Summary of Contents for Mustcam H Series

  • Page 1 IP Camera Quick Start Guide ==================== H Series V3.1...
  • Page 2: Package Contents

    Bracket and Screws Quick Start Guide 2. Install App 2.1 Download App iOS: Search and download Mustcam from App Store. Android: Search and download Mustcam from play.google.com. 2.2 Install App. After installed, click to start it, as follows: You can click + to add camera for live video.
  • Page 3 3. Configure IP Camera to Network 3.1 Power the IP Camera by using the supplied power adaptor. The camera will then start and initialize itself by rotating Pan/Tilt one round respectively. The green LED (at 6-o’clock position) will flash quickly for 90 seconds, waiting for WIFI configuration.
  • Page 4 Direction Connection between Smart Phone and IP Camera: Change your Smart Phone’s WIFI network to the IP Camera’s SSID. Then you can configure the IP Camera to other WIFI network. Please refer to 6.3. 3.2.2 By Net cable: Connect the IP Camera to router by Net cable. If you need to switch wired connection to wireless connection, please go to WIFI Config under Advance Config.
  • Page 5 There are 2 options to add IP Camera. 4.1 Add a New Camera (by WIFI): This enable you to configure an IP Camera to WIFI Network by WIFI directly, no need by Net cable. The WIFI network of your Smart phone should be the same as the WIFI network that the camera will join.
  • Page 6: View Live Video

    5. View Live Video There are two ways to view live video. 5.1 From the Video page ① ② ③ ④ ① Click +, (If there is no camera online, it will shows No online camera, please go to Camera page to add camera.) ②...
  • Page 7 5.3 Preview Interface Icon Definition Audio On/Off Cruise (up/down) Mic On/Off Cruise (left/right) Snapshot Resolution Record Video Brightness Mirror Contrast Flip Setting Single Window Four Window 6. Settings 6.1 By clicking , you can enter setting page, functions are as follows: Modify Camera: Modify camera Name/UID/Password.
  • Page 8 6.2 Advance Config: Motion Detection Sensitivity: sensitiveness to trigger the motion detection. Alarm Interval: interval time for snapshot Change WIFI network for the IP Camera. Switch connection from wired to wireless. Setup record time, resolution and file length. Setup the Pan/Tilt rotation speed. Setup the brightness (darkness) to trigger IR-LED.
  • Page 9 7. View Record Picture & Video Click Media from the bottom main menu. Alarm Records: View pictures captured when alarm triggered. You can switch different camera by clicking Snapshots Files: View taken pictures. You can switch different camera by clicking Record Files: View recorded video clips.
  • Page 10 8. Access the Camera by PC 8.1 Install the software Mustcam IPC Viewer (you can download it from http://www.mustcam.com/download/) and start it. User Name: admin Password: Default password is 8888; you can change the password from Setting page later. 8.2 Main Interface...
  • Page 11 8.3 Add IP Camera (1) Click to enter Setting page, as follows: (2) Click +, and there are two ways to add an IP Camera: ① By IP Address: Input the camera’s IP address, port, Username/Password. ② By P2P (recommended): Input UID (on the label at the bottom of the camera) and P2P Password (8888 by default).
  • Page 12: Tech Support

    9. Tech Support For technical issue, please contact us at support@mustcam.com. For Mustcam IPC Viewer and Search Tool, please download at http://www.mustcam.com/download.
