EV8580 Series
Installation Manual
EV8580F/EV8580U-B/EV8580-C
Document Version 0.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EV8580F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EtroVISION EV8580F

  • Page 1 EV8580 Series Installation Manual EV8580F/EV8580U-B/EV8580-C Document Version 0.1...
  • Page 2: About This Guide

    Information contained in this document may be superseded by updates. No representation or warranty is given and no liability is assumed by Etrovision Technology with respect to the accuracy or use of the information, or infringement of patents or other intellectual property rights.
  • Page 3: Table Of Contents

    INTRODUCTION ................1 Dual Streaming Capabilities ................ 1 Package Checklist..................1 Camera Exterior ..................2 Camera Interior ................... 3 PHYSICAL INSTALLATION..............5 INITIAL CONFIGURATION...............6 Initial Requirements..................6 Software Requirements................6 Install EtroScan™..................6 Physical IP Camera Connections ..............6 Connect to the Network................6 Connect Digital I/O ..................
  • Page 4: Introduction

    1 INTRODUCTION This guide is for the use with firmware version 0.1.2. Please pay close attention to areas that are highlighted in YELLOW. These areas highlight special instructions for this firmware release or functionality that is not yet available. 1.1 Dual Streaming Capabilities Cameras support dual streams simultaneously in pre-stage firmware Include: Stream1 Bit Rate...
  • Page 5: Camera Exterior

    1.3 Camera Exterior...
  • Page 6: Camera Interior

    1.4 Camera Interior 1. Lens tilt and swivel adjustment 2. Audio & Microphone (green: audio, red: microphone) 3. Digital I/O 4. Power Input 5. Cable conduit 6. Micro SD Card slot 7. Factory Default Reset button 8. RJ-45 Ethernet Port 9.
  • Page 8: Physical Installation

    2 PHYSICAL INSTALLATION It is recommended leaving the plastic dome covering on until camera installation is complete. 1. Unscrew the screws securing the dome, and pull off dome cover. 2. After preparing anchoring holes, use screws to affix camera to ceiling or other surface (screw holes highlighted below).
  • Page 9: Initial Configuration

    EtroScan™ is a utility is used to configure network settings for IP cameras and other devices (i.e. NVR). EtroScan™ is available via two methods. EtroScan™ can also be downloaded from Etrovision’s website. It is available in the Software Tools section of the Download area, http://www.etrovision.com/Download_list.aspx?no=5.
  • Page 10: Power On Ip Camera

    Power on IP Camera Connect the power adapter to the power connector. The adapter should be connected to 110v~22OV AC socket. There is no power button on the camera, so connecting/disconnecting the power adapter will start/shutdown the IP camera. 3.3 Initial Network Configuration To configure the IP camera’s network settings use the EtroScan™...
  • Page 11 Press the Scan button to list the IP and MAC address list for IP cameras on the network. A new IP camera will display the factory IP address, 192.168.1.2. However, if multiple new devices are present on the network, then multiple instances of 192.168.1.2 will be listed.
  • Page 12: Change Network Setting Via Etroscan

    To identify a specific IP camera, use the MAC address which is located on the bottom of the camera. Below is an example of the label displaying the MAC address. Change Network Setting via EtroScan™ There are two ways to modify the network settings. 1.
  • Page 13: Access Ip Camera Web Interface

    Here a static IP address can be specified or the device can be changed to DHCP. A login is required to complete. Enter pass for the root password. 3.4 Access IP Camera Web Interface MS Internet Explorer is used to access and configure the IP camera. When accessing an IP camera using the web interface for the first time (or when the IP address changes), some configuration for ActiveX controls may be required.
  • Page 14 Click Install or Run for any pop-up windows. Near the top of the browser, there will likely be additional messages. Click on the add-on message, and choose Run Add-on Repeat the above until all ActiveX controls have been initiated. Once the process is complete, the Live View will be displayed.
  • Page 15: Restore Factory Default Settings

    4 RESTORE FACTORY DEFAULT SETTINGS If necessary (e.g. missing root password), the factory default settings can be restored. 1. Power on the camera 2. Wait for the camera to boot up (if there is some problem with the firmware which prevents the camera from booting properly, then skip this step) 3.

This manual is also suitable for:

Ev8580u-bEv8580-c
