9: System Modes And Connections
Reset button for network reset 5. System Modes and Connections The HTP-T800 system operates in one of two modes: Encoder, Decoder. HTP-T800 systems can be connected in either 1-to-1 fashion where one encoder is connected one decoder or 1-to-many fashion... - Page 10 HTP-T800 User Manual Following chart shows possible combinations of video, audio and serial data transmission. System Mode Video Audio Serial Data Encoder Transmit Transmission/Receive Transmit/Receive Decoder Receive Transmission /Receive Transmit/Receive Therefore, the system modes are defined by the video communication and all system modes are capable of bi-directional transmission of audio or serial data.
- Page 11 HTP-T800 User Manual Remote Center Site Decoder Encoder Decoder Decoder In this configuration, a site can be monitored from many remote center locations. Although up to 64 decoders can be connected to on encoder, in the real network environment, network bandwidth can limit the maximum connections.
- Page 12 HTP-T800 User Manual Site Remote Center Encoder Site Remote Center Encoder Decoder CMS (Central Monitoring System) is a Windows based remote monitoring program to access multiple encoders for real-time monitoring or control of the encoders and connected cameras. Please refer to CMS User Manual for more information on CMS.
-
Page 13: Installation
HTP-T800 User Manual 2. Installation 1. Connecting Video Encoder System Connect camera video output line to the encoder (HTP-T800) video input port. Decoder System Connect monitor video input line to the decoder (HTP-T800) video output port. 2. Connecting Audio Audio is bi-directional in any configuration regardless of the system mode. If necessary, it can be configured to be in transmit-only, receive -only or bi-directional mode. -
Page 14: Checking Operating
HTP-T800 User Manual 6. Checking Operating Once the power is supplied to the camera, it will start booting. The system will boot up to an operating mode after approximately 40-60 seconds. The green LED on the Ethernet port will flash indicating the system is ready. -
Page 15: System Operation
HTP-T800 User Manual 3. System Operation 1. LED Display Description of LEDs System status can be monitored with LEDs. State Description No power Power on Green blinking Normally operating System failure: Needs diagnostics Constant change of colors NTSC/PAL setting does not match with input... - Page 16 HTP-T800 User Manual Video Monitoring using Internet Explorer If HTP-T800’s IP address in entered on the Internet Explorer, the system will ask for confirmation to install Active-X control. Once authorized, the Internet Explorer will start to display video images from the encoder as shown below.
-
Page 17: Initialization Of Ip Address
Focus Near, Focus Far, Auto Focus Adjust the focus Sensor Input When the sensor on the HTP-T800 is connected and working, the light turns red. Alarm Output Alarm Output button can trigger an event directly from the Live View page. - Page 18 HTP-T800 User Manual - Http port : 80 -17-...
-
Page 19: Remote Configuration
4. Remote Configuration 1. Remote Configuration The server can be configured using web browser. Type IP address of HTP-T800 in the address input area of Internet Explorer, then a live viewing screen will be displayed. Press Setup button located in the upper right area of the monitoring screen, then the se page for server setup will be displayed. -
Page 20: System Configuration
HTP-T800 User Manual 2.1 System Configuration System Mode System mode: Select Encoder, Decoder. System ID System ID: Alphanumeric System ID to be transferred to remote software -19-... - Page 21 Language to be used for web-based configuration Firmware version Current firmware version Board ID Network board ID of HTP-T800 recognized by system Start Time Latest system boot date and time Current Time Current date & time: Enter a new date and time and press Set Current Time button to update date &...
-
Page 22: Video Configuration
HTP-T800 User Manual 2.2 Video Configuration -21-... - Page 23 HTP-T800 User Manual - ENCODE Input Format Select input format ; Composite NTSC or PAL Resolution Selectable video compression resolution as below: NTSC : 720 x 480, 720x 240, 352 x 480, 352 x 240 PAL : 720 x 576, 720 x 288, 352 x 576, 352 x 288 Frame Rate Select video frame rate (the maximum number of frames of video images to compress.)
- Page 24 HTP-T800 User Manual - DUAL ENCODE Use Dual Encode Select On to use dual encode Dual Encode Algorithm H.264 and MJPEG can be selected for secondary streaming. Maximum resolution is 720 x 480 and there are 8 steps of resolution. If MJPEG is selected, Preference supports only Quality mode.
- Page 25 HTP-T800 User Manual Sensitivity A condition to trigger an event of motion detection. The value determines the sensitivity of the motion detection within a block: the smaller, the more sensitive. It is selectable from from 0 to 10. Information Display System ID and/or server time can be display over the video window in Web View.
-
Page 26: Audio Configuration
HTP-T800 User Manual 2.3 Audio Configuration Mode Select audio operation mode. Mode Status No operation TX-Only Transmit only RX-Only Receive only TX & RX Transmit and Receive Input Gain Set audio input gain. -25-... -
Page 27: Network Configuration
HTP-T800 User Manual 2.4 Network Configuration -26-... - Page 28 RTSP port used for RTSP-based connection SNMP HTP-T800 can be used as an SNMP agent. It is compatible to both SNMPv1 and SNMPv2c. Vender specific MIBs for IP camera/server are defined. SNMP listen port can be set and disabled when it is 0. SNMP trap is also supported. Destination IP and port can be set. If one of these values is 0, SNMP trap will be disabled.
- Page 29 HTP-T800 User Manual - True DNS : use True DNS service. Systems can be registered on the website for TrueDNS service: http://ns1.truecam.net. System will get a domain name of xxx.truecam.net style. Refer to the user guide document for True DNS service.
-
Page 30: Serial Port Configuration
HTP-T800 User Manual 2.5 Serial Port Configuration -29-... - Page 31 HTP-T800 User Manual Serial Port Configuration There are two serial ports, (COM1 and COM2) in HTP-T800. While COM1 port is fixed to RS- 232C, COM2 port can be set to RS-422 or RS-485 protocol. The serial ports can be configured as follows.
- Page 32 HTP-T800 User Manual -31-...
-
Page 33: Event Configuration
HTP-T800 User Manual 2.6 Event Configuration -32-... - Page 34 HTP-T800 User Manual The event configuration configures the actions for each event type. Local section configures the actions for events from local(self) system, and configuration activates local devices and Remote sections configures the actions for events from remote(peer) system. The following table lists the possible actions for events.
- Page 35 HTP-T800 User Manual entered by delimiting comma(,) or semi-colon(;). Destination address can take up to 63 characters. Video clip of AVI file format at the moment of the event can be attached by setting Video Clip Attaching. FTP Upload Specify the information for uploading video file as the action of an event. The address of an FTP server to receive video files is specified on Server Address field, and Port specifies the port for FTP operation (Port 21 is the default port in FTP operation.
-
Page 36: Preset Configuration
HTP-T800 User Manual 2.7 Preset Configuration Preset Name Move PTZ Camera to normal view Press Set Button Save Configure up to 15 preset positions. Preset function is not available on some PTZ receivers. Make sure to check if a PTZ receiver supports preset. -
Page 37: User Configuration
HTP-T800 User Manual 2.8 User Configuration User can be registered and privilege level of a user can be specified. User configuration is allowed only to admin user. Max 16 users can be registered and each user can have one of f our privilege. - Page 38 HTP-T800 User Manual User ID and password need to be entered and privilege level need to be selected. User ID and password consist of alphanumeric string of max 15 characters. Delete User A user is deleted by pressing Delete button.
- Page 39 HTP-T800 User Manual password. In case changing admin password, old password is checked. Modify Privilege Level Pressing Modify Privilege button after selecting a user shows a page for changing the privilege. It is not allowed to change the privilege level of admin user.
-
Page 40: Decoder System
HTP-T800 User Manual 3. Decoder System Once system mode is changed as decoder, Firmware version shows Dec xxxxxxx which means decoder mode. -39-... -
Page 41: Video Configuration
HTP-T800 User Manual 3.1 Video Configuration Regardless input resolution of Encoder or IP camera, Decoder system of HTP-T800 can display video format as follows; Composite NTSC & HDMI 480i (720 x 480) Composite PAL & HDMI 576i (720 x 576) HDMI &... -
Page 42: Network Configuration
HTP-T800 User Manual 3.2 Network Configuration Network page of Decoder has a section for specifying the remote system to connect. -41-... - Page 43 HTP-T800 User Manual Remote Address Address of the remote system to connect. Remote Channel The channel can be selectable when the remote system has more than multiple video channels. Media Protocol Protocol used for delivery of audio and video data between remote system and Decoder.
-
Page 44: Event Configuration
HTP-T800 User Manual 3.3 Event Configuration The event configuration configures the actions for each event type. Local section configures the actions for events from local (self=Decoder) system, and configuration activates local devices and Remote sections configures the actions for events from remote (Encoder or IP Camera) system. - Page 45 HTP-T800 User Manual single event. On Video Loss Configure the actions when video input signal is lost. Multiple actions can be set for a single event. On Motion Configure the actions when motion is detected. Multiple actions can be set for a single event.
-
Page 46: True Manager
HTP-T800 User Manual 5. True Manager 1. True Manager Software True Manager is a program used for basic configuration, diagnostics and F/W upgrade of video servers or IP cameras. True Manager provides the following features. - Finding servers on the LAN and assigning IP address - Monitoring server status: encoding/decoding, serial, sensor etc. - Page 47 HTP-T800 User Manual If the server is registered on DDNS server, domain name can be used instead of IP address. When the IP address of the server is forgotten, it is possible to find the IP address of the server with IP Discovery function.
- Page 48 HTP-T800 User Manual If you press Select button after selecting a server, the information for the server is automatically entered on Add Server dialog. Pressing IP Change button after selecting a server invokes a dialog on which IP address of the server can be changed.
-
Page 49: Server Connection Management
HTP-T800 User Manual 3. Server Connection Management Server connection If the check box on the first column in Servers (or Channels/Peripheral) tab, True Manager tries to connect to the server. If the server is running and the network to the server is normal, it will be connected immediately and State will be changed to Connected. -
Page 50: Network And System Diagnostics
HTP-T800 User Manual V-E(fps) Video encoding framerate V-D(kbps) Video decoding bitrate V-D(fps) Video decoding framerate A-E(kbps) Audio encoding bitrate A-D(kbps) Audio decoding bitrate Depending on the system mode, items which are not relevant to the mode may display 0 always. For example, V-D(kbps) and V-D(fps) are always 0, if the system mode is Encoder. - Page 51 HTP-T800 User Manual Server executing Ping Destination of Ping Ping test is useful for checking if one or more remote systems are reachable from a server. Up to 4 systems can be registered as the targets of Ping test, which makes it possible to identify the hop (segment of network) where network failure may happen.
- Page 52 HTP-T800 User Manual identifying the reason why video quality comes poorer than expected. TCP protocol can be selected for measuring effective bandwidth, while UDP protocol is appropriate for checking if the network is not reliable. System test Selecting System Test on Tools menu invokes a dialog on which system H/W status, video/audio output function and serial ports can be diagnosed.
-
Page 53: F/W Upgrade
HTP-T800 User Manual Viewing server’s log The log in a server can be viewed by selecting Log on Tools menu. Remote rebooting of a server A server can be rebooted by selecting Reboot on Tools menu. 6. F/W Upgrade When Update is selected on Tools menu, the dialog for F/W upgrade comes. -
Page 54: Remove Configuration And Video Monitoring
HTP-T800 User Manual Select an upgrade file. Press Upgrade button. Wait until Progress is changed to Upgrade succeeded. Caution: Don’t power-off the server while upgrade is in progress. The server may go to irrecoverable state. When network condition is poor, upgrade may fail. In such case, please retry above procedure after network condition is recovered. -
Page 55: Appendix A: Sensor And Alarm Port
HTP-T800 User Manual Appendix A: Sensor and Alarm Port 1. Sensor Port Terminal Type * Voltage Rating: 150VAC * Current Rating : 2A * Color : Red Sensor Signal Input Type * NO Contact Signals Connection to External Device 2. Alarm Port... -
Page 56: Appendix B: Serial Port
HTP-T800 User Manual Connection to External Device Appendix B: Serial Port 1. RS-232 Port Port Type * 3 PIN * Pin Arrangement * Pin Description Pin NO Pin Name Description RS232 TX(Transmit) RS232 RX(Receive) Ground 2. RS-422/485 Port Port Type... -
Page 57: Poe Specification
HTP-T800 User Manual * 4 PIN * Pin Diagram * Pin Description Pin No. Pin Name Description RS422 RX- RS422 RX+ RS422 TX- or RS485 TRX- It is selectable by S/W Setup RS422 TX+ or RS485 TRX+ It is selectable by S/W Setup 3. - Page 58 HTP-T800 User Manual 1500V isolation (input to output) PoE must be protected from over-voltages exceeding the 80V maximum rated surge input voltage Recommended Operating Conditions Parameter Units DC Supply Voltage DC Voltage Lockout Ta/°C Operating Temperature DC Electrical Characteristics Parameter...
