Page 1: Quick Start Guide
IP Camera Quick Start Guide ==================== H Series V3.1... -
Page 2: Package Contents
Bracket and Screws Quick Start Guide 2. Get Started Step-1 Download and Install App iOS: Search and download Mustcam from App Store. Android: Search and download Mustcam from play.google.com. Install App. After installed, click to start it. Note: The operation interface of iOS and Android maybe different slightly. - Page 3 Step-3 Add IP Camera to App Start the App, from the bottom main menu enter Camera page, click at the right-top corner. Name: You can name the camera as you need e.g. Living room. UID: Input the camera UID by typing or Scan QR. The UID is on the label at the bottom of the Camera.
- Page 4 Step-4 Configure IP Camera to WIFI Connection If needed, you can configure the IP Camera to WIFI connection. From Camera page and click , choose Advance Config and then WIFI Config. Choose a target WIFI Network and input password, and then disconnect net cable when the camera starts initialization.
-
Page 5: View Live Video
3. View Live Video There are two ways to view live video. 3.1 From the Video page ① ② ③ ④ ① Click , (If there is no camera online, it will show No online camera, please go to Camera page and add camera.) ②... - Page 6 3.3 Preview Interface Icon Definition Audio On/Off Cruise (up/down) Mic On/Off, Press to Cruise (left/right) talk, release when finished. Snapshot Resolution Record Video Brightness Mirror Contrast Flip Setting Single Window Four Window 4. Settings 4.1 By clicking , you can enter setting page, with options as follows: Modify Camera: Modify camera Name/UID/Password.
- Page 7 4.2 Advance Config: Motion Detection Sensitivity: sensitiveness to trigger the motion detection. Alarm Interval: interval time for snapshot Change WIFI network for the IP Camera. Switch connection from wired to wireless. See 4.3. Setup record time, resolution and file length. Setup the Pan/Tilt rotation speed.
- Page 8 4.3 WIFI Config Here you can: Switch the IP Camera connection from one WIFI network to another. Switch connection from wired wireless (WIFI). Choose a target WIFI Network and input password, and then disconnect net cable when the camera starts initialization. After initialized, the camera will switch to WIFI connection in 60 seconds.
- Page 9 6. Access the Camera by PC 6.1 Install the software Mustcam IPC Viewer (you can download it from http://www.mustcam.com/download/) and start it. User Name: admin Password: Default password is 8888; you can change the password from Setting page later. 6. 2 Main Interface...
- Page 10 6.3 Add IP Camera (1) Click to enter Setting page, as follows: (2) Click +, and there are two ways to add an IP Camera: ① By IP Address: Input the camera’s IP address, port, Username/Password. ② By P2P (recommended): Input UID (on the label at the bottom of the camera) and P2P Password (8888 by default).
-
Page 11: Other Operations
7. Other Operations 7.1 WPS By WPS, you can establish WiFi connection between IP Camera and router directly too. This requires that your router has WPS function. If you are not sure about this, please refer to your router user manual. After the camera powered on and when its green LED flashes press the WPS button on your router and its WPS light will flash, waiting for match. -
Page 12: Tech Support
8. Tech Support For technical issue, please contact us at support@mustcam.com. For Mustcam IPC Viewer and Search Tool, please download at http://www.mustcam.com/download.
