English Table of Contents Intended use ......................3 General notes ......................3 Important notes .......................4 Electrical connection ....................5 Installation .......................6 Minimum clearances ..................6 Terminal connection diagrams ................7 Wiring diagram for 12-27 kW sauna stove with load distribution to control unit and power control unit ..................8 Wiring diagram for sauna heaters to 36 kW without load distribution .....8 Sauna stones ......................9 Maintenance and care ....................9...
Dear Customer, For installation and electrical connection of the rocker switch follow the installation in- You have purchased a high quality technical structions supplied with this part. system which will provide you with many ye- ars of enjoyable sauna bathing. This sauna heating system was constructed in accor- General notes dance with state-of-the-art European safety...
Important notes air intake and exhaust vents must not be closed. Please observe the information If assembled incorrectly, the sys- provided by your sauna cabin supplier. tem will present a fi re hazard. • For the adjustment and control of the sau- Please read this installation guide tho- na heating unit, one of the control units roughly.
in the table. Electrical connection • During the installation of the sauna hea- Your electrician will be able to accomplish ting unit, make certain that the vertical this work without further explanation in ac- cordance with the provided wiring schematic clearance between the upper edge of the and with the help of the circuit diagram sauna heating unit and the sauna ceiling...
Minimum clearances Installation The sauna heating unit is designed for ope- The sauna cabin must have a minimum ration with an input voltage of 400 V AC 3N inside height of 2.10 m. through the sauna control unit. When installing the sauna heater, please ensure that the vertical height between the G 15 = 15 kW top surface of the sauna heater and the...
Terminal connection diagrams 18 kW to control unit 15 kW 5 x 1,5 to LSG to control unit 5 x 1,5 5 x 1,5 to LSG 5 x 1,5 N N N W V U N N N W V U N N N W V U N N N...
Wiring diagram for 12-27 kW sauna stove with load distribution to con- trol unit and power control unit 15 - 27 kW Sensor Saunasteuergerät LSG 9 /18 ECON / EMOTEC control unit 9 kW 6-18 kW U V W N 4 3 2 1 S1 V N L1 L2 L3 N...
Sauna stones Maintenance and care The sauna stone is a natural product. Check All sauna heating units are made of low- the sauna stones at regular intervals. Strong corrosion material. Still, to enjoy your sau- infusion concentrates especially can wea- na heating unit for a long time, you should ken the sauna stones and cause them to maintain and care for the unit.
Page 10
For the installation of sauna heaters, please pay attention to the DIN VDE 0100 part 703 ! This standard makes the following statement valid in your newest expenditure, since Febru- ary 2006, paragraph 703.412.05; Quotation: The additional must be planned for all electric cir- cuits of the Sauna by one or more fault current protection device (RCDs) with a calculation diffe- rence stream not more largely than 30 mA, exclu-...
Service Address: Outside of Germany please contact your EOS-WERKE GÜNTHER GmbH specialist dealer in case of warranty claims. Adolf-Weiß-Straße 43 Direct warranty processing with our service 35759 Driedorf-Mademühlen, Germany department is in this case not possible.
Handling procedures for return shipments (RMA) - Details for all returns ! Dear customer we hope that you will rejoice in the ordered articles. Just in case that you are not entirely contented as an exeption, please follow the procedures specified below.This enabling us to ensure a quick and smooth handling of the return shipment.
