Lezeti ACDC12B Installation Manual

Solar air conditioner heat pump
Hide thumbs Also See for ACDC12B:

Advertisement

INSTALLATION GUIDE

MODEL: ACDC12(B)
Version 1.0
© 2015 CLIMA-TEKNOLOGIES, LLC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACDC12B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lezeti ACDC12B

  • Page 1: Installation Guide

    INSTALLATION GUIDE MODEL: ACDC12(B) Version 1.0 © 2015 CLIMA-TEKNOLOGIES, LLC...
  • Page 2: Installation Manual

    ACDC12B Solar Air Conditioner Heat Pump Installation Manual Before installing or using your solar air conditioner, please print and read this manual carefully and keep it for future reference. Notice To Owner/Installer This unit is designed for easy installation by an experienced person. It is legal for a homeowner to install it, however we highly recommend using a licensed HVAC technician for installation.
  • Page 3: Warning

    INSTALLERS, Please read the following warnings to prevent voiding warranties: WARNING: Make sure the PV panels are wired in PARALLEL, NOT SERIES. Verify voltage is within range prior to connecting to the ODU DC breaker. WARNING: Voltage from breaker box to ODU disconnect should be 220V (measured between L1 and L2.) See page 13, figure 24.
  • Page 4: Table Of Contents

    Table of Contents SAFETY PRECAUTIONS Warning ..............................4 Caution ..............................4 INSTALLATION INSTRUCTIONS ........................5 Selecting installation location ..........................5 Indoor unit installation ..........................5 Outdoor unit installation REFRIGERANT PIPE CONNECTION ........................10 Refrigerant pipe connection ELECTRICAL WORK Electrical work ............................ 12 ..................14 Installation of the solar photovoltaic system AIR PURGING ......................
  • Page 5 SAFETY PRECAUTIONS  Read the follow SAFETY PRECAUTIONS carefully before installation.  Installation must be performed in accordance with the requirement of NEC and CEC by authorized personnel only.  Incorrect installation due to ignoring of the instruction will cause harm or damage. ©...
  • Page 6: Installation Instructions

    Installation Instructions Select an installation location which is rigid and strong enough to support or hold the unit, and select a location for easy maintenance. Read completely, follow instructions step by step. Indoor Unit Fig. 1  Do not expose the indoor unit to heat or steam. ...
  • Page 7 Rooftop installation:  If the outdoor unit is installed on a roof structure, be sure to level the unit.  Ensure the roof structure and anchoring method is adequate for the unit location. Consult local codes regarding rooftop mounting. Recommended Tools For Installation: Level gauge Hex Wrench 5mm Screwdriver...
  • Page 8: Indoor Unit Installation

    INSTALLATION INSTRUCTIONS Indoor unit installation 1. Fit the Installation Plate Fit the installation plate horizontally on a structurally sound part of the wall with spaces around the installation plate. If the wall is made of brick, concrete or the like use anchor bolts.
  • Page 9: Caution

    INSTALLATION INSTRUCTIONS  Never intercross or intertwist the power wire Connective Pipe and Drainage Installation with any other wiring. 6. Run the drain hose sloping downward. Do not install the drain hose as illustrated in Fig.7. When connecting extension drain hose, insulate the connecting part of extension drain hose with a shield pipe, do not let the drain hose slack.
  • Page 10: Outdoor Unit Installation

    Outdoor Unit installation Outdoor installation precaution Install the outdoor unit on a rigid base to prevent increasing noise level and vibration. Determine the air outlet direction where the discharged air is not blocked. In the case that the installation place is exposed to strong wind such as a seaside, make sure the fan operating properly by putting the unit lengthwise along the wall or using a dust or shield plates.
  • Page 11: Refrigerant Pipe Connection

    REFRIGERANT PIPE CONNECTION 4. Cut the cable 1.5m longer than the pipe length. B: Burr removal Installation of Outdoor Unit 1. Completely remove all burrs from the cut  Anchor the outdoor unit with a bolt and cross section of pipe/tube. nut # 10 or # 8 tightly and horizontally 2.
  • Page 12: Tightening Connection

    Tightening Connection  Align the center of the pipes.  Sufficiently tighten the flare nut with fingers, and then tighten it with a spanner and torque wrench as shown in Fig.20 & 21.  Excessive torque can break nut depending on installation conditions. ©...
  • Page 13: Electrical Work

    Electrical work Electric safety regulations for the initial Installation 1. If there is serious safety problem about the power supply, the technicians should refuse to install the air conditioner and explain to the client until the problem is solved. 2. Power voltage should be in the range of 90%~110%of rated voltage. 3.
  • Page 14 Connecting the cable to the indoor unit NOTE: Before performing any electrical work, turn off the main power to the system. 1. The inside and outside connecting cable can be connected without removing the front grille. 2. The indoor power cord type is H05VV-F or H05V2V2-F, the outdoor power cord and interconnected cord type is H07RN-F.
  • Page 15: Installation Of The Solar Photovoltaic System

    ELECTRICAL WORK Installation of the solar photovoltaic system  This guide contains information regarding the installation and safe handling of solar photovoltaic module. All instructions should be read and understood before attempting to install. If there is any question, please contact our support department for further explanation. The installer should conform to all the safety precautions listed in this guide when installing the module.
  • Page 16 When disconnecting wires from a photovoltaic module that is exposed to sunlight, an electric arc may result. Such arcs may cause burns, combustion and may otherwise create problems. Therefore, be extremely careful! Photovoltaic solar modules convert light energy to direct-current electrical energy. They are designed for outdoor use.
  • Page 17 Solar modules produce electrical energy when light strikes on their front surface. The DC voltage may exceed 30V. If modules are connected in series, the total voltage is equal to the sum of the individual module voltages. If modules are connected in parallel, the total current is equal to the sum of individual module currents.
  • Page 18 When performing installation in dry conditions, please ensure the tools used are dry. Fig 34 Abide with the safety regulations for all other components used in the system, including wiring and cables, connectors, charge c o n t r o l l e r s , inverters, storage batteries and rechargeable batteries, etc.
  • Page 19 Selecting the proper racking system  Always observe the instructions and safety precautions included with the support frame to be used with the module.  Never attempt to drill holes in the glass surface of the module, it will void the warranty. ...
  • Page 20 4. Roof mount  When installing a module on a roof or building, ensure that it is securely fastened and cannot fall as a result of wind or snow loads.  Provide adequate ventilation under a module for cooling (3inch minimum air space between module and mounting surface).
  • Page 21 © 2015 CLIMA-TEKNOLOGIES, LLC...
  • Page 22 Electrical installation General installation  Do not use modules of different configurations in the same system.  The solar photovoltaic array consists of modules connected in parallel, no more than 3 modules can be used in parallel. Modules in parallel can increase the output current of the solar photovoltaic system, especially for applications requiring high currents, low voltages.
  • Page 23 Shown below, branch connectors are used (BR2). If you want to connect the photovoltaic modules by using the cables purchased by yourself, the following requirements must be complied:  Cable installation should comply with all local regional and national regulations. ...
  • Page 24 © 2015 CLIMA-TEKNOLOGIES, LLC...
  • Page 25 If you want to use the connector purchased by yourself the following requirements must be complied:  Use only connectors specially designed for solar electric systems.  Use the recommended or specified tools when installing the connectors.  Do not unplug the connectors when the power is on. ...
  • Page 26 GROUNDING PRINCIPALS Equipment grounding provides protection from shock caused by a ground fault and is required for all PV systems by the NEC. A ground fault occurs when a current-carrying conductor comes into contact with the frame or chassis of an appliance or an electrical box.
  • Page 27 2 Panel Grounding Liquid Tight conduit may be used between the Standard AC Disconnect and the 30 AMP internal breaker in the Outdoor Unit. Max 6 ft. © 2015 CLIMA-TEKNOLOGIES, LLC...
  • Page 28 3 Panel Grounding Liquid Tight conduit may be used between the Standard AC Disconnect and the 30 AMP internal breaker in the Outdoor Unit. Max 6 ft. © 2015 CLIMA-TEKNOLOGIES, LLC...
  • Page 29 MNPV3 With 3 15 amp Circuit breakers Combiner boxes can be used where a disconnect is required by local code. Complete instructions can be found at: http://www.midnitesolar.com/pdfs/MNPV2-3-4-6_manual.pdf © 2015 CLIMA-TEKNOLOGIES, LLC...
  • Page 30: Air Purging

    AIR PURGING Air purging Air and moisture in the refrigerant system have undesirable effects as indicated below: Pressure in the system rises. Operating current rises. Cooling or heating efficiency drops. Moisture in the refrigerant circuit may freeze and block capillary tubing. Water may lead to corrosion of parts in the refrigeration system.
  • Page 31  and a compound meter indicates 0 When m o vin g the unit to a new instead of minus) location, perform evacuation using a 5. After the evacuation is complete, vacuum pump. fully close the handle Lo of the ...
  • Page 32 © 2015 CLIMA-TEKNOLOGIES, LLC...
  • Page 33: Running Test

    RUNNING TEST Perform test operation after completing gas leak check at the flare nut connections and electrical safety check.  Check that all tubing and wiring have been properly connected.  Check that the gas and liquid side service valves are fully open. 1.
  • Page 34 DC4812VRF DC Solar Air Conditioner Model: DC4812VRF DC Solar Air Conditioner Powered by batteries & solar panels Powered By Batteries & Solar Panels Minimum 4 PV Panels DC4812VRF 1000W 250W 250W 250W 250W Outdoor Unit Solar Solar Solar Solar Panel Panel Panel Panel...
