Summary of Contents for JS Automation Corp CPU-2616 PCI-104
- Page 1 CPU-2616 PCI-104 CPU Card User’s Manual 健昇科技股份有限公司 JS AUTOMATION CORP. 新北市汐止區中興路 100 號 6 樓 6F., No.100, Zhongxing Rd., Xizhi Dist., New Taipei City, Taiwan TEL：+886-2-2647-6936 FAX：+886-2-2647-6940 http://www.automation.com.tw http://www.automation-js.com/ E-mail：control.cards@automation.com.tw...
-
Page 2: Table Of Contents
CONTENTS Introducing the CPU2616 System .......................4 Overview............................4 Layout ............................5 Specifications..........................6 Packing List ..........................6 Hardware Installation...........................7 Before Installation........................7 Hardware Features ........................7 2.2.1 J4: Power Connector (4-pin 2.5mm JST) ..............8 2.2.2 J2: External Power/HDD LED’s Indicators & Reset Header ........8 2.2.3 J3: RJ45 LAN /Adapter Connector with LED indicators ..........9 2.2.4 J1: Keyboard/Mouse Connector ................10 2.2.5... - Page 3 4.2.9 Total Memory ......................24 BIOS Features Setup........................25 4.3.1 Virus Warning ......................25 4.3.2 CPU Internal Cache ....................25 4.3.3 First /Second /Third/Boot Other Device/ Boot Device..........26 4.3.4 Boot Up Numlock status....................26 4.3.5 Gate A20 Option ......................26 4.3.6 Typematic rate Setting ....................26 4.3.7 Security Option ......................27 Chipset Features Setup......................27 4.4.1...
- Page 4 5.6.2 Watchdog Timer Enabled...................40 5.6.3 Watchdog Timer Trigger ....................40 5.6.4 Watchdog Timer Disabled ..................41 Technical Reference...........................42 Trouble Shooting for Post Beep and Error Messages..............42 6.1.1 POST BEEP.......................42 6.1.2 Error Message ......................42 Technical Reference.........................44 6.2.1 Physical and Environmental ..................44 6.2.2 Real-Time Clock and Non-Volatile RAM ..............45 6.2.3 CMOS RAM Map......................46 6.2.4...
-
Page 5: Introducing The Cpu2616 System
1. Introducing the CPU2616 System 1.1 Overview The CPU2616 is an AMD Geode™ LX-800 Low power processor, all in one, PCI-104 CPU board. This user’s manual provides information on the physical features, installation, and BIOS setup of the CPU2616. Built to unleash the total potential of the AMD Geode™ Processor, the CPU2616 is a single board computer capable of handling today’s demanding requirements. -
Page 6: Layout
1.2 Layout... -
Page 7: Specifications
1.3 Specifications 1. AMD Geode™ LX800 (500MHz) Low Power CPU. 2. AMD Geode CS5536 chipset and 64KB or above L2 cache inside the CPUs. 3. Supporting One 200 pin So-DIMM socket for up to 1GB DDR-333/400 RAM. 4. One 100M/10M Ethernet port. 5. -
Page 8: Hardware Installation
2. Hardware Installation This chapter introduces the system connectors & jumper settings, and guides you to apply them for field application. 2.1 Before Installation Before you install the system, make sure you follow the following descriptions. 1. Before removing the board from its anti-static bag, wear an anti-static strap to prevent the generation of Electricity Static Discharge (ESD). -
Page 9: J4: Power Connector (4-Pin 2.5Mm Jst)
2.2.1 J4: Power Connector (4-pin 2.5mm JST) Note: Be careful with the pin orientation when installing power connector. A wrong connection can easily destroy your CPU2616 board. 2.2.2 J2: External Power/HDD LED’s Indicators & Reset Header The Power and HDD LED’s has two distinctive statuses: Off for inactive operation and blinking light for activity, and the J2 3, 4 pin (LED1+/LED1-) for Power and 5,6 pin for HDD. -
Page 10: J3: Rj45 Lan /Adapter Connector With Led Indicators
2.2.3 J3: RJ45 LAN /Adapter Connector with LED indicators FB4605A is a RJ45 connector with 2 LEDs for LAN. The left side LED (orange) indicates data which is being accessed and the right side LED (green) indicates on-line status. (On indicates on-line and off indicates off-line) J3 provides twist-pair signals of LAN port if you got LAN version and adapter board (FB4605A) with cable. -
Page 11: J1: Keyboard/Mouse Connector
2.2.4 J1: Keyboard/Mouse Connector J1 is a 6-pin 2.0mm JST connector, use the included KB/MS adapter cables you can attach standard PS/2 type keyboard and mouse. 2.2.5 BZ1 & D2: Onboard Buzzer /Power LED... -
Page 12: Cn1: Audio Connector
2.2.6 CN1: Audio Connector CN1 is a 12-pin 2.0mm IDC connector with AC97 signals for Audio I/O. Use the included Audio cable and FB4641x adapter board for your Audio applications. 2.2.7 CN7: USB Connector Use the USB adapter cable and FB4641 board, you can attach up to 2 USB devices. -
Page 13: Cn4 & Cn5: Serial Port Connectors Rs-232C Pin Definitions
2.2.8 CN4 & CN5: Serial Port Connectors RS-232C Pin Definitions CN4 (COM1) & CN5 (COM2) are 10-pin 2.0mm IDC connectors. The included serial port adapter cables are used to transfer 10-pin 2.0mm IDC into standard DB-9 connector. The following tables show the signal connections of these connectors and the included adapter cable for CN5 & CN6: 2.2.9 JP2: Clear CMOS Data You can use JP2 to clear CMOS data. -
Page 14: Cn8: Ide Hard Disk Connectors
2.2.10 CN8: IDE hard Disk Connectors CN8 is 44-pin 2.0mm IDC connectors. Use the included hard disk cables to attach up to two 2.5” hard disk drives. The following table lists the pin description of CN8. Pin Description Pin Description -RESET GROUND DATA 7... -
Page 15: Cn6: Pci-104 Bus Connectors
2.2.11 CN6: PCI-104 Bus Connectors Signal Signal Signal Signal + 5V + 5V CBE0# AD11 AD10 M66EN AD14 AD13 AD12 + 3.3V CBE1# AD15 + 3.3V SERR# A10 GND B10 PERR# C10 + 3.3V D10 GND A11 STOP# B11 + 3.3V C11 LOCK# D11 GND A12 + 3.3V... -
Page 16: Dimm1: So-Dimm Socket
2.2.12 DIMM1: So-DIMM Socket The DIMM1 socket on the solder side accepts 128MB to 1GB of DDR RAM modules 2.2.13 CN9 & JP1: Compact Flash Socket and Master/Slave Select The Compact Flash socket CN9 (on the solder side) is optional and supports 3.3V Compact Flash and Micro Drives. -
Page 17: Fb4641X: Provides Audio And Usb Board
2.2.14 FB4641x: Provides Audio and USB Board The J3, J4, and J5 connectors on FB4641x are 2-way Line-In, mono Microphone input, and 2-way Lineout respectively. You can connect J1, CN2 cable from CPU2616 CN1 to CN7. The following figure shows these Audio connectors on FB4641x board:... -
Page 18: Installing Crt & Lcd Display
3. Installing CRT & LCD Display This chapter describes the configuration and installation procedure of LCD and CRT displays. Both CRT and LCD displays may be used at the same time. However, each type of LCD requires different BIOS. This section describes the configuration and installation procedure using LCD display. -
Page 19: Crt Display (Cn3)
3.2 CRT Display (CN3) The CPU2616 supports a CRT colored monitor. It can be connected to create a compact video solution for the industrial environment. 254MB simulated VRAM allows a maximum CRT resolution of 1920X1440 with 32 bpp at 85Hz. The following table and figure illustrate the pin definition of CN3 and D-sub 15-pin on the CRT adapter cable: Signal DB-15 PIN... -
Page 20: Cn2: Lcd Connector
3.2.1 CN2: LCD Connector CN2 is a 24-bit LCD interface connector. The pin assignments are listed in the following table. Pin Signal Pin Signal Ground Ground +3.3V +3.3V Ground FP10 FP11 FP12 FP13 FP14 FP15 FP16 FP17 FP18 FP19 FP20 FP21 FP22 FP23... -
Page 21: Bios Setup
4. BIOS Setup This chapter describes the BIOS setup. 4.1 Overview BIOS are a program located on a Flash memory chip of a circuit board. It is used to initialize and set up the I/O peripherals and interface cards of the system, which includes time, date, hard disk drive, the ISA bus and connected devices such as the video display, diskette drive, and the keyboard. -
Page 22: Bios Functions
4.1.1 BIOS Functions On the menu, you can perform the following functions 1. Standard CMOS Features 2. Advanced BIOS Features 3. Advanced Chipset Features 4. Integrated Peripherals 5. Power Management Setup 6. PNP/PCI Configuration 7. Frequency/Voltage Control 8. Set Supervisor Password 9. -
Page 23: Keyboard Convention
4.1.2 Keyboard Convention On the BIOS, the following keys can be used to operate and manage the menu: Item Function To exit the current menu or message Page Up/Page Down To select a parameter Save and exit General Help Item Help Previous Values Fail-Safe Defaults Optimized Defaults... -
Page 24: Hard Disk Setup
4.2.2 Hard Disk Setup The BIOS supports various types for user settings, The BIOS supports <Pri Master>, <Pri Slave>, so the user can install up to two hard disks. For the master and slave jumpers, please refer to the hard disk’s installation descriptions and the hard disk jumper settings. You can select <AUTO>... -
Page 25: Memory
4.2.5 Memory This option is for the display-only which is determined by POST (Power On Self Test) of the BIOS 4.2.6 Base Memory The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system. The value of the base memory is typically 512K for systems with 512K memories installed on the motherboard, or 640K for systems with 640K or more memory installed on the motherboard. -
Page 26: Bios Features Setup
4.3 BIOS Features Setup This section describes the configuration entries that allow you to improve your system performance, or let you set up some system features according to your preference. Some entries here are required by the CPU board’s design to remain in their default settings. 4.3.1 Virus Warning This option may flash on the screen. -
Page 27: First /Second /Third/Boot Other Device/ Boot Device
4.3.3 First /Second /Third/Boot Other Device/ Boot Device This field specifies which device the system checks first upon power on. Available options: LS120, Hard Disk, ZIP100, USB-ZIP, USB-CDROM, USB-HDD, LAN and Disable Default setting: Hard Disk, CDROM, LAN 4.3.4 Boot Up Numlock status This field is used to activate the Num Lock function upon system boot. -
Page 28: Security Option
4.3.7 Security Option This field enables password checking every time when the computer is powered on or every time when the BIOS Setup is executed. If Always is chosen, a user password prompt appears every time and the BIOS Setup Program executes and the computer is turned on. If Setup is chosen, the password prompt appears if the BIOS executed. -
Page 29: Cas Latency
4.4.2 CAS Latency This field specifies the latency for the DDR RAM system memory signals. Available Options: Auto, 1.5, 2.0, 2.5, 3.0 and 3.5 Default setting: Auto 4.4.3 Video Memory Size This field specifies which VGA display memory. You can select either Video memory on the VGA. - Page 30 Flat Panel Type See the Flat Panel Display Table Available Options: Auto and TFT Default setting: Auto Flat Panel Display LCD Type Table Resolution 320x240 640x480 800x600 1024x768 1152x864 1280x1024 1600x1200 Data Bus Type This field specifies the Data Bus width and data type Available Options: 18,24 bits, 1 ppc and 18,24 bits, 2 ppc Default setting: 18,24 bits, 1 ppc Refresh Rate...
-
Page 31: Onboard Audio
4.4.5 Onboard Audio This field specifies the internal Audio Control. Available Options: Disable, Enable Default setting: Enable 4.5 Peripheral Setup This section describes the function of peripheral features. 4.5.1 On-Chip Primary IDE Channel 1 This field specifies the IDE channel that can be applied when using IDE hard disk connector. Available Options: Disabled, Enable Default setting: Enable 4.5.2 Master /Slave Drive PIO mode... -
Page 32: Ide Primary Master/Slave Udma
4.5.3 IDE Primary Master/Slave UDMA Ultra DMA/33 implementation is possible only if your IDE hard drive supports it and the operating environment includes a DMA driver (Windows 95 OSR2 or a third-party IDE bus master driver). If your hard drive and your system software both support Ultra DMA/33, select Auto to enable this option, which allows your hard disk controller to use the fast block mode to transfer data to and from your hard disk drive (HDD). -
Page 33: Power Management
4.6 Power Management Power Management The field determines how much power consumption is needed for the system after selecting the below items. Standby Mode This field defines the continuous idle time before the system enters Standby Mode. If any item defined is enabled &... -
Page 34: Pci/Plug And Play
4.7 PCI/Plug and Play 4.7.1 PNP O/S Installed Set to Yes to inform BIOS that the operating system can handle Plug and Play (PnP) devices. Available Options: Yes, No Default setting: No 4.7.2 Reset Configuration Data: Enable, Disable If you select Enable to reset Extended System Configuration Data (ESCD) when you exit setup is you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operation operating system cannot boot. -
Page 35: Pci/Vga Palette Snoop
IRQ-n/DMA-n Assigned: PCI/Reserved PnP The resources are controlled manually. 1. Reserved Devices compliant with the original PC AT bus specification, and require a specific interrupt/DMA (such as IRQ4, IRQ3 for serial port 1 and 2). 2. PCI/Reserved PnP Devices compliant with Plug and play standard, whether to be designed for PCI or Reserved. - Page 36 Note: it is suggested that you write down the password in a safe place to avoid that password may be forgotten or missing. To set the password, please complete the following steps. 1. Select Change Supervisor Password. 2. Press Enter instead of entering any character when you see the message, “Enter New Supervisor Password.”...
-
Page 37: Driver And Utility
5. Driver and Utility The enclosed diskette includes CPU2616 VGA, AUDIO driver and LAN driver. To install and configure you CPU2616 system, you need to perform the following steps. 5.1 VGA Drivers 5.1.1 WINDOWS XP Driver 1. To install the VGA driver, insert the CD ROM into the CD ROM device, and enter DRIVER>VGA>... -
Page 38: Aes Drivers
5.4 AES Drivers 5.4.1 WINDOWS XP Driver 1. To install the SysChip driver, insert the CD ROM into the CD ROM device, and enter DRIVER>SysChip>GeodeLX_XP_AES. If your system is not equipped with a CD ROM device, copy the AES driver from the CD ROM to a CF. 2. -
Page 39: Watchdog Timer
5.6 Watchdog Timer This section describes how to use the Watchdog Timer, including disabled, enabled, and trigger functions. The CPU2616 is equipped with a programmable time-out period watchdog timer. You can use your own program to enable the watchdog timer. Once you have enabled the watchdog timer, the program should trigger the I/O every time before the timer times out. -
Page 40: Watchdog Timer Setting
5.6.1 Watchdog Timer Setting The watchdog timer is a circuit that may be used from your program software to detect system crashes or hang-ups. LED on the Front side is the watchdog timer indicator. Whenever the watchdog timer is enabled, the LED will blink to indicate that the timer is counting. The watchdog timer is automatically disabled after reset. -
Page 41: Watchdog Timer Enabled
5.6.2 Watchdog Timer Enabled To enable the watchdog timer, you have to output a byte of timer factor to the watchdog. The following is a Turbo C program, which demonstrates how to enable the watchdog timer and set the time-out period at 6 seconds. #include “stdio.H”... -
Page 42: Watchdog Timer Disabled
5.6.4 Watchdog Timer Disabled To disable the watchdog timer, simply write a 00H to the watchdog register. #include “stdio.H” #include “WDLIB.H” main( ) InitWD(equWdUnitS); printf (“Disable Watch Dog”); //Disable watch dog DisWD(WD_TIME);... -
Page 43: Technical Reference
6. Technical Reference This section outlines the errors that may occur when you operate the system, and also gives you the suggestions on solving the problems. Topic include: Trouble Shooting for Post Beep & Error Messages Technical Reference 6.1 Trouble Shooting for Post Beep and Error Messages The following information informs the Post Beep &... - Page 44 DISKETTE DRIVES OR TYPES MISMATCH ERROR When the diskette drive type is different from CMOS, please run setup or configure the drive again. ERROR ENCOUNTERED INITIALIZING HARD DRIVE When you can‘t initializes the hard drive, ensure the following things: 1. The adapter is installed correctly 2.
-
Page 45: Technical Reference
REBOOT ERROR When this error occurs that requires you to reboot. Press any key and the system will reboot. SYSTEM HALTED Indicates the present boot attempt has been aborted and the system must be rebooted. Press and hold down the CTRL and ALT keys and press DEL. 6.2 Technical Reference 6.2.1 Physical and Environmental Temperature: Operating 0°C ~ 60°C... -
Page 46: Real-Time Clock And Non-Volatile Ram
6.2.2 Real-Time Clock and Non-Volatile RAM The CPU2616 contains a real-time clock compartment that maintains the date and time in addition to storing configuration information about the computer system. It contains 14 bytes of clock and control registers and 114 bytes of general purpose RAM. Because of the use of CMOS technology, it consumes very little power and can be maintained for long periods of time using an internal Lithium battery. -
Page 47: Cmos Ram Map
6.2.3 CMOS RAM Map Register Description 00h -10h Standard AT-compatible RTC and Status and Status Register data definitions 11h – 13h Varies Equipment Bits 7-6 Number of Floppy Drives 00 1 Drive 01 2 Drives Bits 5-4 Monitor Type 00 Not CGA or MDA 01 40x25 CGA 01 2 Drives 80x25 CGA Bits 3 Display Enabled 0 Disabled... -
Page 48: I/O Port Address Map
6.2.4 I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses, which also becomes the identity of the device. There is a total of 1K-port address space available. The following table lists the I/O port addresses used on the Industrial CPU Card. Address Device Description 000h - 01Fh... -
Page 49: Interrupt Request Lines (Irq)
6.2.5 Interrupt Request Lines (IRQ) There are a total of 15 IRQ lines available on the Industrial CPU Card. Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on the Industrial CPU Card. Level Function IRQ0 System Timer Output... -
Page 50: Serial Ports
6.2.7 Serial Ports The ACEs (Asynchronous Communication Elements ACE1 to ACE2) are used to convert parallel data to a serial format on the transmit side and convert serial data to parallel on the receiver side. The serial format, in order of transmission and reception, is a start bit, followed by five to eight data bits, a parity bit (if programmed) and one, one and half (five-bit format only) or two stop bits. - Page 51 Interrupt Identification Register (IIR) Bit 0: “0” if Interrupt Pending Bit 1: Interrupt ID Bit 0 Bit 2: Interrupt ID Bit 1 Bit 3: Must be 0 Bit 4: Must be 0 Bit 5: Must be 0 Bit 6: Must be 0 Bit 7: Must be 0 Line Control Register (LCR) Bit 0: Word Length Select Bit 0 (WLS0)
- Page 52 Line Status Register (LSR) Bit 0: Data Ready (DR) Bit 1: Overrun Error (OR) Bit 2: Parity Error (PE) Bit 3: Framing Error (FE) Bit 4: Break Interrupt (BI) Bit 5: Transmitter Holding Register Empty (THRE) Bit 6: Transmitter Shift Register Empty (TSRE) Bit 7: Must be 0 MODEM Status Register (MSR) Bit 0: Delta Clear to Send (DCTS)
- Page 53 Divisor Latch (LS, MS) Bit 0: Bit 0 Bit 8 Bit 1: Bit 1 Bit 9 Bit 2: Bit 2 Bit 10 Bit 3: Bit 3 Bit 11 Bit 4: Bit 4 Bit 12 Bit 5: Bit 5 Bit 13 Bit 6: Bit 6 Bit 14 Bit 7: Bit 7 Bit 15 Desired Baud Rate Divisor Used to Generate 16x Clock...
-
Page 54: Appendix
7. Appendix 7.1 Dimension...
