2. Hardware Installation

This chapter introduces the system connectors & jumper settings, and guides you to apply
them for field application.

2.1 Before Installation

Before you install the system, make sure you follow the following descriptions.
1. Before removing the board from its anti-static bag, wear an anti-static strap to prevent the
generation of Electricity Static Discharge (ESD). The ESD may be generated by man's physical
touch. It may do damage to the board circuit.
2. Install any connector, module, or add-on card, be sure that the power is disconnected from
the system board. If not, this may damage the system board components, module, or the
add-on-card.
3. When you connect the connectors and memory modules, be careful with the pin
orientations.

2.2 Hardware Features

The following list is for the setup of the connectors and jumpers of the CPU2616.
Item
CN1
CN2
CN3
CN4 ,CN5 10-pin 2.0mm RS-232 port connector (IDC)
CN6
CN7
CN8
CN9,JP1
J1
J2
J3
J4
BZ1
JP2
DIMM1
AMR connector for provides AC97 signals for Audio function (IDC)
40-pin LCD Connector with 24 bit LCD signals (DF13)
10-pin 2.0mm CRT connector (IDC)
PCI-104
10-pin USB connector header
44-pin 2.0mm IDE 2 hard disk connector (IDC)
Compact Flash Socket and Master/Slave Select
5-pin for Keyboard and Mouse 2.0mm connector (JST)
6-pin Power and watchdog of LED indicator header and Reset header
10-pin for RJ45-Lan 2.54mm connector r (JST)
4-pin Power 2.5mm connector
On board Buzzer
3-pin Battery Select /Clean CMOS jumper
DDR So-DIMM Socket 200-pin
